Super Austenitic 317L Stainless Steel Sheet Plate Cold Rolled And Hot Rolled S31703 Stainless Steel
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 316L 309S 310S 321 347 904L 2205 2507 254SMO |
| Minimum Order Quantity | 400 kgs |
| Price | 2200 -3220 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plates | Grade | 304 316L 309S 310S 321 347 904L 2205 2507 254SMO |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 1.0 - 30.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 200 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | S31703 Steel Sheet Plate,Hot Rolled Steel Sheet Plate,Cold Rolled Steel Sheet Plate |
||
Product Description
Super Austenitic 317L Stainless Steel Sheet Plate Cold Rolled and Hot Rolled S31703 Stainless Steel
|
Product Name
|
Stainless steel sheet and plate
|
|
Standard
|
ASTM AISI DIN, EN, GB, JIS
|
|
Steel Grade
|
200 Series: 201,202
300 Series: 301,304,304L,316,316L,316Ti,317L,321,309s,310s 400 Series: 409L,410,410s,420j1,420j2,430,444,441,436 Duplex Steel: 904L,2205,2507,2101,2520,2304 |
|
Thickness
|
0.1mm-60mm (as required)
|
|
Size
|
1219*2438,1500*6000,1800*6000,2000*6000mm(as required)
|
|
Technique
|
Cold Rolled, Hot Rolled
|
|
Surface
|
No.1 2B BA 6K 8K Mirror No.4 Hairline
|
|
Tolerance
|
±1%
|
|
Price Terms
|
FOB,CFR,CIF
|
|
Application
|
It is widely used to make all kinds of container, furnace shell, furnace plate, bridge and automobile static steel plate, low
alloy steel plate, bridge steel plate, made steel plate, boiler steel plate, pressure vessel steel plate, pattern steel plate, automobile girder steel plate. Some parts and welded components of tractors. |
317L (or UNS S31703) is an austenitic alloy or SS with chromium-nickel-molybdenum content. Besides, 317L is famous for its low carbon corrosion resisting features.
Due to its makeup content, it has high chloride pitting which makes its use in various industries perfect.
The other names 317L is identified by in the industry include:
- ASTM A240
- UNS S31703-317L
- ASTM A182
- ASME SA 240
- ASTM A167
Advantages of 317L Stainless Steel
There are many reasons why you should consider 317L SS for your applications:
- 317L is able to resist corrosion to very high levels which includes pitting and crevice. This is due to its content makeup.
- Unique mechanical qualities. It comes with very strong tensile capacity. This makes it very strong.
- 317L alloy is used for different productions or metal fabrication methods.
- It comes with the finest formability features.
- This alloy has very good weldability features.
- 317L SS is non-magnetic.
- Due to its low carbon, it is protected from sensitization that comes from welding.
- They are very easy to handle and use.
- High durability levels are assured with this SS.
- Very easy to maintain and to clean as well.
- Resistant to oxidation.
- Has low weight.
Chemical Properties
With 20% chromium, 11 – 15% nickel, 3 – 4% molybdenum, including iron (balanced level), and more, the chemical composition of 317L is indeed a strong one.
Other elements found in 317L include manganese 2%, 0.03% sulfur and carbon mixture, 1% silicon, and 0.045% phosphorus.
Due to the above details, they come with these chemical features:
- Rusting and corrosion. Since it has high quantities of molybdenum, it doesn’t corrode or rust easily.
- Resistant to various acidic environments. To many chemicals, 317L alloy is resistant. These include acidic chlorine, sulfuric acid, and phosphorus acid.
- Pitting and crevice corrosion. 317L alloy even with pitting and crevice doesn’t corrode at all.
- It also comes with the very best welding features. However, oxyacetylene welding method needs to be prevented.
Physical Properties
- 317L is not magnetic.
- It has a very elegant and smooth look.
- Heat resistance. 317L alloy doesn’t respond to heat treating.
- Performing conventional hot working methods is possible. However, the right measurements should be followed. 317L shouldn’t be heated below 1700° To ensure corrosion is resisted, annealing is advised.
- Heat treatment does not harden this SS
- Cold working is possible
Mechanical Properties
371L SS comes with 595 MPa tensile strength, 260 mpa yield strength, with 200 GPa modulus of elasticity. Other properties include 55% elongation and 217 Brinell hardness.
Due to the mechanical properties of this stainless steel, it is able to hold pressure on a high level.
What is 317L Stainless Steel Designation Equivalent?
When it comes to choosing stainless steel grade 317L, at times you may encounter these name variations:
- AISI 317L
- ASTM A167
- ASTM A182
- ASTM A213
What Are The Different Forms of 317L Stainless Steel?
After stainless steel manufacturing process, there are usually sold in different forms. Even the 317L grade stainless steel is not exempted from this classification. The most common available forms include:
- Plates
- Tubes
- Sheet
- Pipe
- Tube
- Bar
- Rolls
317L Stainless Steel Applications
The stainless steel composition makes it suitable for many applications in various industries. From industrial to domestic applications, this stainless steel grade finds use in:
- Paper industry
- Beverage and food industry
- Perfect for fossil fuel plant desulfurization.
- Used in textiles industry
- Die making industry
- Power generation plans in condenser systems
- Petrochemical processing.
- Used for chemical processing.
