TISCO BAOSTEEL 304 Stainless Steel Checkered Plate 2.0mm - 8.0mm Pattern Sheet
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 201 304 316L 2205 321.etc |
| Minimum Order Quantity | 1 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Stainless Steel Checkered Plate | Grade | 201 304 316L.etc |
|---|---|---|---|
| Thickness | 1.0 - 8.0mm | Standard | ASTM EN GB |
| Width | 1000mm 1219mm 1500mm | Surface | 2B NO.1 |
| Brand | TISCO BAOSTEEL | MOQ | 1 Ton |
| Highlight | TISCO Stainless Steel Checkered Plate,8.0mm Stainless Steel Checkered Plate,BAOSTEEL Stainless Steel Pattern Sheet Plate |
||
Product Description
TISCO BAOSTEEL 304 Stainless Steel Checkered Plate Thickness 2.0m - 8.0mm Stainless Steel Pattern Sheet
| Item | Stainless Steel Checker Plate |
| Raw Material | Stainless steel sheet (hot rolled and cold rolled) |
| Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc. |
| Thickness | 1mm-10mm |
| Stock Thickness | 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm |
| Width | 600mm – 1,800mm |
| Pattern | Chequered pattern, diamond pattern, lentils pattern, leaves pattern, etc. |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | Standard export package |
Common Grades of Stainless steel Checker Plate
Same as other stainless steel products, the stainless steel checker plate also has many grades to choose from. Here we make a brief table sheet that introduces the common grades of the SS checked plate for you.
| American Standard | European Standard | Chinese Standard | Cr Ni Mo C Cu Mn |
| ASTM 304 | EN1.4301 | 06Cr19Ni10 | 18.2 8.1 – 0.04 – 1.5 |
| ASTM 316 | EN1.4401 | 06Cr17Ni12Mo2 | 17.2 10.2 12.1 0.04 – – |
| ASTM 316L | EN1.4404 | 022Cr17Ni12Mo2 | 17.2 10.1 2.1 0.02 – 1.5 |
| ASTM 430 | EN1.4016 | 10Cr17 | Add.188.022.6.1345 |
Advantages of Stainless Steel Checkered Sheet
1. Excellent Corrosion Resistance
The checked plate made of stainless steel is more resistant than ordinary carbon and galvanized steel sheets. Besides, the Cr element in stainless steel improves the atmospheric corrosion resistance, especially in chloride and alkaline corrosion.
2. Great Anti-slipping Performance
One of the biggest characteristics of stainless steel checker plate is that it has good anti-skid features due to concave and convex patterns. This can provide all-around traction and make it very practical.
3. High Workability
The plate is easy to weld, cut, form and machine with proper equipment. In addition, this processing procedure does not damage its mechanical properties.
4. Attractive Finish
It has high-quality modern appearance and strong metallic texture. The silver-grey finish and raised diamond pattern make it more attractive and decorative. Besides, it has many different patterns to choose from to meet different application needs.
5. Long Lifetime & Easy to Clean
It has a long lifespan of more than 50 years. Also, it is easy to clean and almost maintenance-free.
Because of its unique features and anti-skip texture, stainless steel checker plate have a wide range of applications worldwide. Especially, it is suitable for food machinery, pharmaceutical machinery, electronic weighing, refrigerator, cold storage, buildings, packaging, transmission belts, automatic doors and car system. It includes:
1. Construction: floor decking sheets, roofing panels, wall cladding, garages, storage system, etc.
2. Industry: engineer processing, loading ramps, packing, printing, logistics equipment, etc.
3. Decoration: elevator cabs, building curtain walls, cold storage, ceilings, special ornamental projects, etc.
4. Transportation: cargo trailer, the interior of vehicles, automobile stairs, subway station, trailer beds, etc.
5. Road Protection: walkways, stair pedals, trench covers, pedestrian bridges, escalator approaches, etc.
6. Other Uses: store signs, displays, bars, toolboxes, counters, emergency fire landings, food preparation areas, dinnerware, cupboard, water heater, kitchen utensil, ship deck, etc.
Application of Stainless Steel Checkered Plate
Because of its unique features and anti-skip texture, stainless steel checker plate have a wide range of applications worldwide. Especially, it is suitable for food machinery, pharmaceutical machinery, electronic weighing, refrigerator, cold storage, buildings, packaging, transmission belts, automatic doors and car system. It includes:
1. Construction: floor decking sheets, roofing panels, wall cladding, garages, storage system, etc.
2. Industry: engineer processing, loading ramps, packing, printing, logistics equipment, etc.
3. Decoration: elevator cabs, building curtain walls, cold storage, ceilings, special ornamental projects, etc.
4. Transportation: cargo trailer, the interior of vehicles, automobile stairs, subway station, trailer beds, etc.
5. Road Protection: walkways, stair pedals, trench covers, pedestrian bridges, escalator approaches, etc.
6. Other Uses: store signs, displays, bars, toolboxes, counters, emergency fire landings, food preparation areas, dinnerware, cupboard, water heater, kitchen utensil, ship deck, etc.
