High Credit Wholesale ASTM A240 1.4547 F44 S31254 254smo Duplex Stainless Steel Plate

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProducts Name | Stainless Steel Checkered Plate | Grade | 254SMO |
---|---|---|---|
Thickness | 0.6-30.0mm | Standard | ASTM EN GB |
Width | 1000mm 1219mm 1500mm | Surface | 2B NO.1 |
Brand | TISCO BAOSTEEL | MOQ | 1 Ton |
Highlight | 1.4547 Duplex Stainless Steel Plate,254smo Duplex Stainless Steel Plate,ASTM A240 Duplex Stainless Steel Plate |
High Credit Wholesale ASTM A240 1.4547 F44 S31254 254smo Duplex Stainless Steel Plate
Item | 254SMO Stainless Steel Plate |
Raw Material | Stainless steel sheet (hot rolled and cold rolled) |
Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, 2205 ,2507,254SMO,253MA.etc. |
Thickness | 0.6 - 30.0mm |
Stock Thickness | 0.6mm ,0.8mm,1.0mm,1.2mm,1.5mm.2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,25mm,30.0mm |
Width | 1000mm 1219mm 1500mm or cutting any size as your request |
Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
Package | Standard export package |
Stainless steel is an alloy steel whose main component is iron, while containing at least 11% chromium, as well as other elements such as nickel, molybdenum, manganese and so on. The following are some properties of stainless steel:
Alloy 254 SMO is a very high end, molybdenum and nitrogen alloyed super austenitic stainless steel with low carbon content. It demonstrates outstanding resistance to pitting, crevice corrosion stress cracking, and corrosion fatigue uniform corrosion. Alloy 254 SMO is substantially stronger than the common austenitic grades, with strength nearly twice that of 300 series stainless steel. It is also characterized by high ductility and impact strength. With high levels of chromium, molybdenum, and nitrogen, Alloy 254 SMO is frequently used in high chloride environments, such as brackish water, seawater, pulp mill bleach plants, and other chloride process streams. In some applications it has even been found to be a more cost effective substitute for high nickel and titanium alloys.
Corrosion resistance: Stainless steel is known for its excellent corrosion resistance. The chromium element reacts with oxygen to form a dense oxide film (chromium oxide layer), which prevents further oxidation and corrosion on the surface of the steel, making the stainless steel resistant to the erosion of most chemical media. This makes stainless steel widely used in environments containing water, gases and chemicals.
High temperature performance: stainless steel maintains good performance at high temperatures and can maintain structural stability and strength for a long time. This makes stainless steel suitable for high-temperature processes and applications, such as petrochemical, energy production and other fields.
Mechanical properties: Stainless steel has excellent mechanical properties, including strength, hardness and ductility. This makes stainless steel widely used in manufacturing industries, including automotive, aerospace, construction and manufacturing.
Aesthetic: The surface of stainless steel is smooth and uniform, and it can show different appearance effects by polishing, brushing or painting. This makes stainless steel in architectural decoration, furniture manufacturing, art production and other fields have a wide range of applications.
Renewable: Stainless steel is a recyclable material, through recycling and reuse, can reduce resource consumption and environmental pollution, in line with the principle of sustainable development.
In general, stainless steel has excellent properties such as corrosion resistance, high temperature resistance, good mechanical properties, aesthetics and renewability, making it widely used in various industrial and civil fields.
