Super Duplex S32760 Stainless Steel Plate Hot Rolled 3.0 - 40.0mm SS Plate for Chemical Area
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | UNS S32760 |
| Minimum Order Quantity | 500 kgs |
| Price | 2800 -3200 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | UNS S32760 |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.4 - 40.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | acid resisting hot rolled steel plates,2mm hot rolled stainless steel plate,3mm cold rolled stainless steel sheet |
||
Product Description
Super Duplex S32760 Stainless Steel Plate Hot Rolled 3.0 - 40.0mm SS Plate for Chemical Area
| Products | Stainless Steel Plate |
| Thickness | 0.4 - 40.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 409L 410 420 430 431 434 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
Chemical Composition of S32760 Duplex Stainless Steel
| Carbon | 0.03% max | Chromium | 24.00-26.00% |
| Manganese | 1.00% max | Nickel | 6.00-8.00% |
| Silicon | 1.00% max | Molybdenum | 3.00-4.00% |
| Phosphorous | 0.035% max | Copper | 0.50-1.00% |
| Sulphur | 0.015% max | Nitrogen | 0.20-0.30% |
| Tungsten | 0.50-1.00% |
Welding
Welding procedures are similar to those applied for conventional duplex stainless steel grades. Electric arc welding processes is suitable for UNS S32760 super duplex stainless steel, though oxyacetylene welding is not recommended due to the possibility of carbon pick up in the weld area. We recommend you contact your welding consumables supplier who should provide you full assistance and information of welding UNS S32760 super duplex.
Typical Physical Properties
| Temp ºC |
Density Kg/m³ |
Mean Coefficient of Thermal Expansion at 20-100°C |
Thermal Conductivity W.m-¹.°C |
Modulus of Elasticity GPa |
Specific Thermal Capacity J.Kg-¹.K-¹ |
|---|---|---|---|---|---|
| 20 | 7.80 | 13.0×10-6 | 15 | 200 | 500 |
Minimum Mechanical Properties*
| Tensile UTS N/mm² |
0.2% Proof Stress N/mm² min |
Elongation % min |
Hardness HB max |
Impact J |
|---|---|---|---|---|
| 730-930 | 530 | 25 | 290 | 100 |
*Minimum Mechanical Properties at room temperature (160mm dia max – solution treated)
Certification
Super duplex stainless steel grade UNS S32760 is available with BS EN 10204 3.1 mill certificate, please request when placing any orders.
Form of Supply
West Yorkshire Steel are suppliers and stockholders of round bar. Also available as UNS S32760 plasma cut super duplex stainless plate and sheet. UNS S32760 duplex stainless steel ground steel diameter bar can be supplied, providing a high quality stainless precision ground bar to your required tolerances.
- Sheet
- Plate
- Diameter
Applications of S32760 Stainless Steel Plate
UNS S32760 super duplex is used in a wide range of marine, oil and gas environments. UNS S32760 is commonly used in the mining, marine, pharmaceutical, petrochemical and chemical engineering industries. Typical applications include flanges, pumps, valves, chokes, connecters and manifolds.
