AISI430 BA Stainless Steel Strips Thickness 0.3 - 2.0mm Bright Annealing Stainless Steel Roll
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 200Series 300 Series 400 Series C276 904L,Monel 400 K500 |
| Minimum Order Quantity | 2 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.03 - 3.0mm |
|---|---|---|---|
| Width | Within 1500mm | MOQ | 1000 Kgs |
| Grade | 200 Series 300 Series 400 Series , Nickel Alloy | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | thin stainless steel strips,stainless strip,stainless steel metal strips |
||
Product Description
AISI430 BA Stainless Steel Strips Thickness 0.3 - 2.0mm Bright Annealing Stainless Steel Roll
Specification of 301 Stainless Steel Strip
| ProductName: | 301 Stainless Steel Strip |
| Standard: | ASTM,AISI,DIN,EN,GB,JIS |
| Grade: | 201,301,304,310S,316,316L,430,409,410,434.etc |
| Thickness: | 0.1mm-3.0mm |
| Width: | 15mm-1500mm,or customized |
| Edge: | Slit edge/Mill edge |
| Surface: | 2B,BA,HL,Mirror,2D,NO.1 |
| Packaging: | Standard exporter package or as your requirements |
| Origin: | China |
| Supply Ability: | 50 Tons per Month |
| Price terms: | EX-Work,FOB,CIF,CFR,CNF |
| Payment terms: | T/T,30%advanced payment before production and balance before shipment; |
| MOQ: | 2 Ton each size |
| Delivery time: | 10-15 days after receiving deposit by T/T or L/C. |
| Sample: | Samples free and express charges bear by you. |
SS 430 is a corrosion and heat resistant ferritic Chromium Steel. It can be polished to appear similar to Chromium plate. The material is magnetic in both annealed and cold rolled tempers.
The alloy can be readily blanked and formed. The material can be resistance welded, brazed, and soldered. SS 430 is resistant to atmospheric corrosion and fresh water, but it not resistant to most salts and sea water. It is resistant to scaling by oxidation up to about 1400°F.
Available Sizes:
SS 430 is available from Hamilton Precision Metals as strip product in thicknesses from 0.001” to 0.050” (0.0254 mm to 1.27 mm) in widths up to 12.0” (304.8 mm). The material conforms to ASTM A240, FED QQS 766, and UNS S43000.
Nominal Composition of 430 Stainless Steel
| SS 430 NOMINAL COMPOSITION | |
|---|---|
| Chromium | 16.3% |
| Manganese | 0.45% |
| Silicon | 0.40% |
| Nickel | 0.2% |
| Carbon | 0.04% |
| Iron | Balance |
Mechanical Properties of 430 Stainless Steel
| SS 430 MECHANICAL PROPERTIES | ||
|---|---|---|
| ANNEALED | COLD ROLLED | |
| Ultimate Tensile Strength | 75,000 PSI | 145,000 PSI |
| Yield Strength (0.2% Offset) | 45,000 PSI | 135,000 PSI |
| Elongation in 2” * | 30% | 1% |
| Modulus of Elasticity (Tension) | 29 x 106 PSI | |
| Poisson’s Ratio | 0.27 | |
*The measured elongation will be less as thickness decreases to 0.002” and less.
These values may be adjusted by control of process variables – consult HPM for desired values
Physical Properties of 430 Stainless Steel
| SS 430 PHYSICAL PROPERTIES | |
|---|---|
| Density | 0.28 lbs/cu.in. |
| Melting Point (Approx.) | 1425°C |
| Electrical Resistivity @ R.T. | 60 Microhm·cm |
| Temperature Coefficient of Resistivity (TCR) (0° to 100°C) | 10.5 x 10-6 /°C |
| Thermal Conductivity @ 100°C | 26.1 W/m·K |
| Magnetic Permeability | 800 |
| Magnetic Attraction | Yes |
430 Stainless Steel Strip Applications
430 stainless steel strip is widely used for building decoration, fuel heating parts, hot water supply systems, household appliances, banding systems, home appliance parts and hareware.
