Hot Rolled Stainless Steel Coils Plate Sheet 317L / 1.4438 Alloy AISI317
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 317L / UNS S31703 / EN 1.4438 |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-6000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 317L / UNS S31703 / EN 1.4438 |
|---|---|---|---|
| Thickness | 0.4-30.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 2B | Brand | POSCO TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | Hot Rolled Stainless Steel Coils Plate,1.4438 Stainless Steel Plate |
||
Product Description
Cold Rolled / Hot Rolled 317L / 1.4438 Alloy AISI317 Stainless Steel Plate Sheet & Coils
| Products | 317L / S31703 Stainless Steel Plate | |||
|
Width
|
1000mm/1219mm/1240mm/1500mm/2000mm or as customer's requirements
|
|||
|
Thickness
|
cold rolled: 0.1-3mm; hot rolled: 3-100mm
|
|||
|
Length
|
100mm to 12000mm or as customer's request
|
|||
|
Surface
|
N0.1, N0.4, 2D, 2B, HL, BA, 6K, 8K, Mirror,etc
|
|||
|
Material
|
201,202,301,302,303,304,304L,304N1,309S,310S,316,316L, 316Ti,316N,317,317L,321,409L,410,420,430,904,904L,etc
|
|||
|
Grade
|
200/300/400/500/600/700/800/900 series/duplex stainless steel
|
|||
|
Standards
|
AISI ASTM JIS SUS DIN GB
|
|||
|
Brand
|
TISCO,ZPSS,Baosteel,POSCO,LISCO,YUSCO,Ansteel, QPSS,JISCO, HXSCO,Chengde,Yongjin,Tsingshan,Shouyang,
|
|||
Type 317L stainless steel is a low-carbon molybdenum-containing austenitic stainless steel. It provides superior corrosion resistance compared to Type 316L in highly corrosive process environments, especially in chlorides or other halides. The low carbon content makes it suitable for welding without sensitization to intergranular corrosion caused by chromium carbide precipitation in the grain boundaries. They are non-magnetic in the annealed condition but exhibit a little magnetism during welding or after welding.
Stainless Steel 317L Sheet Specifications
- ASTM A240, ASME SA240, BS EN 10028-7, BS EN 10088-2 and BS EN 10088-4
- EN 10088/2, EN 10088/4 and CE Marking
- NACE MR 0175/ISO 15156 Certification
- Grade 317L
More Informations of 317L Stainless Steel Sheet
| Other Trade Name of 317L Stainless Sheet | SS 317L, SUS 317L, Inox 317L, DIN 1.4438, UNS S31703, AISI 317L, SAE 317L Sheet |
|---|---|
| Product Type | ASTM A240 317L Sheet, ASTM A240 317L Plate |
| Specification | ASTM A240 / ASME SA240 |
| Tolerances (width / thickness) |
|
| International Standard |
|
| Sizes |
|
| Thickness | 0.1 to 100 mm Thk |
| Width | 10-2500mm |
| Length | 2m, 2.44m, 3m, or as required |
| Finish | SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror etc. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| Manufacturing Shapes | Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
Regular Stock Size of Our S31703 Duplex Stainless Steel Plate
| Cold Rolled S317L Sheet | Hot Rolled 317L Plate | ||
| Thickness | Size | Thickness | Size |
| 0.4mm | 1000*2000mm | 4.0mm | 1500*6000mm |
| 0.5mm | 1000*2000mm | 5.0mm | 1500*6000mm |
| 0.6mm | 1219*2438mm | 6.0mm | 1500*6000mm |
| 0.7mm | 1219*2438mm | 8.0mm | 1500*6000mm |
| 0.8mm | 1219*2438mm | 10.0mm | 1500*6000mm |
| 1.0mm | 1219*2438mm | 12.0mm | 1500*6000mm |
| 1.2mm | 1219*2438mm | 14.0mm | 1500*6000mm |
| 1.5mm | 1219*2438mm | 16.0mm | 1500*6000mm |
| 2.0mm | 1219*2438mm | 20.0mm | 1500*6000mm |
| 2.5mm | 1219*2438mm | 25.0mm | 1500*6000mm |
| 3.0mm | 1219*2438mm | 30.0mm | 1500*6000mm |
317L Material Equivalent
| STANDARD | UNS | WERKSTOFF NR. |
| SS 317L | S31703 | 1.4438 |
Applications of 317L Stainless Steel Plate
Grade 317L stainless steel is widely used in the following applications:
- Condensers in fossil
- Pulp and paper manufacturing
- Nuclear fueled power generation stations
- Chemical and petrochemical process equipment.
