317L Stainless Steel Coil, SS 317L Coil, 317L Steel Coil, Cold Rolled &Hot Rolled 317L Steel Coil
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL POSCO |
| Certification | ISO |
| Model Number | 201 304 309S 310S 316L 317L 321 347 410 420 430.etc |
| Minimum Order Quantity | 2 Ton |
| Price | 2200 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Coil | Material | Stainless Steel |
|---|---|---|---|
| Thickness | 0.1 - 16.0mm | Width | 1000mm 1219mm 1500mm |
| Surface | 2B NO.1 NO.4 8K | Grade | 201 304 309S 310S 316L 317L 321 347 410 420 430 436 439 441 444.etc |
| Standard | ASTM EN GB JIS | Service | Cutting |
| Highlight | 317L Stainless Steel Coil,317L Cold Rolled Stainless Steel Coil,317L Hot Rolled Stainless Steel Coil |
||
Product Description
317L Stainless Steel Coil, SS 317L Coil, 317L Steel Coil, Cold Rolled &Hot Rolled 317L Steel Coil
|
Product Name
|
Stainless steel coil
|
|
Finish
|
2B, 2D, 4B, BA, HL, MIRROR, Brush, NO. 1-NO. 4, 8K, and so on
|
|
Width
|
800mm-3000mm
|
|
Length
|
1000mm-11000mm or as customer' s requirement
|
|
Standard
|
Mainly 201, 202, 304, 304L, 304H, 316, 316L,316Ti,2205, 330, 630, 660, 409L, 321, 310S, 410, 416, 410S, 430, 347H, 2Cr13, 3Cr13 etc
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347 200series:201,202,202cu,204 400series:409,409L,410,420,430,431,439,440,441,444 Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304 Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo |
|
Package
|
clients' requirement and Standard export sea-worthy packing
|
|
Delivery time
|
3-15 days subject to the clients' requirement and quantity
|
|
Application
|
Escalator, Elevator, Doors; Furniture; Production tools, Kitchen appliances, freezers, cold rooms; Auto Parts; Machinery and Packaging; Equipment and Medical devices; Transport system
|
317L Stainless Steel Coils Definition
Grade Alloy 317L is a molybdenum containing, low carbon austenitic stainless steel with increased additions of chromium, nickel, and molybdenum for better corrosion resistance and increased resistance to chemical attack for sulfurous, acetic, formic, citric, and tartaric acids. Due to its low carbon content, 317L Stainless Steel also provides resistance to sensitization when welded and higher creep, stress to rupture, and tensile strength at elevated temperatures. It is non-magnetic in the annealed condition but may become slightly magnetic after welding.
An ISO 9001:2008 Certified Company, Savoy piping Inc., is a leading Stockholder, Supplier and Exporter of ASTM A240 317L Stainless Steel Coil. 317L Stainless Steel Coils are cut to your specifications and supplied with complete set of mill test reports. Custom length and width up to 2000 mm can be made available. Exports is Our Specialty! and we can source many hard to find grades and or non-standards sizes to meet the special requirements of our customers. All ASTM SS 317L Steel Coil can be cut to size with the help of our extensive expertise in processing steel Coil products.
Our stock of ASTM A240 317L Stainless Steel Coil includes thickness of 6mm up to 80mm with width of 1250mm, 1500mm, 2000mm.
- Order Large or Small Quantity of ASTM A240 317L Stainless Steel Coil
- Cut to Size ASTM A240 317L Stainless Steel Coil Available
- No Minimum Order Quantity for ASTM A240 317L Stainless Steel Coil
317L Stainless Steel Coil Chemical Compostion and Properties
The chemical composition of grade 317L Stainless Steel is outlined in the following table
| % | Cr | Ni | C | Si | Mn | P | S | Mo | Fe |
|---|---|---|---|---|---|---|---|---|---|
| 317L | min: 18.0 max:20.0 |
min: 11.0 max: 15.0 |
0.035 max |
0.75 max |
2.0 max |
0.04 max |
0.03 max |
min: 3 max: 4 |
balance |
317L Stainless Steel Coil Mechanical and Physical Properties
The mechanical properties of grade 317L Stainless Steel Coils are displayed in the following table.
