DIN 1.6523 Structure Alloy Steel Bars SAE8620 Round Rod 20NCD2 Alloy
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | SAE8620/1.6523 |
| Minimum Order Quantity | 1 Ton |
| Price | 612-884USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Alloy Steel Round Bar | Diameter | 10 - 350mm |
|---|---|---|---|
| Length | 6m | Tech | Hot Rolled |
| Service | Cutting | MOQ | 1 Ton |
| Loading Port | Shanghai Port | Standard | ASTM EN GB |
| Highlight | din steel round bar,hot rolled steel round bar,hot rolled mild steel round bar |
||
Product Description
DIN 1.6523 Structure Alloy Steel Bars SAE8620 Round Rod 20NCD2 Alloy
Products Specification
| Products Name |
SEA8620 / 1.6523 Alloy Steel Round Bar |
| Diameter | 10 - 320mm |
| Length | 6m or custom cutting any length as request |
| Type | Hot Rolled |
| Brand | BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc |
| MOQ | 1 Ton |
| Loading Port | Shanghai Port |
| Packing | packing by steel wire rope |
| Deliver time | 5 - 7 days for stock materials |
| Other Grade |
Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov, 15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo, 40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo |
| Standard | ASTM GB EN DIN |
| Application | Structure and Industrial |
Regular Standard Size of our SAE8620 Round Bar in Stock
| Standard Diameter | 10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300 |
Other Alloy Steel Round Bar We Can Supply:
40CrNiMoA,4340,40CrNi2Mo,34CrNiMo6,17CrNiMo6,20CrNiMoA,8620H,35CrMo,Ⅴ40,20CrMnMo,20MnCr5,30CrNiMo8,18CrNiMo7
What is 1.6523 (AISI 8620, 20NiCrMo2) Steel Material?
1.6523 (AISI 8620, 20NiCrMo2) is an alloy steel type that is commonly used in applications that require high hardness, durability, and strength properties.
1.6523 (AISI 8620, 20NiCrMo2) steel contains elements such as nickel, chromium, molybdenum, manganese, carbon, and iron. When processed to have a hardened core, this steel provides high strength and impact resistance. Additionally, it is suitable for surface-hardening processes.
1.6523 (AISI 8620, 20NiCrMo2) steel is popular due to its high strength and durability properties. However, there are also some disadvantages to this steel. For instance, difficulties in welding processes can occur, and oxidation might take place at high temperatures. Therefore, proper application and processing are essential.
What is the Hardness Value of 1.6523 (AISI 8620, 20NiCrMo2) Steel?
The surface hardness and hardness depth of 1.6523 (AISI 8620, 20NiCrMo2) steel can be adjusted through case hardening.
What are the Mechanical Properties of 1.6523 (AISI 8620, 20NiCrMo2) Steel?
You can find the material properties of 1.6523 (AISI 8620, 20NiCrMo2) in the "Technical Details" tab. All mechanical and material properties of 1.6523 (AISI 8620, 20NiCrMo2) steel are specified within this tab.
Where is 1.6523 (AISI 8620, 20NiCrMo2) Steel Used?
1.6523 (AISI 8620, 20NiCrMo2) steel is used in various industries. For example, gears, transmissions, shafts, axles, traction control components, and many other parts used in industries like automotive, aviation, agriculture, mining, energy, and construction are made from this steel type.
What is the Price of 1.6523 (AISI 8620, 20NiCrMo2) Material?
The price of 1.6523 (AISI 8620, 20NiCrMo2) material varies depending on the product section, dimensions, and surface quality. You can access 1.6523 (AISI 8620, 20NiCrMo2) steel prices
Chemical Component and Material Code:
1.6523, AISI 8620, 20NiCrMo2
Carbon |
Manganese |
Molybdenum |
Silicon |
Phosphorus |
Sulfur |
Chromium |
Nickel |
0,17 - 0,23 |
0,65 - 0,95 |
0,15 - 0,25 |
Max 0,40 |
Max 0,025 |
Max 0,035 |
0,35 - 0,70 |
0,40 - 0,70 |
Mechanical Properties
Hardness |
24-34 |
HRC |
Tensile Strength |
530 |
MPa |
Yield Strength |
385 |
MPa |
Elongation L=5D |
18 |
% |
Physical Properties
Coefficient of Thermal Expansion |
6,6 |
1/K * 10-6 |
Thermal Conductivity (20°C) |
46.6 |
W/mK |
Density |
7.85 |
g/cm3 |