Chemical Composition:
Stainless steel is an austenitic stainless steel that has a composition of chromium, nickel, and manganese. Its chemical composition is as follows:
Grade | Chemical Composition (%) | |||||||
c | si | Mn | P | s | Ni | Cr | Mo | |
201 | ≤0.15 | ≤0.75 | 5.5-7.5 | ≤0.06 | ≤ 0.03 | 3.5-5.5 | 16.0-18.0 | - |
301 | ≤0.15 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 6.0-8.0 | 16.0-18.0 | - |
304 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 8.0-10.5 | 18.0-20.0 | - |
304L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0-13.0 | 18.0-20.0 | - |
316 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 |
316Ti | ≤0.08 | ≤0.75 | ≤2.0 | ≤0.045 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 |
310S | ≤0.08 | ≤1.5 | ≤2.0 | ≤0.045 | ≤0.03 | 19-22 | 24-26 | |
316L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0-15.0 | 16 .0-1 8.0 | 2.0-3.0 |
321 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.013 | 17.0-1 9.0 | - |
405 | ≤0.08 | ≤1.0 | ≤1.0 | ≤0.04 | ≤0.03 | 0.6 | 11.5-14.5 | |
409 | ≤0.08 | ≤1.0 | ≤1.0 | ≤0.04 | ≤0.03 | 0.6 | 11.5-14.5 | |
409L | ≤0.08 | ≤1.0 | ≤1.0 | ≤0.04 | ≤0.03 | 0.6 | 11.5-14.5 | |
410 | ≤0.15 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.03 | - | 11.5-13.5 | - |
430 | ≤0.12 | ≤0.75 | ≤1.0 | ≤0.040 | ≤ 0.03 | ≤0.60 | 16.0-18.0 | - |
420 | ≤0.05 | ≤1.0 | ≤1.0 | ≤0.04 | ≤0.03 | 0.75 | 12-14 | 0.5 |
430 | ≤0.12 | ≤1.0 | ≤1.0 | ≤0.04 | 0.03 | 0.5 | 16-18 | 0.75 |
444 | ≤0.025 | ≤1.0 | ≤1.0 | ≤0.04 | 0.03 | 1 | 17.5-19.5 | 1.75-2.5 |
904L | ≤0.02 | ≤1.0 | ≤2.0 | ≤0.045 | 0.035 | 23-28 | 19-23 | 4.0-5.0 |
2205 | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.03 | 0.02 | 4.5-6.5 | 22.0-23.0 | 3.0-3.5 |
2507 | ≤0.03 | ≤0.8 | ≤1.0 | ≤0.035 | 0.02 | 6.0-8.0 | 24-26 | 3.0-5.0 |
Product Name
|
ASTM A240 1.4547 F44 S31254 254SMO Duplex Stainless Steel Plate With Different Thickness | |||
Thickness
|
0.3mm-16mm
|
|||
Width
|
1000mm-2000mm
|
|||
Length
|
2000 mm , 2438 mm , 3000 mm , 6000 mm OR as reqirement
|
|||
Finish
|
No.1 , 2B , HL , NO.4 , BA , SB ,1D , 2D , 2C , 2E , NO.5 , NO.9
|
|||
Technical
|
Hot rolled,Cold rolled
|
|||
Standard
|
ASTM 240 , A480 , JIS G 4304 , EN 10088-2
|
|||
MOQ
|
1 ton
|
|||
Certification
|
MTC Type 3.1 , PMI , CO
|
|||
Delivery Time
|
7 days if have stock
|
Thickness and Width:
The thickness and width of stainless steel an vary according to specific needs and applications. Generally speaking, the thickness of stainless steel can range from a very thin few millimeters to tens of millimeters, and the width is usually between tens of millimeters and several meters.
Grade | GB | ASTM | DIN | JIS | BS |
200 series stainless steel | 12Cr17Mn6Ni5N | 201 | 1.4371 | SUS201 | - |
12Cr18Mn8Ni5N | 201 | 1.4373 | SUS202 | 284S16 | |
300 series stainless steel | 12Cr17Ni7 | 301 | 1.4319 | SUS301 | 301S21 |
06Cr19Ni10 | 304 | 1.4301 | SUS304 | 304S15 | |
022Cr19Ni10 | 304L | 1.4306 | SUS304L | 304S12 | |
06Cr19Ni10N | 304N | 1.4315 | SUS404N1 | - | |
16Cr23Ni13 | 309 | 1.4828 | SUH309 | ||
06Cr23Ni13 | 309S | 1.4833 | SUS309S | ||
20Cr25Ni20 | 310 | 1.4821 | |||
06Cr25Ni20 | 310S | 1.4845 | SUS310S | ||
06Cr17Ni12Mo2 | 316 | 1.4401 | SUS316 | 316S16 | |
07Cr17Ni12Mo2 | 316H | 1.4436 | |||
06Cr17Ni12Mo3Ti | 316Ti | 1.4571 | SUS316Ti | 320S31 | |
022Cr17Ni12Mo2 | 316L | 1.4404 | SUS316L | 316S12 | |
022Cr17Ni13Mo2N | 316LN | 1.4429 | SUS316LN | 316S61 | |