| Grade | Tensile Strength ksi (min.) |
Yield Strength 0.2% Offset ksi (min.) |
Elongation - % in 50 mm (min.) |
Hardness (Brinell) MAX |
Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 317L | 75 | 30 | 40 | 217 | 95 |
317L STAINLESS STEEL COILS PHYSICAL PROPERTIES
Physical properties of 317L grade stainless steel in the annealed condition
| Denstiy lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Electrical Resistivity mW-in | Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | ||
|---|---|---|---|---|---|---|
| at 68 °F | at 77 – 212°F | at 77 – 932°F | at 77 – 1832°F | at 68 – 1832°F | at 32 – 212°F | |
| 0.29 | 9.2 | 10.1 | 10.8 | 31.1 | 14.6 | 0.11 |
317L Stainless Steel Coil Available Other Grade
| EN-standard Steel no. k.h.s DIN |
EN-standard Steel name |
SAE grade | UNS |
| 1.4109 | X65CrMo14 | 440A | S44002 |
| 1.4112 | X90CrMoV18 | 440B | S44003 |
| 1.4125 | X105CrMo17 | 440C | S44004 |
| 440F | S44020 | ||
| 1.4016 | X6Cr17 | 430 | S43000 |
| 1.4408 | G-X 6 CrNiMo 18-10 | 316 | S31600 |
| 1.4512 | X6CrTi12 | 409 | S40900 |
| 410 | S41000 | ||
| 1.4310 | X10CrNi18-8 | 301 | S30100 |
| 1.4318 | X2CrNiN18-7 | 301LN | |
| 1.4307 | X2CrNi18-9 | 304L | S3043 |
| 1.4306 | X2CrNi19-11 | 304L | S30403 |
| 1.4311 | X2CrNiN18-10 | 304LN | S30453 |
| 1.4301 | X5CrNi18-10 | 304 | S30400 |
| 1.4948 | X6CrNi18-11 | 304H | S30409 |
| 1.4303 | X5CrNi18-12 | 305 | S30500 |
| X5CrNi30-9 | 312 | ||
| 1.4841 | X22CrNi2520 | 310 | S31000 |
| 1.4845 | X 5 CrNi 2520 | 310S | S31008 |
| 1.4541 | X6CrNiTi18-10 | 321 | S32100 |
| 1.4878 | X12CrNiTi18-9 | 321H | S32109 |
| 1.4404 | X2CrNiMo17-12-2 | 316L | S31603 |
| 1.4401 | X5CrNiMo17-12-2 | 316 | S31600 |
| 1.4406 | X2CrNiMoN17-12-2 | 316LN | S31653 |
| 1.4432 | X2CrNiMo17-12-3 | 316L | S31603 |
| 1.4435 | X2CrNiMo18-14-3 | 316L | S31603 |
| 1.4436 | X3CrNiMo17-13-3 | 316 | S31600 |
| 1.4571 | X6CrNiMoTi17-12-2 | 316Ti | S31635 |
| 1.4429 | X2CrNiMoN17-13-3 | 316LN | S31653 |
| 1.4438 | X2CrNiMo18-15-4 | 317L | S31703 |
| 1.4362 | X2CrNi23-4 | 2304 | S32304 |
| 1.4462 | X2CrNiMoN22-5-3 | 2205 | S31803/S32205 |
| 1.4501 | X2CrNiMoCuWN25-7-4 | J405 | S32760 |
| 1.4539 | X1NiCrMoCu25-20-5 | 904L | N08904 |
| 1.4529 | X1NiCrMoCuN25-20-7 | N08926 | |
| 1.4547 | X1CrNiMoCuN20-18-7 | 254SMO | S31254 |
317L Stainless Steel Coil is in Ready Stock and Ready to Deliver. High Quality, Lower Cost But Best Service in Steel Coils
317L Stainless Steel Coil Application
- Automotive
- Railway & Transport
- Architecture, Building & Construction
- Chemical & Petrochemical Industries
- Pharmaceutical
- Energy and Power
- Oil and Gas Industries
- Kitchenware and Food Processing Industries
- Plumbing And Overhead Water Tanks
FAQ
Q1: What are your terms of payment?
A1: We accept TT, L/C and west union or you can pay through Alibaba. 30%T/T as the upfront deposit, 70% before delivery, We will show you the photos and package before you pay the balance.
Q2: Do you have after-sales service?
A2: Our quality and service is our life, so even after your buying, we still offer free after sale service.
A2: Our quality and service is our life, so even after your buying, we still offer free after sale service.
A3:If you have your own design , we can produce according to your specification and drawing
Q4:Reasonable price
A4:fter clients receive the quotation , we will show you rationality of the price
Q5:Design
A5:Customers’ design is acceptable
Q6: What's the terms of delivery?
A6: EXW, FOB, CFR, CIF
A6: EXW, FOB, CFR, CIF
Q7: What's the terms of packing?
A7: Generally,we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q8: What's your delivery time?
A8: For stocks, we could transport the goods to loading port within 7 work days after we received the deposit.For productionperiod,it usually takes about 15 days to 30 days after we received the deposit.
