EN 1.4460 / SS329 / S32900 Stainless Steel Plate Sheet 0.3 - 100mm Custom Cutting
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 1.4460 / 329 / S32900 |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-6000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 1.4460 / 329 / S32900 |
|---|---|---|---|
| Thickness | 0.4-30.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 2B | Brand | POSCO TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | S32900 Stainless Steel Plate,TISCO Stainless Steel Sheet |
||
Product Description
EN 1.4460 / SS329 / S32900 Stainless Steel Plate & Sheet 0.3 - 100mm Custom Cutting SS Plate
| Products | 1.4460 / 329 / s32900 Stainless Steel Plate | |||
|
Width
|
1000mm/1219mm/1240mm/1500mm/2000mm or as customer's requirements
|
|||
|
Thickness
|
cold rolled: 0.1-3mm; hot rolled: 3-100mm
|
|||
|
Length
|
100mm to 12000mm or as customer's request
|
|||
|
Surface
|
N0.1, N0.4, 2D, 2B, HL, BA, 6K, 8K, Mirror,etc
|
|||
|
Material
|
201,202,301,302,303,304,304L,304N1,309S,310S,316,316L, 316Ti,316N,317,317L,321,409L,410,420,430,904,904L,etc
|
|||
|
Grade
|
200/300/400/500/600/700/800/900 series/duplex stainless steel
|
|||
|
Standards
|
AISI ASTM JIS SUS DIN GB
|
|||
|
Brand
|
TISCO,ZPSS,Baosteel,POSCO,LISCO,YUSCO,Ansteel, QPSS,JISCO, HXSCO,Chengde,Yongjin,Tsingshan,Shouyang,
|
|||
AISI 329 stainless steel is a duplex stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the annealed condition. 329 is the AISI designation for this material. S32900 is the UNS number.
It has a fairly low ductility among wrought duplex stainless steels. In addition, it has a moderately high thermal conductivity and a fairly low electrical conductivity.
The graph bars on the material properties cards below compare AISI 329 stainless steel to: wrought duplex stainless steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
Chemical Properties of 329 Stainless Steel
| Elements | Content |
| Iron | 63% |
| Chromium | 28% |
| Nickel | 4.5% |
| Manganese | 2% |
| Molybdenum | 1.5% |
| Silicon | 1% |
| Carbon | 0.10% |
| Phosphorous | 0.040% |
| Sulfur | 0.030% |
329 Stainless Steel Mechanical Properties
The mechanical properties of 329 stainless steel mainly depend on the heat treatment process used during manufacturing. After heat treatment processes like annealing or quenching, this grade can achieve improved hardness levels up to 30 HRC while still maintaining its excellent strength and ductility characteristics. This makes it particularly useful for applications where hard-wearing parts are required but must still be able to withstand heavy loads without breaking or cracking under pressure.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength, ultimate | 725 MPa | 105000 psi |
| Tensile strength, yield (@0.2%) | 550 MPa | 79800 psi |
| Charpy impact | 54 J | 39.8 ft-lb |
| Elastic modulus | 190 – 210 GPa | 27557 – 30458 ksi |
| Poisson’s ratio | 0.27 – 0.30 | 0.27 – 0.30 |
| Elongation at break (in 50 mm) | 25% | 25% |
| Hardness, Brinell | 230 | 230 |
| Hardness, Knoop (converted from Brinell hardness) | 253 | 253 |
| Hardness, Rockwell B | 96 | 96 |
| Hardness, Rockwell C (converted from Brinell hardness) | 20 | 20 |
| Hardness, Vickers (converted from Brinell hardness) | 242 | 242 |
329 Stainless Steel Equivalent
- ASTM A240
- ASTM A268
- ASTM A789
- ASTM A790
- ASTM A511
- ASME SA268
- ASME SA268
- DIN 1.4460
329 Stainless Steel Application
UNS S32900 is a primary metal alloy used in many applications across industries. Its ability to retain strength and resist corrosion makes it an ideal material for a variety of projects, from construction to food processing. In construction, its extraordinary tensile strength makes it a great choice for bolts and other structures that require stability when experiencing movement and vibration. Additionally, its excellent corrosion resistance has made it popular for chemical processing applications such as pipes, valves and pumps that have frequent contact with liquids or vapours. Lastly, 329 stainless steel is great for food processing as it can handle prolonged contact with liquids like acid-based foods or alcoholic beverages without suffering wear and tear or discolouration over time. Clearly, 329 stainless steel is one of the most useful metals available today due to its wide range of applications.
