17-7PH Stainless Steel Plate Hot Rolled SS Plate UNS S17700 Hot Rolled 10 - 200mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 17-7PH Stainless steel |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-6000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 17-7PH Stainless Steel |
|---|---|---|---|
| Width | 1500mm 1219mm 1000mm | Surface | NO.1 2B |
| Brand | POSCO TISCO BAOSTEEL | Standard | ASTM A240/240M |
| Loading Port | Shanghai Port | Thickness | 0.6 - 30.0mm |
| Highlight | stainless plate,ss plate,custom stainless steel plates |
||
Product Description
17-7PH Stainless Steel Plate Hot Rolled SS Plate UNS S17700 Hot Rolled 10 - 200mm
Specification of SS 17-7PH plate
|
specifications
|
ASTM A240 / ASME SA240, EN 10088-2 |
|---|---|
|
Standard
|
ASME, ASTM, DIN, BS, EN |
|
Thickness
|
1 to 200mm |
|
Length
|
2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
|
Surface
|
2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand blast, etc |
|
Origin
|
China |
|
Technique
|
Cold Rolled and Hot Rolled |
|
Width
|
1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc |
|
Stainless Steel Sheet Finish
|
Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D |
|
MTC
|
Available as per EN 10204 3.1, Mill Test Certificate |
|
Brand Name
|
TISCO BAOSTEEL POSCO JISCO LISCO |
|
Container
|
40ft HC: 12032m |
|
Form
|
Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc. |
| Price term | CFR, Ex-Work, FOB, CNF, CIF |
|
Size
|
40ft GP: 12032mm x 2352mm x 2393mm |
| 20ft GP: 5898mm x 2352mm x 2393mm |
Detail Size of 17-7PH Stainless Steel Plate We have
| Grade | 17-7PH |
| Thickness |
Cold rolled: 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm Hot Rolled : 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm 25mm 30mm 35mm 40mm 45mm 50mm 55mm 60mm |
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm |
17-7 PH is a precipitation-hardening stainless steel that provides high strength and hardness, excellent fatigue properties, good corrosion resistance, good formability, and minimum distortion upon heat treatment. The alloy provides valuable property combinations particularly well suited for aerospace applications. This special alloy also provides benefits for other applications requiring high strength and good corrosion resistance, as well as excellent properties for flat springs at temperatures up to 600°F (316°C).
Chemical Properties of 17-7PH Stainless Steel
| TYPE | Cr | Ni | Al | C | Mn | P | S | Si |
|---|---|---|---|---|---|---|---|---|
| 17-7 | min: 16.0 max: 18.0 |
min: 6.75 max: 7.75 |
min: 0.75 max: 1.50 |
0.09 max |
1.00 max |
0.05 max |
0.03 max |
1.00 max |
Mechanical Propertiesof 17-7PH Stainless Steel
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
|---|---|---|---|---|
| 17-7 | 130 | 40 | 35 | B85 |
Application of 17-7PH Stainless steel
Classified as a semi-austenitic stainless steel, 17-7 is used extensively in making parts used by the aerospace industry. It is also used in a variety of springs and washers, power boilers, and heat exchangers.
Currently, the 17-7 material is most often used in sheet and strip form when producing springs, clips, and bellows. It is finding new applications in the medical industry due to its high alloy content that provides high, spring-like strength, good ductility, and excellent corrosion, all important attributes for items manufactured for the medical industry.
Vacuum heat treatment technology is allowing the use of 17-7 steel alloy in new medical device design that is based on 17-7’s established set of mechanical properties with the additional benefit of producing bright, non-discolored medical devices. Using this technique does not require removing parts from the furnace for a separate cooling step. This reduces heat treatment costs and provides shiny, cost-effective medical instruments. Though not classified as a standard PH condition, this approach is gaining traction due to the medical industry’s interest.
Why choose us
We are customer driven and proud of our ability to roll precision strip to tighter tolerances, with both short lead times and smaller minimum amounts than our competition. We value your business and will work hard to get it and keep it, not only by producing quality products but by allowing you to receive material quickly.
Our state of the art conversion mill in Hampshire, Illinois is one of the leading producers of light gauge stainless steel strip, that is produced to precision thickness and widths based on our customer’s specifications. Our facilities for slitting, shearing, blanking, and edging, offer 17-7 PH stainless steel in coils or cut lengths in thicknesses .001 and heavier in accordance with your specifications.
