Alloy 28 / UNS N08028 / EN 1.4563 Stainless Steel Plates / SS Plate Specification

Place of Origin	China
Brand Name	DELTA
Certification	ISO
Model Number	EN 1.4529 / 926
Minimum Order Quantity	500 kgs
Price	7.8-8.7 USD/Kg
Packaging Details	wooden pallets + waterproof paper
Delivery Time	5 - 12 days based on the quantity
Payment Terms	L/C, T/T, Western Union
Supply Ability	10 Ton per week

Product Details

Products	Stainless Steel Plates&Sheets	Grade	Alloy 28 / UNS N08028 / EN 1.4563
Standard Size	10002000mm 12192438mm 1500*6000mm	Thickness	0.4- 40.0mm
Brand	TISCO BAOSTEEL POSCO LISCO	Loading Port	Shanghai Port
MOQ	300 Kgs	Packing	Wooden Pallets + Waterproof Paper
Highlight	stainless steel flat plate , stainless flat plate , stainless flat sheet

Leave a Message

Product Description

Alloy 28 / UNS N08028 / EN 1.4563 Stainless Steel Plates / SS Plate Specification

Quick Informations

Products Name	1.4563 Stainless Steel Plate	Standard	ASTM EN DIN JIS GB
Thickness	0.4 - 50.0mm	Surface	2B NO.1 BA NO.4 8K
Standard Size	10002000mm 12192438mm 1500*6000mm	Service	Cutting, surface processing

More Informations of our Products

Item	Stainless Steel Plates / Stainless Steel Sheets
Main Grades	201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc.
Thickness	0.4mm-40mm
Stock Thickness	0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm
Width	1000mm 1219mm 1500mm or cutting any size as request
Standard size	10002000mm 12192438mm 15006000mm 20006000mm
Finish	2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc.
Package	wooden pallets and waterproof paper

EQUIVALENT GRADES OF 1.4563 STAINLESS STEEL

STANDARD	WERKSTOFF NR.	UNS	EN
Alloy 28	1.4563	N08028	X1NiCrMoCuN31-27-4

CHEMICAL COMPOSITION OF 1.4563 STAINLESS STEEL

Grade	C	Si	Mn	P	Cr	Mo	Ni	N
Alloy 28	0.02 max	0.70 max	2.00 max	0.03 max	26.00 – 28.00	30.00 – 32.00	19.00 – 21.00	0.11 max

MECHANICAL PROPERTIES OF EN 1.4563 STAINLESS STEEL

Element	Hardness	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
EN 1.4563	230	220	500 – 750	30 %

CORROSION RESISTANCE

EN 1.4563 has excellent resistance to strong acids, including phosphoric, hydrochloric, nitric, formic, and sulfuric acids. Its resistance to pitting and corrosion resistance makes it suitable for seawater piping and heat exchangers.

ELEVATED TEMPERATURE RESISTANCE

EN 1.4563 should not be exposed to temperatures exceeding 1100°F (593°C) for prolonged periods as this may result in embrittlement.

MECHANICAL PROPERTIES

In the annealed condition, en 1.4563 has a minimum yield strength of 32 ksi. However, it may also be provided in the cold-worked condition with yield strength exceeding 125 ksi. It maintains excellent toughness at cryogenic temperatures.

HEAT TREATMENT

EN 1.4563 cannot be strengthened by heat treating. Annealing is performed at 2000°F - 2100°F (1093°C - 1149°C), followed by rapid cooling.

WORKABILITY

EN 1.4563 can be cold formed. However, it has a moderately high work hardening rate, so intermediate anneals may be required. Annealing is also recommended subsequent to hot forming or cold forming in order to achieve optimal stress corrosion resistance.

APPLICATIONS

EN 1.4563 is used for heat exchangers in severely corrosive conditions high in chlorides, such as marine applications and oil and gas production. CRA offers specialty alloy 28 seamless pipe & tube for use in multiple industries and applications, including:
