ASTM A240 Stainless Steel Plate 310S / 06Cr25Ni20 / 1.4845 / S31008 0.4 - 80.0mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 310S |
| Minimum Order Quantity | 1 Ton |
| Price | 6000 - 7500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Stainless Steel Plate | Grade | 310S |
|---|---|---|---|
| Thickness | 0.6-30.0mm | Standard | ASTM EN GB |
| Width | 1000mm 1219mm 1500mm | Surface | 2B NO.1 |
| Brand | TISCO BAOSTEEL | MOQ | 1 Ton |
| Highlight | S31008 Stainless Steel Plate,1.4845 Stainless Steel Sheets,80.0mm Stainless Steel Sheets |
||
Product Description
ASTM A240 310S / 06Cr25Ni20 / 1.4845 / S31008 Stainless Steel Plate Thickness 0.4 - 80.0mm
| Item | 310S Stainless Steel Plate |
| Raw Material | Stainless steel sheet (hot rolled and cold rolled) |
| Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, 2205 ,2507,254SMO,253MA.etc. |
| Thickness | 0.6 - 30.0mm |
| Stock Thickness | 0.6mm ,0.8mm,1.0mm,1.2mm,1.5mm.2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,25mm,30.0mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as your request |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | Standard export package |
About 310S Stainless Steel Plate
Grade 310 / 310S stainless steel (1.4845) is one of the most widely used grades of heat-resistant stainless steel supplied to numerous industry sectors. The key properties of this material are its high chromium and medium nickel content making its resistance to oxidation, sulfidation, and other forms of hot corrosion its main characteristics. Whilst retaining good strength when exposed to high temperatures, like most austenitic grades this grade will also maintain its strength and toughness at sub-zero temperatures. Overall this grade is an excellent choice for various applications ranging from furnace components to burner tips. 310 / 310S has a maximum dry air service temperature of 1100ºC.
Form of Supply
| * 310 Sheet | * 310 Plate | * 310 Round Bar | * 310 Wire | * 310 Tube & Pipe |
Nationwide Stainless is one of the UK’s largest independent Stockholders and Processors of grade 310 / 310S stainless steel (1.4845). With a large stock range and excellent processing capabilities, we are able to supply most projects whether stock items or custom-made products. We can offer; Stock size plate & sheet, Stock length round bar, Cut to size plate & sheet, Cut to length round bar, Cold forming of plate & sheet and round bar, And any other additional machining requirements that may be necessary.
Applications
| * Jigs | * Tube Hangers | * Brick Shelf |
| * Heat Treatment Baskets | * Refractory Anchors | * Heat Exchangers |
| * Coal Gassifier Components | * Flare Tips | * Furnace Components |
| * Food Processing Equipment | * Bricking Plates | * Cement Kiln Components |
| * Burners | * Burner Tips | * Brick Supports |
Corrosion Resistance
310 / 310S stainless steel (1.4845) has excellent corrosion resistance at normal temperatures but is primarily designed to perform at high temperatures. In these high-temperature environments, 310 / 310S (1.4845) maintains very good corrosion resistance and also has exceptional resistance to; oxidizing and carburizing atmospheres and other forms of hot corrosion, up to a maximum dry air service temperature of 1100ºC. Other corrosive compounds such as water and sulphur compounds will significantly reduce the maximum service temperature.
Chemical Composition of 310S Stainless Steel
| 310S | Cr% | Ni% | C% | Si% | Mn% | P% | S% | Mo% | Cu% | Fe% |
| MIN | 24.0 | 19.0 | - | - | - | - | - | - | - | - |
| MAX | 26.0 | 22.0 | 0.08 | 0.75 | 2.0 | 0.045 | 0.03 | 0.75 | 0.5 | Bal |
Mechanical Properties
The properties quoted below are guideline figures only and should not be used for any design purposes
| Temperature ºC | 100 | 500 | 800 | 1000 | 1100 |
| UTS (Nmm²) | 600 | 475 | 215 | 85 | 45 |
| 0.2% (Nmm²) | 265 | 175 | 110 | ||
| Elongation % | 41 | 35 | 30 | 54 | 57 |
