304H Stainless Steel Plate Thickness 6.0 - 150mm SS Plate UNS S30409 Hot Rolled NO.1 Finish
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 304H / UNS S30409 |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-6000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 304H / UNS S30409 |
|---|---|---|---|
| Thickness | 3.0 - 150.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 2B | Brand | POSCO TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | stainless plate,ss plate,custom stainless steel plates |
||
Product Description
304H Stainless Steel Plate Thickness 6.0 - 150mm SS Plate UNS S30409 Hot Rolled NO.1 Finish
Alloy 304 is a T-300 series stainless steel austenitic, which has a minimum of 18% chromium and 8% nickel with a maximum of 0.08% carbon. It is the standard “18/8 stainless” that is commonly found in pans and cooking tools. Alloy 304 is the most versatile and widely used alloy in the stainless steel family. It may be used for a wide variety of home and commercial applications and exhibits excellent corrosion resistance, has a high ease of fabrication, outstanding formability, and tremendous strength. The austenitic stainless steels are also considered to be the most weldable of the high-alloy steels and can be welded by all fusion and resistance welding processes. Due to its controlled carbon content of 0.04 to 0.10, Alloy 304H provides improved high temperature strength when exposed to temperatures above 800oF. Alloy 304H also has greater short term and long term creep strength than Alloy 304L at temperatures above 500oC and is more resistant to sensitization than Alloy 304L.
APPLICATIONS OF 304H STAINLESS STEEL
Alloy 304H is often used as a material of construction up to about 1500oF. Some examples of applications that Alloy 304H is commonly used for includes:
- Most commonly used in petroleum refineries
- Boilers
- Heat exchangers
- Condensers
- Pipelines
- Cooling towers
- Steam exhausts
- Electric generation plants
- On occasion will be found in fertilizer and chemical plants
STANDARDS – ALLOY 304H
ASTM/ASME: UNS S30409
EURONORM: FeMi35Cr20Cu4Mo2
DIN: 2.4660
HEAT RESISTANCE
- Good oxidation resistance in intermittent service to 870O C and in continuous service to 920O C
- Continuous use of Alloy 304 in the 425-860°C range is not recommended if subsequent aqueous corrosion resistance is important
- Alloy 304H has higher strength at elevated temperatures so is often used for structural and pressure-containing applications at temperatures above about 500°C and up to about 800°C
- Alloy 304H will become sensitized in the temperature range of 425-860°C; this is not a problem for high temperature applications, but will result in reduced aqueous corrosion resistance.
CORROSION RESISTANCE
- Resistance to corrosion in oxidizing environments is a result from the 18 to 19% chromium that the 304 alloys contain
- Resistance to moderately aggressive organic acids is a result from the 9 to 11% nickel that the 304 alloys contain
- At times, Alloy 304L may show a lower corrosion rate than the higher carbon Alloy 304; otherwise, the 304, 304L, and 304H alloys may be considered to perform uniformly in most corrosive environments.
Chemical Properties of 304H Stainless Steel
| % | Cr | Ni | C | Si | Mn | P | S | N |
|---|---|---|---|---|---|---|---|---|
| 304H | min: 18.0 max:20.0 |
min: 8.0 max: 10.5 |
min: 0.04 max:0.10 |
0.75 max |
2.0 max |
0.045 max |
0.03 max |
0.10 max |
Mechanical Properties of 304H Stainless Steel
| Grade | Tensile Strength ksi (min.) |
Yield Strength 0.2% Offset ksi (min.) |
Elongation - % in 50 mm (min.) |
Hardness (Brinell) MAX |
Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 304H | 75 | 30 | 40 | 201 | 92 |
Physical Properties:
| Denstiy lbm/in^3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)^2-psi | ||
|---|---|---|---|---|---|---|
| at 68 °F | at 68 – 212°F | at 68 – 1600°F | at 212°F | at 932°F | at 32 – 212°F | in tension (E) |
| 0.285 | 9.2 | 11.0 | 9.4 | 12.4 | 0.12 | 29 x |
