EN 1.7231 (G42CrMo4) Alloy Steel Round Bar Diameter 10 - 400mm Custom Cutting any Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | EN 1.7231 (G42CrMo4) |
| Minimum Order Quantity | 1 Ton |
| Price | 600-889USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Alloy Steel Round Bar | Diameter | 10 - 350mm |
|---|---|---|---|
| Length | 6m | Tech | Hot Rolled |
| Service | Cutting | MOQ | 1 Ton |
| Loading Port | Shanghai Port | Standard | ASTM EN GB |
| Highlight | din steel round bar,hot rolled steel round bar,hot rolled mild steel round bar |
||
Product Description
EN 1.7231 (G42CrMo4) Alloy Steel Round Bar Diameter 10 - 400mm Custom Cutting any Length
Products Specification
| Products Name |
EN1.7231 / G42CrMo4 Alloy Steel Round Bar |
| Diameter | 10 - 300mm |
| Length | 6m or custom cutting any length as request |
| Type | Hot Rolled |
| Brand | BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc |
| MOQ | 1 Ton |
| Loading Port | Shanghai Port |
| Packing | packing by steel wire rope |
| Deliver time | 5 - 7 days for stock materials |
| Other Grade |
Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov, 15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo, 40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo |
| Standard | ASTM GB EN DIN |
| Application | Structure and Industrial |
Regular Standard Size of our EN1.7231 / G42CrMo4 Round Bar in Stock
| Standard Diameter | 10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300 |
EN 1.7231 (G42CrMo4) Alloy Steel
EN 1.7231 steel is an alloy steel formulated for casting. 1.7231 is the EN numeric designation for this material. G42CrMo4 is the EN chemical designation.
It has a moderately low embodied energy among cast alloy steels. In addition, it can have a very low ductility and has a moderately low electrical conductivity.
The properties of EN 1.7231 steel include two common variations. This page shows summary ranges across both of them. For more specific values, follow the links immediately below. The graph bars on the material properties cards further below compare EN 1.7231 steel to: cast alloy steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on
| Grade : | G42CrMo4 |
| Number: | 1.7231 |
| Classification: | Cast steel |
| Standard: | EN 10293: 2005 Steel castings for general engineering uses |
Alloy Composition
Among cast alloy steels, the composition of EN 1.7231 steel is notable for containing comparatively high amounts of chromium (Cr) and manganese (Mn). Chromium is used to improve corrosion resistance and most mechanical properties (particularly at higher temperatures). Manganese is used to improve hardenability and surface quality.
| Iron (Fe) | 96.4 to 98.1 | |
| Chromium (Cr) | 0.8 to 1.2 | |
| Manganese (Mn) | 0.6 to 1.0 | |
| Carbon (C) | 0.38 to 0.45 | |
| Silicon (Si) | 0 to 0.6 | |
| Molybdenum (Mo) | 0.15 to 0.3 | |
| Sulfur (S) | 0 to 0.030 | |
| Phosphorus (P) | 0 to 0.025 |
All values are % weight. Ranges represent what is permitted under applicable standards.
Heat Treatment:
| Annealing | Quenching | Tempering | Normalizing | Q & T |
| √ | √ | √ | √ | √ |
Can produce 1.7231 specifications and size
- Steel grade
- Specification
- Processing range(mm)
- 1.7231
- 1.7231
- 1.7231
- 1.7231
- 1.7231
- 1.7231
- Φ1 to Φ2000
- 10 to 1000
- 0.08 to 800(T)*10 to 1500(W)*Long
- Pipe/tube/slugs/donuts/cubes/other shapes
- OD: Φ4-410; WT: 1-35 mm
- THK:0.1mm Width:1500mm
