SA240 Grade 329 Stainless Steel Plate 0.4 - 20.0mm SS Plate in 5ft*20ft 4ft*8ft UNS S32900
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | UNS S32900 |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-6000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | UNS S32900 |
|---|---|---|---|
| Width | 1500mm 1219mm 1000mm | Surface | NO.1 2B |
| Brand | POSCO TISCO BAOSTEEL | Standard | ASTM A240/240M |
| Loading Port | Shanghai Port | Thickness | 0.6 - 30.0mm |
| Highlight | stainless plate,ss plate,custom stainless steel plates |
||
Product Description
SA240 Grade 329 Stainless Steel Plate 0.4 - 20.0mm SS Plate in 5ft*20ft 4ft*8ft UNS S32900
Specification of SS UNS S32900 sheet
|
specifications
|
ASTM A240 / ASME SA240, EN 10088-2 |
|---|---|
|
Stainless Steel 316ti Sheet Standard
|
ASME, ASTM, DIN, BS, EN |
|
Thickness
|
1 to 200mm |
|
Length
|
2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
|
Surface
|
2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand blast, etc |
|
Origin
|
China |
|
Technique
|
Cold Rolled and Hot Rolled |
|
Width
|
1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc |
|
Stainless Steel 316 Sheet Finish
|
Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D |
|
MTC
|
Available as per EN 10204 3.1, Mill Test Certificate |
|
Brand Name
|
TISCO BAOSTEEL POSCO JISCO LISCO |
|
Container
|
40ft HC: 12032m |
|
Form
|
Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc. |
| Price term | CFR, Ex-Work, FOB, CNF, CIF |
|
Size
|
40ft GP: 12032mm x 2352mm x 2393mm |
| 20ft GP: 5898mm x 2352mm x 2393mm |
The Stainless Steel Type 329 is duplex steel being a combination of austenitic and ferritic types. It can resist pitting as well as corrosion cracking under stress. This type of steel is better to use in forged valve pumps and their components.
Type 329 is also frequently used for centrifugal machines. This type of steel forges better at temperatures around 1250/1050C or 2280/1900F. The parts need to be air-cooled once they are forged. Duplex steel of such grade is very difficult to weld, and hence its machinability is very low.
Common Names: The other names of stainless steel 329 are AISI 329, and UNS S32900.
Executive Standards:
- ASTM A240
- ASME SA240
- ASTM A268
- ASME SA268
- ASTM A789
- ASME SA789
- ASTM A790
- ASME SA790
- ASTM A511
- ASME SA511
- DIN 1.4460
Chemical Properties:
| Elements | Content |
| Iron | 63% |
| Chromium | 28% |
| Nickel | 4.5% |
| Manganese | 2% |
| Molybdenum | 1.5% |
| Silicon | 1% |
| Carbon | 0.10% |
| Phosphorous | 0.040% |
| Sulfur | 0.030% |
Mechanical Properties:
| Properties | Metric |
| Ultimate tensile strength | 725 MPa (105000 psi) |
| Tensile strength, yield (@0.2%) | 550 MPa (79800 psi) |
| Elastic modulus | 190 to 210 GPa (27557 to 30458 Ksi) |
| Poisson’s ratio | 0.27 – 0.30 |
| Elongation (50 mm) | 25% |
| Hardness, Brinell (Knoop) (RB) (RC) (Vickers) | 230 (253) (96) (20) (242) |
Physical Properties: The most notable physical property of SS Type 329 is its density which is 7.80 g/cm3 (0.282 lb/in3
Key Features:
- The thermal expansion coefficient (TEC) at 20C to 815C (68F to 1500F) is 14.4µm/mC (8 µin/inF).
- Slightly lower alloy content as compared to Grade 2205.
- Parts and components must be solutions annealed at around 1020C to 1100C (1870F to 2010F) and then must be quenched in water.
Product Forms Available:
- Plates
- Pipes
- Round Bar
- Tube
- Flanges
- Wire
- Fittings
Applications:
- Off-shore technology.
- Paper industry.
- Chemical tanks.
- Heat exchangers.
- Refineries.
- Flanges, fittings, and pipes for the oil and gas industries.
- Compressor parts.
- Marine shafts for pressure vessel parts.
- Desalination plants at seawater.
Possible Alternative Grades:
- Type 2205
- Type 316L
- Type 904L
Frequently Asked Questions
- What is the temperature for the full martensite transformation of SS 329?
The temperature for a full martensite transformation for Type 329 SS is 1038C (1090F) for 30 minutes and then cool it down below 16C (60F).
- Is oxyacetylene welding recommended for SS329?
No, the recommended welding for SS 329 is standard fusion-resistance methods.
- How to forge SS329?
329 Stainless Steel Application
UNS S32900 is a primary metal alloy used in many applications across industries. Its ability to retain strength and resist corrosion makes it an ideal material for a variety of projects, from construction to food processing. In construction, its extraordinary tensile strength makes it a great choice for bolts and other structures that require stability when experiencing movement and vibration. Additionally, its excellent corrosion resistance has made it popular for chemical processing applications such as pipes, valves and pumps that have frequent contact with liquids or vapours. Lastly, 329 stainless steel is great for food processing as it can handle prolonged contact with liquids like acid-based foods or alcoholic beverages without suffering wear and tear or discolouration over time. Clearly, 329 stainless steel is one of the most useful metals available today due to its wide range of applications.
