301 Stainless Steel Plate ASTM A240 SS Plate 0.4 - 10.0mm AISI301 Stainless Sheets
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 17-4PH Stainless steel |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-6000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 17-4PH Stainless Steel |
|---|---|---|---|
| Width | 1500mm 1219mm 1000mm | Surface | NO.1 2B |
| Brand | POSCO TISCO BAOSTEEL | Standard | ASTM A240/240M |
| Loading Port | Shanghai Port | Thickness | 0.6 - 30.0mm |
| Highlight | stainless plate,ss plate,custom stainless steel plates |
||
Product Description
301 Stainless Steel Plate ASTM A240 SS Plate 0.4 - 10.0mm AISI301 Stainless Sheets
Specification of SS 301 plate
|
specifications
|
ASTM A240 / ASME SA240, EN 10088-2 |
|---|---|
|
Standard
|
ASME, ASTM, DIN, BS, EN |
|
Thickness
|
1 to 200mm |
|
Length
|
2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
|
Surface
|
2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand blast, etc |
|
Origin
|
China |
|
Technique
|
Cold Rolled and Hot Rolled |
|
Width
|
1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc |
|
Stainless Steel Sheet Finish
|
Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D |
|
MTC
|
Available as per EN 10204 3.1, Mill Test Certificate |
|
Brand Name
|
TISCO BAOSTEEL POSCO JISCO LISCO |
|
Container
|
40ft HC: 12032m |
|
Form
|
Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc. |
| Price term | CFR, Ex-Work, FOB, CNF, CIF |
|
Size
|
40ft GP: 12032mm x 2352mm x 2393mm |
| 20ft GP: 5898mm x 2352mm x 2393mm |
Detail Size of 301 Stainless Steel Plate We have
| Grade | 17-4PH |
| Thickness |
Cold rolled: 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm Hot Rolled : 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm 25mm 30mm 35mm 40mm 45mm 50mm 55mm 60mm |
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm |
AISI 301 Stainless Steel (UNS S30100)
AISI 301 stainless steel (UNS S30100) is the most susceptible to cold deformation strengthening among conventional austenitic stainless steels. Its work hardening rate is extremely high, with each increase in the amount of cold work, the tensile strength and yield strength will increase significantly. The response to work hardening is particularly important for structural parts, including angle steel and channel sections, which are expected to have additional strength and stiffness after manufacture. On the other hand, for deep drawing applications, lower work hardening rates are generally preferred and can be obtained in austenitic alloys with higher nickel content (especially types 304, 304L, and 305).
Type 301 SS has good corrosion resistance under atmospheric conditions, but it has poor corrosion resistance in reducing media, and chemical media such as acids, alkalis and salts, so it is not recommended for harsh corrosion environments. 301 steel is mainly used in the cold working state to withstand higher loads, but also hopes to reduce the weight of equipment and corrosion-resistant parts.
301 Stainless Steel Chemical Composition
301 stainless steel is an austenitic grade alloy that contains 17-19% chromium, 6-8% nickel, and less than 0.15% carbon. It is known for its excellent corrosion resistance and strength in comparison to other stainless steels. The properties of this type of steel also make it good for deep drawing operations such as sinks, pans, and other components used in kitchenware or tableware.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|
301 ASTM A666 |
min. max. |
– 0.15 |
– 2.0 |
– 1.0 |
– 0.045 |
– 0.030 |
16.0 18.0 |
– |
6.0 8.0 |
– 0.10 |
|
301L JIS G4305 |
min. max. |
– 0.03 |
– 2.0 |
– 1.0 |
– 0.045 |
– 0.030 |
16.0 18.0 |
– |
6.0 8.0 |
– 0.20 |
|
1.4318/301LN EN 10088-2 |
min. max. |
– 0.03 |
– 2.0 |
– 1.0 |
– 0.045 |
– 0.015 |
16.5 18.5 |
– |
6.0 8.0 |
0.10 0.20 |
301 Stainless Steel Physical Properties
301 stainless steel is known for its remarkable physical properties, making it an ideal component for construction projects. Versatile and strong, 301 stainless steel can be formed to almost any shape or size, while possessing extraordinary wear and corrosion resistance. Due to its anti-magnetic characteristics, this alloy also provides excellent electrical conductivity. Moreover, the stainless steel maintains its tolerance over a wide range of temperatures and can provide reinforcement to even the most demanding applications. With this combination of strong properties, 301 stainless steel is long-lasting and a great choice when requiring a reliable building material – perfect for any job requiring premium quality items!
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) |
Electrical Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 301 | 7880 | 193 | 16.9 | 17.2 | 18.2 | 16.2 | 21.4 | 500 | 695 |
301 Stainless Steel Mechanical Properties
301 stainless steel is an extremely versatile material due to its superior mechanical properties. These properties include tensile strength and yield strength, both of which are significantly higher when compared to other standard grades of stainless steel. Additionally, its corrosion resistance is highly robust, in bright oxidizing environments as well as those with low-sulfur gases or chlorine. It also remains stable during high temperatures, making it ideal for use in food preparation applications or heavy equipment exposed to extreme temperatures. To meet the industrial standards for 301 stainless steel, manufacturers must guarantee that the material meets international standards such as ASTM A240/ASME SA240 or EN10088-2.
| Grade 301 Temper ASTM A666 | Tensile Strength (MPa) min. | Yield Strength 0.2% Proof (MPa) min. | Elongation (% in 50mm) (thick.>0.76mm) min. | Bend Test (thickness > 1.27mm) | |
| Bend Angle (°) | Factor | ||||
| Annealed | 758 | 276 | 60 | – | – |
| 1/16 Hard | 620 | 310 | 40 | 180 | 1 |
| 1/8 Hard | 690 | 380 | 40 | 180 | 1 |
| 1/4 Hard | 862 | 514 | 25 | 90 | 2 |
| 1/2 Hard | 1034 | 758 | 18 | 90 | 2 |
| 3/4 Hard | 1205 | 930 | 12 | 90 | 3 |
| Full Hard | 1276 | 965 | 9 | 90 | 5 |
APPLICATIONS:
High strength and excellent corrosion resistance make Type 301 Stainless Steel useful for a wide variety of applications. Typical uses include:
- aircraft structural parts
- trailer bodies
- utensils
- architectural and automotive rim
- roof drainage products
- conveyor belts
- variety of industrial applications.
