UNS S32550 Duplex Stainless Steel Plate Ferralium 255 EN 1.4507 Alloy 255 Plate
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | Ferralium 255 / UNS S32550 / 2550 |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-6000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | Ferralium 255 / UNS S32550 / 2550 |
|---|---|---|---|
| Thickness | 0.4-30.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 2B | Brand | POSCO TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | Duplex Stainless Steel Plate,EN 1.4507 Stainless Plate |
||
Product Description
UNS S32550 Duplex Stainless Steel Plate Ferralium 255 Plate EN 1.4507 Alloy 255 Stainless Steel Plate
| Products | S32550 Duplex Stainless Steel Plate | |||
|
Width
|
1000mm/1219mm/1240mm/1500mm/2000mm or as customer's requirements
|
|||
|
Thickness
|
cold rolled: 0.1-3mm; hot rolled: 3-100mm
|
|||
|
Length
|
100mm to 12000mm or as customer's request
|
|||
|
Surface
|
N0.1, N0.4, 2D, 2B, HL, BA, 6K, 8K, Mirror,etc
|
|||
|
Material
|
201,202,301,302,303,304,304L,304N1,309S,310S,316,316L, 316Ti,316N,317,317L,321,409L,410,420,430,904,904L,etc
|
|||
|
Grade
|
200/300/400/500/600/700/800/900 series/duplex stainless steel
|
|||
|
Standards
|
AISI ASTM JIS SUS DIN GB
|
|||
|
Brand
|
TISCO,ZPSS,Baosteel,POSCO,LISCO,YUSCO,Ansteel, QPSS,JISCO, HXSCO,Chengde,Yongjin,Tsingshan,Shouyang,
|
|||
Ferralium® 255 is a super duplex stainless steel supplied in the hot worked, annealed and pickled condition. It achieves higher strengths than other alternative corrosion resistant alloys, offering the potential to reduce section size and therefore weight and cost.
As a 25% Cr alloy, with significant additions of Cu, it offers excellent corrosion resistance in a wide variety of corrosive chemicals including sulphuric, nitric and phosphoric acid. In seawater and other chloride containing environments it also provides outstanding resistance to pitting and crevice corrosion, with Critical Pitting Temperature exceeding 50°C. Excellent ductility and impact strength at both ambient and sub-zero temperatures combine with a high resistance to abrasion, erosion and cavitation erosion.
Listed in NACE MR 0175 for sour service and having gained ASME Approval for Pressure Vessel applications, Ferralium® 255 is tested to the highest degree using tests designed to guarantee that the trade-marked product possesses high integrity, a correct phase balance and the absence of sigma and other deleterious phases.
Regular Stock Size of Our 32550Duplex Stainless Steel Plate
| Cold Rolled 32550 Sheet | Hot Rolled 32550 Plate | ||
| Thickness | Size | Thickness | Size |
| 0.4mm | 1000*2000mm | 4.0mm | 1500*6000mm |
| 0.5mm | 1000*2000mm | 5.0mm | 1500*6000mm |
| 0.6mm | 1219*2438mm | 6.0mm | 1500*6000mm |
| 0.7mm | 1219*2438mm | 8.0mm | 1500*6000mm |
| 0.8mm | 1219*2438mm | 10.0mm | 1500*6000mm |
| 1.0mm | 1219*2438mm | 12.0mm | 1500*6000mm |
| 1.2mm | 1219*2438mm | 14.0mm | 1500*6000mm |
| 1.5mm | 1219*2438mm | 16.0mm | 1500*6000mm |
| 2.0mm | 1219*2438mm | 20.0mm | 1500*6000mm |
| 2.5mm | 1219*2438mm | 25.0mm | 1500*6000mm |
| 3.0mm | 1219*2438mm | 30.0mm | 1500*6000mm |
Chemical Composition of UNS S32550 Duplex Stainless Steel
Chemical Requirements |
|||||||
|---|---|---|---|---|---|---|---|
|
|
Ni |
Cr |
Mo |
Mn |
C |
Si |
Fe |
|
Max |
6.5 |
27.0 |
3.9 |
1.50 |
0.04 |
1.00 |
Bal |
|
Min |
4.5 |
24.0 |
2.9 |
|
|
|
|
Mechanical Properties of Duplex S32550 Stainless Steel
| For plates up to 3” in thickness | ||
| 0.2% Proof Stress | 550 N/mm2 | 79.8 ksi |
| Tensile Strength | 790 N/mm2 | 114.5ksi |
| Elongation, 5.65√S0 and 4D | 25% | |
| Reduction of Area | 50% | |
| Hardness (Brinell) | 220-270 | |
| Impact Strength (Room Temp) | 80J | 59 ft.lb |
Notes:
- Testing shall be carried out in accordance with ASTM A370 or EN ISO 6892-1 (tensile), EN ISO 6506-1 (hardness)
- Minimum properties quoted (tested at room temperature in a longitudinal direction)
- Testing performed on each melt of material per heat treatment batch
- Hardness shall be in accordance with NACE MR 1075 with a maximum HRC value of 28 (270HB)
- ASTM G48A corrosion test (at 40°C) no pitting and < 0.8g/m2 weight loss
- Ferrite content 35-55%
- Microstructure certified free from grain boundary carbides, sigma, chi and laves phases
Applications of Duplex S32550 Stainless Steel Plate
- Oil & Gas industry pumps, valves, wellhead and subsea equipment
- Pollution control scrubbers, precipitators, fans and pumps
- Marine propellers, shafts, rudders, seals, pumps, valves
- Bolts and fasteners
- Process industry equipment in sulphuric acid, nitric acid, phosphoric acid, PP / PVC/TiOx production, agrochemicals
- Grain and vegetable processing plant, sugar cane centrifuges
- Pulp and paper digester blow vales, feed valves, washers, black liquor heater tubes, bleaching components
- Copper smelting fans, tuyere bars, wet scrubbers, leaching area precipitators
- Water and sewage treatment, desalination, swimming pools
