Duplex 2205 Stainless Steel Plate Sheets S31803 / S32205 / EN 1.4462 TISCO BAOSTEEL
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 2205 |
| Minimum Order Quantity | 1 Ton |
| Price | 2500-3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Stainless Steel Plate | Grade | 2205 |
|---|---|---|---|
| Thickness | 0.6-30.0mm | Standard | ASTM EN GB |
| Width | 1000mm 1219mm 1500mm | Surface | 2B NO.1 |
| Brand | TISCO BAOSTEEL | MOQ | 1 Ton |
| Highlight | Duplex 2205 Stainless Steel Sheets,BAOSTEEL Stainless Steel Plate Sheets,EN 1.4462 Stainless Steel Sheets |
||
Product Description
Duplex 2205 / S31803 / S32205 / EN 1.4462 Stainless Steel Plate & Sheets TISCO BAOSTEEL
| Item | Duplex 2205 Stainless Steel Plate |
| Raw Material | Stainless steel sheet (hot rolled and cold rolled) |
| Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, 2205 ,2507,254SMO,253MA.etc. |
| Thickness | 0.6 - 30.0mm |
| Stock Thickness | 0.6mm ,0.8mm,1.0mm,1.2mm,1.5mm.2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,25mm,30.0mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as your request |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | Standard export package |
Duplex 2205 LIMITING CHEMICAL COMPOSITION, %
| Element | Percent By Weight | |
|---|---|---|
| Cr | Chromium | 22.0 - 23.0% |
| Ni | Nickel | 4.5 - 6.5% |
| Mn | Manganese | 2.0% max |
| Si | Silicon | 1.0% max |
| P | Phosphorous | 0.03% max |
| S | Sulfur | 0.02% max |
| C | Carbon | 0.03% max |
| N | Nitrogen | 0.1 - 0.2% |
| Mo | Molybdenum | 3.0 - 3.5% |
| Fe | Iron | Balance |
2.Duplex 2205 Introduction
2205 is a duplex stainless steel with higher alloy content, thus making it superior in corrosion resistance and strength. It has excellent resistance to uniform, pitting, crevice corrosion and chloride stress corrosion cracking. In dilute sulfuric acid contaminated with chloride ions.
3.Duplex 2205 MAJOR SPECIFICATIONS
4.Duplex 2205 PHYSICAL PROPERTIES
| Density | Magnetic | Specific heat | Thermal conductivity | Thermal expansion rate |
| (g/cm) | (J/g.C) | 100C(W/m. | 20~100C | |
| (10/C) | ||||
| 7.8 | YES | 0.45 | 19 | 13.7 |
5.Duplex 2205 MECHANICAL PROPERTIES
| Heat Treatment | T*S | Y*S | El | Hardness |
| MPA | MPA | % | HB | |
| 1025-1125 | 800 | 550 | 15 | ≤310 |
6.Duplex 2205 APPLICATIONS
Chemical processing industry piping, vessels and heat exchangers; desalination plant seawater piping; oil and gas industry equipment; power plant flue gas desulfurization systems, scrubber systems and absorber towers; and chemical tankers.
FAQ
Q: Are you a trading company or a manufacturer?
A: We are a direct factory with production lines and workers. Everything is flexible and there is no need to worry about intermediaries or additional fees for traders.
Q: Which countries do you export to?
A: Our products are mainly exported to Australia, Canada, Britain, the United States, Germany, Thailand, South Korea and so on.
Q: Do you provide samples? Is it free or extra?
A: Because our raw materials are so expensive that we do not supply free samples.
Q: What is your minimum order quantity?
A: In fact, there is no minimum order quantity for our products. But usually we recommend quantities based on acceptable prices.
Q: How about the delivery time?
A: It is order based, usually within 15-30 days after receiving your advance payment.
