SAE4320H Alloy Steel Round Rod in 6m Length ASTM AISI Standard Forged Steel Rod
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | SAE4320H |
| Minimum Order Quantity | 1 Ton |
| Price | 600-885USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Alloy Steel Round Bar | Diameter | 10 - 350mm |
|---|---|---|---|
| Length | 6m | Tech | Hot Rolled |
| Service | Cutting | MOQ | 1 Ton |
| Loading Port | Shanghai Port | Standard | ASTM EN GB |
| Highlight | ASTM AISI Steel Round Rod,6m Length Steel Round Rod,Forged Steel Round Rod |
||
Product Description
SAE4320H Alloy Steel Round Rod in 6m Length
Products Specification
| Products Name |
Alloy SAE4320H Steel Round Bar |
| Diameter | 10 - 300mm |
| Length | 6m or custom cutting any length as request |
| Type | Hot Rolled |
| Brand | BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc |
| MOQ | 1 Ton |
| Loading Port | Shanghai Port |
| Packing | packing by steel wire rope |
| Deliver time | 5 - 7 days for stock materials |
| Other Grade |
Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov, 15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo, 40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo ,30CrNiMo8,34CrNiMo6 |
| Standard | ASTM GB EN DIN |
| Application | Structure and Industrial |
Regular Standard Size of our SAE4320H Round Bar in Stock
| Standard Diameter | 10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300 320 330 350mm |
Alloy steel contains alloying elements such as aluminum, chromium, copper, titanium, nickel, silicon and manganese in varying amounts to manipulate the properties of steel such as weldability, strength, formability, hardenability and corrosion resistance.
AISI 4320H is a nickel-chromium-molybdenum steel. The following section will discuss about AISI 4320H alloy steel.
Chemical Composition
The chemical composition AISI 4320H alloy steels is outlined in the following table.
| Element | Content (%) |
|---|---|
| Iron, Fe | 95.745 - 97.18 |
| Nickel, Ni | 1.55 - 2 |
| Manganese, Mn | 0.40 - 0.70 |
| Chromium, Cr | 0.35 - 0.65 |
| Molybdenum, Mo | 0.20 - 0.30 |
| Carbon, C | 0.17 - 0.23 |
| Silicon, Si | 0.15 - 0.30 |
| Sulfur, S | ≤0.040 |
| Phosphorous, P | ≤0.035 |
Physical Properties
The following table shows the physical properties of AISI 4320H alloy steels.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 7.85 g/cm3 | 0.284 lb/in3 |
Mechanical Properties
The mechanical properties of AISI 4320H alloy steels are displayed in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 1505 MPa | 218300 psi |
| Yield strength | 1050 MPa | 152000 psi |
| Modulus of elasticity | 1225 GPa | 177700 psi |
| Bulk modulus | 140 GPa | 20300 ksi |
| Shear modulus | 80 GPa | 11600 ksi |
| Poisson’s ratio | 0.29 | 0.29 |
| Elongation at break | 13.50% | 13.50% |
| Reduction of area | 48.20% | 48.20% |
| Hardness, Brinell | 429 | 429 |
| Hardness, Vickers | 455 | 455 |
| Hardness, Knoop | 461 | 461 |
| Hardness, Rockwell C | 46 | 46 |
| Hardness, Rockwell B | 105 | 105 |
Thermal Properties
The thermal properties of AISI 4320H alloy steels are given in the following table
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@-18-95°C/-0.4-203°F) | 11.3 µm/m°C | 6.28 µin/in°F |
| Thermal conductivity | 44.5 W/mK | 309 BTU.in/hrft².°F |
Other Designations
Other designations that are equivalent to AISI 4320H alloy steels include the following.
- ASTM A304
- SAE J1268
- AMS 6299
Applications
The following are the list of applications of AISI 4320H alloy steels:
- Heavy-section gears
- Pinions
- Other heavy-duty machinery components
