X1CrNiMoCuN24-22-8 / EN 1.4652 Stainless Steel Plate / Sheets / Coils Thickness 0.4 - 50.0mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | EN 1.4652 |
| Minimum Order Quantity | 200 kgs |
| Price | 6520 - 7840USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plates&Sheets | Grade | EN 1.4652 |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.4- 50.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 300 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | stainless steel flat plate,stainless flat plate,stainless flat sheet |
||
Product Description
X1CrNiMoCuN24-22-8 / EN 1.4652 Stainless Steel Plate / Sheets / Coils Thickness 0.4 - 50.0mm
Quick Informations
| Products Name | 1.4652 Stainless Steel Plate | Standard | EN 10088-2 |
| Thickness | 0.4 - 50.0mm | Surface | 2B NO.1 BA NO.4 8K |
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Service | Cutting, surface processing |
More Informations of our Products
| Item | Stainless Steel Plates / Stainless Steel Sheets |
| Main Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc. |
| Standard | ASTM GB JIS EN DIN BS |
| Thickness | 0.4mm-40mm |
| Stock Thickness | 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as request |
| Standard size | 1000*2000mm 1219*2438mm 1500*6000mm 2000*6000mm |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | wooden pallets and waterproof paper |
UNS S32654 Stainless Steel
Equivalent Grades: UNS S32654 (Alloy 654), EN 1.4652, ASTM UNS S32654, X1CrNiMoCuN24-22-8, 654 SMO
UNS S32654 (1.4652, 654SMO) is a type of special stainless steel containing a high percentage of Nickel and Chromium, containing 7% molybdenum, and very high Nitrogen, High mechanical strength. 654SMO (1.4652, UNS S32654) is stainless steel with the highest corrosion resistance in the world. It has a fairly high electrical conductivity among wrought super austenitic stainless steel. In addition, it has a fairly low thermal conductivity and moderately high ductility.
Useful for e.g. pressurized and erosive systems handling chlorinated seawater at higher temperatures, plate heat exchangers, and flue gas cleaning applications.
UNS S32654 Chemical Composition:
| C | N | Cr | Ni | Mo | Cu | Mn | PREN | UNS S32654 |
| 0.02 | 0.45-0.55 | 24.0-26.0 | 21.0-23.0 | 7.0-8.0 | 0.30-0.60 | 2.0-4.0 | 54 | 654 SMO |
Mechanical Properties of 1.4652 Super Austenitic Stainless Steel (654SMO)
| MECHANICAL PROPERTIES | |||
| Tensile Strength, MPa, min | Yield Strength, MPa, min | Elongation (%), min | Hardness, max |
| 750 | 430 | 40 | 250 HB |
Features of 1.4652 Super Austenitic Stainless Steel (UNS S32654)
- Non-magnetic
- Excellent resistance to localized corrosion
- Excellent resistance to pitting
- Excellent resistance to stress corrosion
- Good heat resistance
- Good tensile strength
- Good plasticity
- Good toughness
Equivalent Grades of 1.4652 Super Austenitic Stainless Steel (UNS S32654)
| ASTM | UNS | WERKSTOFF NR. | GB | EN |
| 654SMO | S32654 | 1.4652 | 00Cr24Ni22Mo7Mn3CuN | X1CrNiMoCuN24-22-8 |
Typical applications of 1.4652 Stainless Steel
- Pressurized and erosive systems handling chlorinated seawater at higher temperatures
- Plate heat exchangers
- Flue gas cleaning
- Process equipment in the chemical industry
- Bleaching equipment in the pulp and paper industry
- Desalination
- Hydrometallurgy
- Food and beverage
- Pharmaceuticals
