Grade 310H Stainless Plate Thickness 3.0 - 60.0mm Width 1500mm 2000mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 202 304 316L 309S 310S 321 347 904L 2205 2507.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet & Plate | Grade | 201 304 310S 310H 316L 430.etc |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.6 - 60.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | 310H stainless plate,310H ss plate,3 mm custom stainless steel plates |
||
Product Description
Grade 310H Stainless Steel Plate / SS Plate Thickness 3.0 - 60.0mm TISCO BAOSTEEL Width 1500mm 2000mm
| Products | Stainless Steel Plate |
| Thickness | 0.6 - 60.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 310H 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
Our 310H Stainless Steel Plate in Stock
| 310H Stainless Steel Plate Standard Size In Stock | ||
| 3.0*1500*6000mm | 25*1500*6000mm | 3*2000*6000mm |
| 30*1500*6000mm | 4*2000*6000mm | |
| 5.0*1500*6000mm | 35*1500*6000mm | 5*2000*6000mm |
| 6.0*1500*6000mm | 40*1500*6000mm | 6*2000*6000mm |
| 8.0*1500*6000mm | 45*1500*6000mm | 8*2000*6000mm |
| 10.0*1500*6000mm | 50*1500*6000mm | 10*2000*6000mm |
| 12.0*1500*6000mm | 55*1500*6000mm | 12*2000*6000mm |
| 14.0*1500*6000mm | 60*1500*6000mm | 14*2000*6000mm |
| 16.0*1500*6000mm | 65*1500*6000mm | 16*2000*6000mm |
| 18.0*1500*6000mm | 70*1500*6000mm | |
| 20.0*1500*6000mm | 80*1500*6000mm | |
Chemical composition of 310H Stainless Steel
| 310H Stainless Steel | Cr | Ni | Mn | Si | P | S | C |
| Element | 24-26 | 19.0-22.0 | 2.0 | 0.75 | 0.045 | 0.03 | 0.04-0.10 |
Mechanical Properties of 310H Stainless Steel
The mechanical properties of annealed grade 310H stainless steel are displayed in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 515 MPa | 74694 psi |
| Yield strength | 205 MPa | 29732 psi |
| Modulus of elasticity | 200 GPa | 29000 ksi |
| Shear modulus | 77.0 GPa | 11200 ksi |
| Poissons ratio | 0.3 | 0.3 |
| Elongation at break (in 50 mm) | 40% | 40% |
| Hardness, Rockwell B | 95 | 95 |
| Hardness, Brinell | 217 | 217 |
Applications of 310H Stainless Steel
Grade 310H stainless steel is chiefly used in the heat treatment industry, and the chemical process industry.
The following are the specific areas of applications:
- Fans
- Trays
- Baskets
- Rollers
- Burner parts
- Oven linings
- Tube hangers
- Retorts linings
- Conveyor belts
- Refractory supports
- Containers for hot concentrated acids, ammonia, and sulfur dioxide
- Used along with hot acetic and citric acid in the food processing industry.
