Chemical Alloy Stainless Steel Sheet Plate 254SMO Thickness 0.6 - 30.0mm
Product Details
| Products Name | Stainless Steel Plate | Grade | 254SMO |
|---|---|---|---|
| Thickness | 0.6-30.0mm | Standard | ASTM EN GB |
| Width | 1000mm 1219mm 1500mm | Surface | 2B NO.1 |
| Brand | TISCO BAOSTEEL | MOQ | 1 Ton |
| Highlight | TISCO Alloy Stainless Steel Sheet Plate,30.0mm Stainless Steel Sheet Plate,254SMO Stainless Sheet Plate |
||
Product Description
Chemical Industrial Application Alloy 254SMO Stainless Steel Plate Sheet Thickness 0.6 - 30.0mm
| Item | 254SMO Stainless Steel Plate |
| Raw Material | Stainless steel sheet (hot rolled and cold rolled) |
| Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, 2205 ,2507,254SMO,253MA.etc. |
| Thickness | 0.6 - 30.0mm |
| Stock Thickness | 0.6mm ,0.8mm,1.0mm,1.2mm,1.5mm.2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,25mm,30.0mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as your request |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | Standard export package |
254 SMO / 1.4547 / UNS S31254 / Alloy 254 SMO
254 SMO is a high-alloy austenitic stainless steel, developed for use in sea water and other aggressive environments containing chloride.
Properties of Alloy 254 SMO:
• Great resistance against pitting corrosion and crevice corrosion, PRE = ≥42,5
• High resistance against general corrosion and stress corrosion
• Higher durability than conventional austenitic stainless steel types
• Good weldability
Chemical Properties of 254SMO Stainless Steel
| % | C | Cr | Mn | Mo | N | Ni | P | Si | S |
|---|---|---|---|---|---|---|---|---|---|
| 254 SMO | 0.02 max | min: 19.5 max:20.0 |
1.00 max | min: 6.0 max: 6.5 |
min: 0.18 max: 0.20 |
min: 17.5 max: 18.0 |
0.03 max | 0.80 max | 1.01 max |
Mechanical Properties of 254SMO Stainless Steel
| Grade | Tensile Strength ksi (MPa) min | Yield Strength 0.2% Offset ksi (MPa) min |
Elongation - % in 50 mm (min.) |
Hardness (Brinell) MAX |
Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 254 SMO Sheet & Strip | 100 (690) | 45 (310) | 35 | 223 | 96 |
| 254 SMO Plate | 95 (655) | 45 (310) | 35 | 223 | 96 |
Physical Properties
| Grade: | Alloy 254 |
|---|---|
| Density | 8.0 kg/dm^3 |
| Modulus of Elasticity | 195 GPa |
| Linear Expansion at 68to 212oF (20 to 100oC) | 16.5 X10^-6/oC |
| Thermal Conductivity | 14 w/moC |
| Thermal Capacity | 500 J/kgoC |
| Electrical Resitivity | 0.85 μΩm |
Applications of 254 SMO
✓ Sea-water systems such as sea-water cooling, cooling water piping, ballast water systems, fire-extinguishing systems, etc.
✓ Hydraulic and instrumentation hoses
✓ Equipment in pulp bleaching facilities
✓ Components for gas cleaning systems
✓ Tanks and pipes for chemicals with high halide levels
254 SMO material
254 SMO material consists of:
• Material number 1.4547
• X1CrNiMoCuN20-18-7
• UNS S31254
