Grade 409L SUH409L Astm Stainless Steel Sheet Thickness 0.6 - 10.0mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 202 218 304 316L 309S 310S 317L 321 347 904L 2205 2507 925 926.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet & Plate | Grade | 201 202 218 304 310S 310H 316L 317L 409L 430.etc |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.6 - 60.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | stainless plate,ss plate,custom stainless steel plates |
||
Product Description
Hot Rolled Stainless Steel Plate Grade 409L from TISCO SUH409L SS Plate Thickness 0.6 - 10.0mm
More Specification of 409L Stainless Steel Plate
| Products | Stainless Steel Plate |
| Thickness | 0.6 - 60.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 310H 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO Nitronic 60 925 926.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
Alloy 409 is a general purpose, chromium, titanium stabilized, ferritic stainless steel whose primary application is automotive exhaust systems. It contains 11% chromium which is the minimum amount for the formation of the passive surface film which gives stainless steels their corrosion resistance. It combines good elevated temperature corrosion resistance with medium strength, good formability, and overall cost. Alloy 409 resists corrosion strongly compared to carbon steel and is used as an alternative to carbon steel in mildly challenging environments where its high resistance to corrosion and high temperature oxidation gives an advantage. It is commonly used in applications where appearance is a secondary quality to mechanical properties and corrosion resistance.
Chemical Composition of 409L Stainless Steel
The typical chemical compositional ranges of grade 409 stainless steels are given below:
Table 1 - Composition ranges of grade 409 stainless steels
| Grade | C | Mn | Si | P | S | Cr | Ni | Ti | |
| 409 |
min. max. |
- 0.08 |
- 1.00 |
- 1.00 |
- 0.045 |
- 0.045 |
10.5 11.75 |
- 0.5 |
6x C 0.75 |
Mechanical Properties of 409L Stainless Steel
The table below provides the mechanical properties of grade 409 stainless steels:
Table 2 - Mechanical properties of grade 409 stainless steels
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 409 | 450 | 240 | 25 | 75 | 131 |
STANDARDS:
- ASTM/ASME: UNS S40900
- EURONORM: FeMi35Cr20Cu4Mo2
- DIN: 2.4660
APPLICATIONS of 409L Stainless Steel
Although Alloy 409 is designed principally for the automotive exhaust industry, it has been successfully used in other industrial applications as well. Some examples of applications that call for Alloy 409 include:
- Automotive exhaust systems
- Catalytic converters
- Mufflers
- Tailpipes
- Farm equipment
- Structural support and hangers
- Transformer cases
- Furnace components
- Heat exchanger tubing
