AISI1050 Steel Strip / Cold Rolled Steel Coil 50# Carbon Steel Band
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | SK5 SK4 SK2 65Mn 45Mn 40Mn 15CrMo 20Cr 40 Cr 10# 20# 35# 45# 50# 60# CK75 SPHC SPCC Q195-355 ST12 ST14 .etc |
| Minimum Order Quantity | 4 Ton |
| Price | 625-870 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Spring Steel Strip | Thickness | 0.3 - 3.0mm |
|---|---|---|---|
| Width | 1000mm 1250mm Or As Request | Surface | Regular Spangle, Zero Spangle |
| Packing | Wooden Pallets And Waterproof Paper | Brand | BAOSTEEL ANSTEEL |
| Service | Cutting | Coil ID | 508mm |
| Highlight | 50# Carbon Band Steel Strip,Cold Rolled Steel Strip,AISI 1050 carbon steel band |
||
Product Description
AISI1050 Steel Strip / Cold Rolled Steel Coil 50# Carbon Steel Band
Specification of our products
|
Product Name
|
Cold rolled steel strip
|
|
Thickness
|
0.12-4mm
|
|
Coil Weight
|
3-8 ton, or as your requirement
|
|
width
|
6-700mm, or as your requirement
|
|
Tolerance
|
Thickness: +/-0.02mm, Width:+/-2mm
|
|
Material grade
|
65MN
S50C, C50, CK50, CK50E, SAE 1050 S75C, C75, CK75, CK75E, SAE1075 S60C, C60, CK60, CK60E, SAE1060 S45C, C45, CK45, CK45E, SAE1045 S55C, C55, CK55, CK55E, SAE1055 SK4, SK5, SK85,51CrV4, 75Cr1 60Si2Mn, 55Si2Mn, 62Si2Mn, SUP 6,etc |
|
surface
|
iron gray (low carbon plate), brown (special alloy plate, the high carbon plate), partial ochre (weather resistance), with temperature oxidation pattern, than manufacture rough surface
|
|
Standard
|
ASTM,DIN,JIS,BS,GB/T
|
|
Payment terms
|
30% T/T deposit in advance, 70% T/T balance within 5 days after B/L copy, 100% Irrevocable L/C at sight, 100% Irrevocable L/C
after receive B/L 30-120 days, etc |
|
Delivery times
|
Delivered within 7 days after the receipt of deposit
|
|
Package
|
tied up with steel strips and wrapped with water proof paper
|
|
Application Range
|
Widely used in ship, automobile, Bridges, buildings, machinery, pressure vessels and other manufacturing industries
|
|
Advantages
|
1. Reasonable price with excellent quality
2. Abundant stock and prompt delivery 3. Rich supply and export experience, sincere service |
|
Certificates
|
CE, ISO9001-2008,ETC.
|
ASTM A684 1050 Cold Rolled High Carbon Steel Strip
We stock a large range of carbon steels which can be slit to the customers requirement. We also have a wide range of excess offcuts which may be of interest.
High Carbon Steel Strip can be produced to a large variety of tensile strengths/hardnesses to suit the subsequent component-manufacturing processes and end-uses involved. The softened/annealed condition provides maximum deformability for more complex component shapes or, alternatively, lower relative wear on component-forming tools. In this condition hardnesses of 160 - 200 VPN (equivalent to tensile strength up to about 690 N/mm²) would be typical.
Dimension
Thickness: 0.01-6mm
Tolerances on thickness: +/-0.015 - 0.030mm
Tolerances on width: +/- 0.10 - 0.30 mm
Tolerances on length of cut-to-Iength: -0/+10-30mm
Chemical Composition
| Steel Designation No. | Carbon | Manganese | Phosphorus, max | Sulfur, max |
| 1050 | 0.48 to 0.55 | 0.60 to 0.90 | 0.030 | 0.035 |
Silicon composition as one of the following:
Type 1: 0.15-0.30
Type 2: 0.10 max
Manufacture
Condition:
1 The strip shall be furnished cold rolled spheroidized annealed, soft annealed, intermediate hardness, or full hard, as specified.
2 Intermediate hardness may be obtained by either rolling the strip after final annealing or by varying the annealing treatment, or both.
3 Pinch Pass一Spheroidized annealed and annealed ma terial may be pinch rolled after the final anneal to improve flatness, uniformly oil, modify surface, obtain proper mechani cal properties, and minimize stretcher strains if required by the purchaser.
Heat Treatment
1 Soft spheroidized annealed high-carbon steel is in tended for applications requiring maximum cold forming. It is normally produced to give the lowest maximum Rockwell hardness for each grade.
2 Soft annealed high-carbon steel is intended for appli cations requiring moderate cold forming. It is produced to a maximum Rockwell hardness.
3 Intermediate hardness high-carbon steel is intended for applications where cold forming is slight or a stiff, springy product is needed, or both. It is produced to specified Rockwell hardness ranges, the maximum being higher than obtained for the annealed type.
4 Full hard high-carbon steel is intended for flat appli cations. It is produced to minimum Rockwell hardness requirements, which vary with grade, microstructure and gauge. Full hard can be produced with either a pearlitic or spheroidized microstructure or a mixture of both. The mini mum hardness should be established between the consumer and the producer.
Surface Finish
Surface—The strip shall be furnished with a No. 2 Regular Bright or No. 1 Matte (Dull) finish, as specified.
Oiling—The strip shall be furnished oiled or dry, as specified.
Description
AISI 1050 is a high-carbon, cold rolled steel containing approximately 0.50% carbon that can be hardened by heat treatment to a maximum hardness of approximately Rockwell C 58. Soft annealed high carbon steel is intended for applications requiring moderate forming, while soft spheroidized annealed product is intended for applications requiring maximum cold forming.
The soft spheroidized annealed product is processed to give the lowest hardness for maximum formability. This grade of steel is used for the manufacture of blades, brackets, brake discs, clips, clutches, springs, washers and gears and for a wide range of applications that can make use of its good combination of mechanical properties.
Application
Steel grade 1050 is widely used for the manufacture of forged shafts and gears, axles, bandages, shares, screws, sickles, knives, axes, hammers, unloaded springs and springs.
Other Services
1 Cutting: Small pieces
2 CNC Machine: Produce as your drawing
3 Package: Bare/Nylon/Canvas/Wooden
4 Payment:T/T, L/C, O/A(request credit)
5 Transport:FOB/CFR/CIF/DDU/DDP (train/ship/Air)
