TISCO 445 Stainless Steel Sheets ASTM EN DIN Standard UNS S44500 / EN 1.4621 SS Sheets
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 445 |
| Minimum Order Quantity | 500 kgs |
| Price | 1220 - 1410 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | Stainless Steel 445 |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm |
| Thickness | 0.5 - 3.0mm | Type | Cold Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | rolled sheet metal,400 series stainless plate,thin ss plate |
||
Product Description
TISCO 445 Stainless Steel Sheets ASTM EN DIN Standard UNS S44500 / EN 1.4621 SS Sheets
Products Specification
| Products Name | 445 Stainless Steel Sheet |
| Standard | ASTM EN JIS GB BIS |
| Thickness |
0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm |
| Surface | 2B 2D NO.1 or process other surface as request |
| Standard Size | 1219*2438mm 1000*2000mm |
| Service | Slit Cutting, bending , surface treatment |
| Other Grade | 200 Series: 201 202 |
| 300 Series: 301 304 304L 309S 310S 316L 316Ti 317l 321 329 347 | |
| 400 Series: 409L 410S 416 420 431 436L 439 441 443 444 446 | |
| Special Grade: 254SMO 904L 2205 2507 253MA Nickel Alloy | |
| MOQ | 500 kgs |
| Packing | Wooden Pallets and waterproof paper |
Introduction
Stainless steel grade 445 is one of the most widely used precipitation hardening grade steels. Although this material is soft and ductile in the solution annealed condition, it is very capable of good properties with a single precipitation or aging treatment. This steel possesses good corrosion resistance, high harness, toughness and strength.
The following datasheet provides an overview of stainless steel grade 445.
AISI 445 stainless steel is a ferritic stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the annealed condition. 445 is the AISI designation for this material. S44500 is the UNS number.
It has a moderately high ductility among the wrought ferritic stainless steels in the database.
The graph bars on the material properties cards below compare AISI 445 stainless steel to: wrought ferritic stainless steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
Chemical Composition of 445 Stainless Steel
The chemical composition of grade 445 stainless steel is outlined in the following table.
| Grade | C | Si | Mn | P | S | Cr | Ni | Fe |
| 445 | 0.02 | 1.00 | 1.00 | 0.04 | 0.012 | 19.0-21.0 | 0.60 | Bal |
Mechanical Properties of 445 Stainless Steel
The mechanical properties of grade 445 stainless steel are displayed in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 427 MPa | 61931 psi |
| Yield strength | 205 MPa | 29732 psi |
| Modulus of elasticity | 190-210 GPa | 27557- 30457 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break | 22% | 22% |
| Hardness | 83 | 83 |
Manufacturing Process
The 445 stainless steel grade can be machined into long gummy chips. For heat treatment of this material, it must be soaked at 1038°C (1900°F) for 30 min and then cooled below 16°C (60°F) for complete martensite transformation. Common fusion and resistance methods can be used to weld grade 445 steel. Oxyacetylene welding should be avoided. AWS E/ER630 filler metal is recommended. The material has to be soaked for 1 h at 1177°C (2150°F) for performing forging. The material should not be worked below 1010°C (1850°F). Before final hardening, post-work solution treatment is required.
