Alloy 304H Stainless Steel Plate AISI304H / UNS S30409 SS Plate Custom Cutting
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304H |
| Minimum Order Quantity | 400 kgs |
| Price | 2200 -3220 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plates | Grade | 304H |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.6- 40.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 200 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | AISI304H Stainless Steel Plate,Custom Cutting Stainless Steel Plate,S30409 Stainless Steel Plate |
||
Product Description
Alloy 304H Stainless Steel Plate AISI304H / UNS S30409 SS Plate Custom Cutting
More Informations of our Products
|
Product
|
Stainless Steel Sheet/Plate
|
|
Standard
|
ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc
|
|
Material
|
310S,310,310H,309,309S,316,316L,316Ti,317,317L,321,321H,347,347H,304,304L,302,301,
201,202,403,405,409,409L,410,410S,420,430,631,904L,Duplex,etc
|
|
Surface
|
2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror,checkered,embossed,hair line,sand blast,Brush
|
|
Thickness
|
Cold Rolled:0.3-6mm
|
|
Hot Rolled: 3-20mm
|
|
|
Width
|
1000mm,1219mm,1500mm,1800mm,2000mm,2500mm,,etc
|
|
Length
|
2000mm,2440mm,3000mm,5800mm,6000mm,etc
|
|
Package
|
Covered with a layer of plastic film and cardboard,packed on the wooden pallets/ iron packing,bound with iron belt,loaded in the containers.
|
|
Price Terms
|
Ex-Work,FOB,CFR,CIF,FCA,etc
|
|
Payment Terms
|
TT,L/C at sight ,western Union,etc.
|
Alloy 304/304H (UNS S30400/ S30409) is a modification of the most widely utilized "18-8" chromium-nickel austenitic stainless steel. The carbon content is controlled in the range of 0.04-0.10% for increased strength at temperatures above 800°F (427°C). It is an economical and versatile corrosion resistant alloy suitable for a wide range of general purpose applications.
It is common practice for 304H to be dual certified as 304 and 304H. The high carbon chemistry of 304H enables 304 to meet the mechanical properties and grain size requirements of 304H.
Alloy 304/304H has general corrosion resistance similar to 304/304L. It resists atmospheric corrosion, as well as, moderately oxidizing and reducing environments. However, because of its high carbon content, Alloy 304/304H is subject to carbide precipitation in the heat affected zone of welds.
Alloy 304/304H is non-magnetic in the annealed condition, but can become slightly magnetic as a result of cold working or welding. It can be easily welded and processed by standard shop fabrication practices.
Chemical Analysis
Weight % (all values are maximum unless a range is otherwise indicated)
| Element | 304 | 304H |
|---|---|---|
| Chromium | 18.0 min.-20.0 max. | 18.0 min.-20.0 max. |
| Nickel | 8.0 min.-10.5 max. | 8.0 min.-10.5 max. |
| Carbon | 0.08 | 0.04 min-0.10 max. |
| Manganese | 2.00 | 2.00 |
| Phosphorus | 0.045 | 0.045 |
| Sulfer | 0.030 | 0.030 |
| Silicon | 0.75 | 0.75 |
| Nitrogen | 0.10 | 0.10 |
| Iron | Balance | Balance |
Our 304H Stainless Steel Products and Size Range
| Type | Sizes | Schedules | ASTM Standards |
|---|---|---|---|
| Bar | A276, A479 | ||
| Butt Weld Fittings | 1/2″ thru 12″ | Sch 10, 40, 80, 160 & XXH | A403 |
| Forgings | 1/2″ thru 8″ | A182 | |
| Pipe Welded & Seamless | 1/4″ thru 16″ | Sch 10, 40, 80, 160 & XXH | A312 |
| Tube, Welded | A249 | ||
| Tube, Seamless | A213 | ||
| Plate | A240 | ||
| Flange & Pressure Fittings | All Descriptions |
