317L / UNS S31703 2b Stainless Steel Plate ASTM A240 0.4 - 30.0mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 317L / UNS S31703 / EN 1.4438 |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-6000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 317L / UNS S31703 / EN 1.4438 |
|---|---|---|---|
| Thickness | 0.4-30.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 2B | Brand | POSCO TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | 317L 2b stainless steel plate,2b stainless steel plate 0.4mm |
||
Product Description
TISCO POSCO 317L / UNS S31703 Stainless Steel Sheet & Plate ASTM A240 0.4 - 30.0mm
| Products | 317L / S31703 Stainless Steel Plate | |||
|
Width
|
1000mm/1219mm/1240mm/1500mm/2000mm or as customer's requirements
|
|||
|
Thickness
|
cold rolled: 0.1-3mm; hot rolled: 3-100mm
|
|||
|
Length
|
100mm to 12000mm or as customer's request
|
|||
|
Surface
|
N0.1, N0.4, 2D, 2B, HL, BA, 6K, 8K, Mirror,etc
|
|||
|
Material
|
201,202,301,302,303,304,304L,304N1,309S,310S,316,316L, 316Ti,316N,317,317L,321,409L,410,420,430,904,904L,etc
|
|||
|
Grade
|
200/300/400/500/600/700/800/900 series/duplex stainless steel
|
|||
|
Standards
|
AISI ASTM JIS SUS DIN GB
|
|||
|
Brand
|
TISCO,ZPSS,Baosteel,POSCO,LISCO,YUSCO,Ansteel, QPSS,JISCO, HXSCO,Chengde,Yongjin,Tsingshan,Shouyang,
|
|||
317L stainless steel plate is an austenitic, molybdenum-bearing grade of stainless steel with increased resistance to chemical attack when compared to basic chromium-nickel alloy such as 304. Due to its chemical composition, this steel plate offers higher creep strength, stress to rupture and tensile strength, specifically at elevated temperatures. This stainless steel plate is a low carbon grade which results in greater resistance to sensitization during welding and other important thermal processes.
This stainless steel plate is available for purchase at Penn Stainless Products in a variety of length, widths, and thicknesses. It can be purchased in plate mill plate thickness ranging between 0.188” and 1.0”. Other thickness and a variety of lengths and widths are available, consult with a member of the Penn Stainless Products team.
Type 317L stainless steel was first developed to resist attacks by sulfurous acid compounds. Consequently it has a proven ability to combat corrosion in other environments and is now used for many other industrial applications. Other features of 317L stainless steel include:
- Higher creep, stress-to-rupture and tensile strength than other stainless steels.
- Reduced intergranular precipitation of chromium carbides during welding and stress relieving.
- A reduced possibility of corrosion failure from intergranular attack.
- Resistance to pitting and crevice corrosion, which makes 317L a successful product for a variety of highly corrosive environments.
Regular Stock Size of Our S31703 Duplex Stainless Steel Plate
| Cold Rolled S317L Sheet | Hot Rolled 317L Plate | ||
| Thickness | Size | Thickness | Size |
| 0.4mm | 1000*2000mm | 4.0mm | 1500*6000mm |
| 0.5mm | 1000*2000mm | 5.0mm | 1500*6000mm |
| 0.6mm | 1219*2438mm | 6.0mm | 1500*6000mm |
| 0.7mm | 1219*2438mm | 8.0mm | 1500*6000mm |
| 0.8mm | 1219*2438mm | 10.0mm | 1500*6000mm |
| 1.0mm | 1219*2438mm | 12.0mm | 1500*6000mm |
| 1.2mm | 1219*2438mm | 14.0mm | 1500*6000mm |
| 1.5mm | 1219*2438mm | 16.0mm | 1500*6000mm |
| 2.0mm | 1219*2438mm | 20.0mm | 1500*6000mm |
| 2.5mm | 1219*2438mm | 25.0mm | 1500*6000mm |
| 3.0mm | 1219*2438mm | 30.0mm | 1500*6000mm |
Stainless Steel SA 240 Gr 317L Composition
| SS | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| A240 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 - 20.00 | 3.00 - 4.00 | 11.00 - 15.00 | 57.89 min |
Stainless Steel 317L Properties
| Melting Range | Density | Tensile Strength (PSI/MPa) | Yield Strength (0.2%Offset) (PSI/MPa) | Elongation % |
| 1400 °C (2550 °F) | 7.9 g/cm3 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Our Processing Service for 317L Stainless Steel Plate
- Plasma cutting
- Plate saw cutting
- Shearing
- Laser cutting
- Waterjet cutting
- Forming
- Welding
- Machining
- Plate leveling
Applications of 317L Stainless Steel Plate
Grade 317L stainless steel is widely used in the following applications:
- Condensers in fossil
- Pulp and paper manufacturing
- Nuclear fueled power generation stations
- Chemical and petrochemical process equipment.
