DIN 1.4565 Stainless Steel Plate UNS S34565 Alloy 24 Stainless Steel Austenitic SS Plates
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | EN 1.4565 |
| Minimum Order Quantity | 500 kgs |
| Price | 7.5-8.1 USD/Kg |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plates&Sheets | Grade | EN 1.4565 |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.4- 40.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 300 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | stainless steel flat plate,stainless flat plate,stainless flat sheet |
||
Product Description
DIN 1.4565 Stainless Steel Plate UNS S34565 Alloy 24 Stainless Steel Austenitic SS Plates
Quick Informations
| Products Name | 1.4652 Stainless Steel Plate | Standard | EN 10088-2 |
| Thickness | 0.4 - 50.0mm | Surface | 2B NO.1 BA NO.4 8K |
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Service | Cutting, surface processing |
More Informations of our Products
| Item | Stainless Steel Plates / Stainless Steel Sheets |
| Main Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc. |
| Standard | ASTM GB JIS EN DIN BS |
| Thickness | 0.4mm-40mm |
| Stock Thickness | 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as request |
| Standard size | 1000*2000mm 1219*2438mm 1500*6000mm 2000*6000mm |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | wooden pallets and waterproof paper |
EN1.4565 / UNS S34565 Stainless Steel
EN 1.4565 stainless steel is a superaustenitic (highly alloyed) stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the annealed condition. EN 1.4565 is the UNS number for this material. Alloy 24 is the common industry name.
It has a very low base cost among wrought superaustenitic stainless steels. In addition, it has a very high tensile strength and a very low embodied energy.
The graph bars on the material properties cards below compare EN 1.4565 stainless steel to: wrought superaustenitic stainless steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
| Material Designation | EN 1.4565 |
| Alloy | Alloy 24 |
| EN Name | X2CrNiMnMoNbN25-18- 5-4 |
| UNS | S34565 |
| Brand Names | 4565 S/ P512 |
| Standards | EN 10088-2/ ASTM S240/ SEW 400 |
| VdTÜV | 509 |
Main fields of application of 1.4565
Alloy 24 is a nitrogen and molybdenum alloyed austenitic stainless steel, resistant to intergranular corrosion and excellent resistance to pitting, crevice corrosion and stress corrosion cracking in sea water and other corrosive media.
Fields of application are:
- Chemical Process Industry (CPI)
- Flue gas desulphurisation (FGD) in power plants as well as on large sea going vessels
- Seawater desalination and other seawater applications
- Food industry
- Pharmaceutical industry
- Heat exchangers
Chemical composition of EN 1.4565 Stainless Steel
| Ni % | Cr % | Mn % | Mo % | N % | C % | Fe |
| 17 | 24 | 5.5 | 4.5 | 0.45 | 0-0,2 | Rest |
Characteristics of 1.4565 Stainless Steel
| Temperature-range | Wet corrosion material up to ~400°C |
| ISO-V charpy | 120J (longitudinal))/ 90J (transverse) >10mm material at RT |
| Elongation Rp0,2 | 420N/mm² (240N/mm² bei 400°C) |
| Tensile Rm | 800N/mm² |
| Extension 100°C to 20°C | 14,5 |
Some properties of EN 1.4565 Stainless Steel
- Very good general corrosion properties
- Very high resistance to localized corrosion such as pitting and crevice corrosion
- Very good resistance to different types of stress corrosion cracking
- Very good mechanical properties
- Very good weldability
- Very good formability
- Many active references
- Acc VDTÜV Werkstoffblatt applicable for pressure applications in a temperature range of -196-400 ° C
- Very good resistance in seawater applications and other applications of acids and alkalis
- Described in the standard for German swimming pool construction and tunnel applications Z-30.3-6 in the resistance class IV (5 / severe)
- Use in flue gas desulfurization in power plants and vessel FGD
- Substitute for various alloys such as Duplex, Alloy 31 or nickel alloys with many advantages
Processing of 1.4565 Stainless Steel
- Forging temperature at about 1150-950 ° C with cooling on air.
- Solution annealing 1170-1120 ° C with cooling in water.
- Comparison of the critical pitting and crevice corrosion temperature with the PREn number
