Austenitic Nickel-Iron-Chromium Alloy Uns N08020 Alloy 20 Stainless Steel Bar / Nickel Alloy Bar
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Alloy 20 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Bars | Grade | Alloy 20 |
|---|---|---|---|
| Diameter | 6 - 250mm | Length | 6000mm Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | austenitic nickel iron chromium alloy,6mm nickel iron chromium alloy |
||
Product Description
Austenitic nickel-iron-chromium alloy UNS N08020 Alloy 20 Stainless Steel Bar / Nickel Alloy Bar
| Form | Nickel Alloy Bars |
| Grade | Alloy 20 |
| Outer Diameter (mm) | 6mm-250mm or according to customer’s requirement |
| Length | 1meter, 3 meters and 6 meters or customer’s requirement |
| Standard | ASTM, ASME, EN, JIS, DIN, GB/T, etc |
| Process Method | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar & Rod |
| Surface Finish | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Other Grade |
Hastelloy : B2 B3 C22 C276 G30 X Incoloy: 800 800H 800HT 825 925 A286 330 Inconel: 600 601 617 625 718 725 X-750 Monel: 400 k-500 |
| Price Item | EXW FOB CFR CIF |
| Payment | 30% TT inadvance, 70% TT Balance against copy of B/L |
| Delivery Time | It depends on your bars order total quantity and stock of these mother origin materials. Usually from the start of the order to the completion of production is about 3-4 weeks |
| Quality Requirement | Mill test certificate will be offered with shipment, the third party inspection is available |
| Main Markets | Europe, North America, Middle East, Southeast Asia |
| Metal Test | High or low temperature impact test, metallographic analysis |
| Chemical Analysis | As nickel alloy C276 bars standard |
Alloy 20 / UNS N08020 / W.Nr. 2.4660
Description
Alloy 20 is a nickel-iron-chromium based, austenitic alloy with excellent corrosion resistance in chemical environments containing sulfuric acid and many other aggressive media. This alloy is stabilized with niobium to resist intergranular corrosion. Alloy 20 may provide potential cost savings when carefully compared to higher nickel-based alloys, while out performing standard stainless steels.
Industries and Applications
Alloy 20 is used in a variety of industries, including chemical processing, petrochemical and refining, marine, pharmaceutical and food processing. End use applications include storage tanks, mixing tanks, agitators, pump and valve parts, food processing equipment, fasteners and fittings. Applications are limited to a maximum temperature of 1000°F per ASME. It is also important to determine if the necessary corrosion resistance can be achieved within the given environment.
Resistance to Corrosion
Alloy 20 has very good resistance to sulfuric acid. This alloy also shows suitable resistance in phosphoric acid, nitric acid and aqueous salt solutions. Alloy 20 is an excellent option when chloride stress corrosion cracking is an issue, as it resists pitting and crevice corrosion. Caution should be taken in chloride ion containing environments because the corrosion rate can increase significantly.
Fabrication and Heat Treatment
Alloy 20 can be formed by either hot-working or cold-work using traditional methods. Hot forged material should be heated between 2100°F and 2250°F with careful temperature control insuring that the material not fall below 1800°F prior to forging. After hot working, anneal the material by heating to 1725°F and 1850°F for a minimum of 30 minutes per inch of thickness followed by water quench.
When stress relieving is desired, heat to a temperature below 1000°F followed by water quench after the desired time at temperature has been established. Annealing Alloy 20 should be between 1725°F and 1850°F for 30 minutes at temperature per inch of thickness. A lower hardness can be obtained by heating to 2100°F but his may have a negative effect on the stabilization of the alloy.
Welding Alloy 20 is commonly performed via, TIG, MIG as well as submerged arc welding (SAW) using either the matching filler metal, ER320LR for TIG and MIG and E320LR for SAW. When welding to dissimilar alloys such as 316 or higher alloys such as C276 and Alloy 22, AWS ERNiCrMo-3 can be used for TIG and MIG while using ENiCrMo-3 for SAW.
Superior Machinability & heat treated Alloy 20cb3 Threaded Bar and UNS 8020 Forged Bar
Alloy 20 Material Specification: ASTM B473/ ASME SB473 Inco 20
Grade: B473 UNS N08020 Round Bar
Form: Round, Square, Hex (A/F), Bush, Rectangle, Flat, Billet, Ingot, Forging, PSQ Bar, Wire Rod, Wire (Coil Form), Wire-mesh etc.
Size Range: 15NB to 150NB In manufacturing process: Cold drawn/ Extruded
Length: 100 mm To 3000 mm Long & Above
Diameter (Size) : Metric M6 to M48, Inches - 1/4’’ to 2’’
Tolerance : H8, H9, H10, H11, H12, H13, K9, K10, K11, K12 or as per clients’ requirements
Finish : Cold Drawn, Shot Blast & Drawn, 240 Grit Belt Polished, Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish, High Polished
Condition : Cold Drawnd Polished Cold Drawn Centreless Ground & Polished, Threading
Surface : Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline
Alloy 20 Rod Capabilities
Alloy 20 Forged Round Bars Capabilities: The maximum length for forged round bars and hex bars is 420 inches, in the ASTM B473 Alloy 20 Bars with a maximum weight of 20,000 pounds, 220 inches.
Alloy 20 Flat Bars Capabilities: The maximum length for ASTM B473 Alloy 20 flat bars is 220 inches in the ASTM B473 Alloy 20 Bars with a maximum weight of 15,000 pounds.
Alloy 20 Square Bars Capabilities: The maximum length for ASTM B473 Alloy 20 square bars is 220 inches in the ASTM B473 Alloy 20 Bars with a maximum weight of 15,000 pounds
Standard: ASTM A276, A484, A479, A580, A582, JIS G4303, JIS G4311, DIN 1654-5,DIN 17440,GB/T 1220
| Specifications | Alloy 20 Round bar | Diameter: 3mm~800mm |
|---|---|---|
| Alloy 20 Angle bar | Size: 3mm*20mm*20mm~12mm*100mm*100mm | |
| Alloy 20 Square bar | Size: 4mm*4mm~100mm*100mm | |
| Alloy 20 Flat bar | Thickness: 2mm~100mm | |
| Width: 10mm~500mm | ||
| Alloy 20 Hexagonal | Size: 2mm~100mm |
