Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409

  • Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409
  • Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409
  • Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409
  • Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409
Place of Origin China
Brand Name DELTA
Certification ISO
Model Number 8810 Alloy / UNS N08810
Minimum Order Quantity 500 kgs
Price 40-45 USD/Kg
Packaging Details standard packing for export
Delivery Time 5 - 12 days based on the quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 3 Ton per week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Products Nickel Alloy Bars Grade 8810 Alloy / UNS N08810
Thickness 0.6 - 20.0mm Size 1219*2438 1500*6000mm
Standard ASTM EN Service Cutting
Loading Port Shanghai Port Surface 2B NO.1
Highlight

UNS N08810 Nickel Alloy Plate

,

ASME B409 Nickel Alloy Plate

,

UNS N08800 Nickel Alloy Plate
Leave a Message
Product Description

Incoloy 800 / 800H Nickel Alloy Plate UNS N08800 / UNS N08810 Plate Sheet ASME B409



Products Description



Product Name Incoloy 800/800H/800HT Plate/Sheet (UNS N08800,UNSN 08810,UNSN 08811)
Technology Hot rolled , Cold rolled
Grade Inconel 600, Inconel 601, Inconel 625, Inconel 617, Inconel 690, Inconel 718, Inconel X-750
Incoloy A-286, Incoloy 800, Incoloy 800H, Incoloy 800HT
Incoloy 825, Incoloy 901, Incoloy 925, Incoloy 926
Monel 400, Monel K-500
Hastelloy C22, Hastelloy C-276, Hastelloy B-2, Hastelloy B-3, Hastelloy X
Specifications ASTM, UNS, JIS, EN, AFNOR
Surface 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Processing Service
Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining
Deformation processing : Bending / Cutting / Rolling / Stamping
Delivery time 10-30 days subject to the clients' requirement and quantity
Package clients' requirement and Standard export sea-worthy packing
MOQ 1 ton



Incoloy 800/800H/HT Plate/Sheet

Alloy 800 series (Incoloy 800, 800H and 800HT) are nickel-iron-chromium superalloys that offer high temperature strength and resistance to oxidation, carburization and other types of high-temperature corrosion.

Available Size Range

Dimension Range
thickness 0.2-100mm
Width 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, etc.
or customer's request
Length 1000mm~6000mm,
or as customer's request

Chemical Analysis

  % C Mn Si Gr S Ni Cu Fe Ai Ti
800 Min. - - - 19 - 30 - Balance 0. 15 0. 15
Max. 0.10 1.5 1 23 0. 015 35 0.75 Balance 0.60 0.60
800H Min. 0. 05 - - 19 - 30 - Balance 0. 15 0. 15
Max. 0.10 1.5 1 23 0. 015 35 0.75 Balance 0.60 0. 6
800HT Min. 0. 06 - - 19 - 30 - Balance 0. 15 0. 15
Max. 0.10 1.5 1 23 0. 015 35 0.75 Balance 0.60 0.60



Mechanical Properties



Mechanical properties Tensile, min, ksi[MPa] Yield, min, ksi[MPa] Elongation, %(min)
Incoloy 800 75[517] 30[207] 30
Incoloy 800H 65[448] 25[172] 30
Incoloy 800HT 65[448] 25[172] 30
Incoloy 825 85[586] 35[241] 30



Applications

800 Heat exchangers and process piping Furnace components Ammonia effluent coolers

800H Chemical and petrochemical processing Pressure vessels Heat exchangers Industrial furnaces
