SAE8620/SAE8620H/20CrNiMo Alloy Steel Bar Structure Application Alloy Steel Rod
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | SAE8620/SAE8620H/20CrNiMo |
| Minimum Order Quantity | 1 Ton |
| Price | 612-884USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Alloy Steel Round Bar | Diameter | 10 - 350mm |
|---|---|---|---|
| Length | 6m | Tech | Hot Rolled |
| Service | Cutting | MOQ | 1 Ton |
| Loading Port | Shanghai Port | Standard | ASTM EN GB |
| Highlight | din steel round bar,hot rolled steel round bar,hot rolled mild steel round bar |
||
Product Description
SAE8620/SAE8620H/20CrNiMo Alloy Steel Bar Structure Application Alloy Steel Rod
Products Specification
| Products Name |
SEA8620 / 20CrNiMo Alloy Steel Round Bar |
| Diameter | 10 - 320mm |
| Length | 6m or custom cutting any length as request |
| Type | Hot Rolled |
| Brand | BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc |
| MOQ | 1 Ton |
| Loading Port | Shanghai Port |
| Packing | packing by steel wire rope |
| Deliver time | 5 - 7 days for stock materials |
| Other Grade |
Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov, 15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo, 40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo |
| Standard | ASTM GB EN DIN |
| Application | Structure and Industrial |
Regular Standard Size of our SAE8620 Round Bar in Stock
| Standard Diameter | 10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300 |
Other Alloy Steel Round Bar We Can Supply:
40CrNiMoA,4340,40CrNi2Mo,34CrNiMo6,17CrNiMo6,20CrNiMoA,8620H,35CrMo,Ⅴ40,20CrMnMo,20MnCr5,30CrNiMo8,18CrNiMo7
AISI SAE 8620 Steel (UNS G86200)
AISI SAE 8620 steel is a commonly used low-alloy material for carburizing, with excellent carburizing response, good hardenability for most section sizes, it has many extensive applications due to its low cost, better machinability, and availability.
Chemical Composition
AISI SAE 8620 steel chemical composition is listed in the table below.
| SAE AISI 8620 Chemical Composition, % | ||||||||||||
| Standard | Steel Grade (UNS) | C | Si | Mn | P, ≤ | S, ≤ | Cr | Ni | Mo | Cu, ≤ | O, ≤ | Al, ≤ |
| ASTM A322; ASTM A29/A29M |
8620 (UNS G86200) | 0.18-0.23 | 0.15-0.35 | 0.70-0.90 | 0.035 | 0.040 | 0.40-0.60 | 0.40-0.70 | 0.15-0.25 | – | – | – |
| ASTM A534 | 8620H | 0.17-0.23 | 0.15-0.35 | 0.60-0.95 | 0.025 | 0.015 | 0.35-0.65 | 0.35-0.75 | 0.15-0.25 | 0.3 | 0.002 | 0.05 |
Mechanical Properties
AISI SAE 8620 material mechanical properties are listed in the following tables including yield strength (yield stress), tensile strength, impact strength and hardness, etc.
Notes:
- 1 MPa = 1 N/mm2
- 1 GPa = 1 kN/mm2
| 8620 alloy steel mechanical properties | |||||||
| Steel (UNS) | Tensile strength, Mpa (ksi), ≥ | Yield strength, Mpa (ksi), ≥ | Elongation in 50 mm (2 in.), %, ≥ | Reduction in area, %, ≥ | Hardness, HB | Izod impact strength, J (ft·lbf) | Condition or treatment |
| 8620 (UNS G86200) | 633 (92) | 357 (52) | 26.3 | 59.7 | 183 | 100 (74) | Normalized at 915 °C (1675 °F) |
| 536 (78) | 385 (56) | 31.3 | 62.1 | 149 | 115 (83) | Annealed at 870 °C (1600 °F) | |
Applications
The applications of AISI SAE 8620 steel including: Differentials (automotive and off-highway), drives (industrial, tractor accessory), engines, equipment (off-highway, steel or paper mill, mining), starters. Gears, steering mechanism, gear box and transmission components for cars.
Carburized gears, pinions, shafts, differential rings, steering worms, engine crankshafts, spline shafts, chains, air drill parts, chuck jaws, oil well bit and reamer cutters, piston pins, pneumatic chucks, heavy-duty bolts, fasteners, and hand tools.
SAE AISI 8620 Equivalent Material
SAE AISI 8620 material equivalent to European EN (Germany DIN, British BSI, French NF…), ISO, Japanese JIS and Chinese GB standard (For reference).
| US | China | Japan | European Union | ISO | |||
| Standard | Grade (UNS) | Standard | Grade (UNS) | Standard | Grade | Standard | Standard |
| AISI SAE; ASTM A322; ASTM A29/A29M |
8620 (UNS G86200) | GB/T 3077 | 20CrNiMo (A50202) | JIS G4053 | SNCM220 | ||