06Cr19Ni13Mo3 | 317 | 1.4436 | SUS317 | 317S16 | |
022Cr19Ni13Mo3 | 317L | 1.4438 | SUS317L | 317S12 | |
06Cr18Ni9Ti | 321 | 1.4541 | SUS321 | 321S12 | |
06Cr18Ni11Nb | 347 | 1.4550 | SUS347 | 347S17 | |
07Cr18Ni11Nb | 347H | 1.4912 | SUS347H | ||
Duplex stainless steel | 015Cr20Ni18Mo6CuN | 254SMo | 1.4547 | ||
015Cr21Ni26Mo5Cu2 | 904L | 1.4539 | |||
06Cr26Ni4Mo2 | 329 | SUS329J1 | |||
022Cr19Ni5Mo3Si2N | 3RE60 | 1.4417 | DP11 | ||
022Cr22Ni5Mo3N | F51 | 1.4462 | SUS329J3L/DP8 | ||
022Cr23Ni5Mo3N | F60 | ||||
022Cr25Ni7Mo4N | F53 | 1.4410 | |||
03Cr25Ni6Mo3Cu2N | F61 | 1.4507 | SUS329J4L | ||
022Cr25Ni7Mo4CuWN | F55 | 1.4362 | DP11 | ||
022Cr23Ni4MoCuN | 1.4362 | DP11 | |||
022Cr25Ni6Mo2N | 1.4460 | ||||
Precipitation hardening type stainless steel | 05Cr15Ni5Cu4Nb | 15-5PH | 1.4545 | XM-12 | |
05Cr17Ni4Cu4Nb | 17-4PH | 1.4542 | |||
07Cr17Ni7Al | 17-7PH | 1.4568 | |||
400 series stainless steel | 06Cr13Al | 405 | 1.4002 | SUS405 | 405S17 |
06Cr111Ti | 409 | SUS409 | |||
022Cr111Ti | 409L | 1.4512 | SUH409L | ||
10Cr17 | 430 | 1.4016 | SUS430 | 430S15 | |
Y10Cr17 | 430F | 1.4104 | SUS430F | ||
019Cr19Mo2NbTi | 444 | 1.4521 | SUS444 | ||
06Cr13 | 410S | 1.4000 | SUS410S | 430S17 | |
12Cr13 | 410 | 1.406 | SUS410 | 410S21 | |
2Cr13 | 420 | 1.4021 | SUS420J1 | 420S37 | |
3Cr13 | 420 | 1.4028 | SUS420J2 | 420S45 | |
17Cr16Ni2 | 431 | 1.4057 | SUS431 | 431S29 | |
108Cr17 | 440C | 1.4125 | SUS440S | ||
Y108Cr17 | 440F | SUS440F |
We can provide different specifications and sizes of stainless steel, and can choose the appropriate thickness and width according to the specific needs.
Hot Rolled and Cold Rolled
Stainless steel products can be manufactured using either hot rolled or cold rolled techniques. Hot rolling involves heating the steel above its recrystallization temperature and then passing it through rollers to form the desired shape. Cold rolling, on the other hand, involves passing the steel through rollers at room temperature to reduce its thickness.
APPLICATIONS:
Due to its high levels of molybdenum and nickel, Alloy 254 SMO is frequently used in high chloride environments. Examples of applications that call for the used of Alloy 254 SMO include:
* Petroleum production
* Saltwater handling
* Food and chemical processing equipment
* Pulp mill bleach systems
* Flue gas desulphurization scrubbers
* Tall oil distillation columns
* Offshore oil & gas production equipment
* Desalination equipmentSemi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Different Finishes
Stainless steel comes in different finishes that can affect its appearance and properties. Here are some common finishes:
Different Finishes |
2B: This is a smooth, reflective finish that is produced by cold rolling followed by annealing and descaling. |
No.1: This is a rough, dull finish that is produced by hot rolling followed by annealing and pickling. |
SB: This is a satin finish that is produced by applying a fine abrasive material to the surface of the steel. |
BA: This is a bright, mirror-like finish that is produced by buffing the surface of the steel with a fine abrasive material. |
HL: This is a hairline finish that is produced by brushing the surface of the steel with a fine abrasive material. |
Mirror: This is a highly reflective finish that is produced by polishing the surface of the steel with a very fine abrasive material. |
