Hot Dipped Galvanized Steel Sheet Coil DX51D DX52D DX53D 0.3 - 3.0mm
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL WISCO |
| Certification | ISO |
| Model Number | DX51D SGCC |
| Minimum Order Quantity | 2 Ton |
| Price | 600-850 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Galvanized Steel Coil | Thickness | 0.3 - 3.0mm |
|---|---|---|---|
| Width | 1000mm 1250mm 1500mm Or As Request | Surface | Regular Spangle, Zero Spangle |
| Zinc Coating | Z40 - Z275 | Brand | BAOSTEEL ANSTEEL |
| Service | Cutting | Coil ID | 508mm |
| Highlight | Hot Dipped Galvanized Steel Sheet Coil,DX51D Galvanized Steel Coil,3.0mm Galvanized Steel Coil |
||
Product Description
Hot Dipped Galvanized Steel Sheet & Coil DX51D DX52D DX53D DX54D+Z Thickness 0.3 - 3.0mm
Galvanization is a manufacturing process involving the application of zinc coating to steel to prevent it from rusting. The zinc coating works to protect the base metal. It does this by acting as a barrier to the various corrosive elements. Therefore, it offers a sacrificial nature that gives a high-quality and long-lasting steel product.
Galvanized sheet metal is one of the most popular types of steel. This is due to its increased strength, extended durability, and formability. The corrosion-resistant property throws its usefulness up a significant notch.
|
PROCESS TYPES
|
|
Types of Galvanizations
|
|
There is a wide variety of galvanization types for corrosion protection. Each of these types has its unique performance and characteristics. Following is a brief description of the various types of galvanizations.
|
|
Hot-Dip Galvanization
|
|
Hot-dip galvanization is the most widely used method of galvanization. Just as its name suggests, it involves the dipping of the steel in molten zinc. The pool of molten zinc often maintains a temperature of about 860°F (460 °C). After proper cleaning of the base metal chemically, it gets fluxed to eliminate residual oxides. A metallurgical bond begins to form between the zinc and the intended metal. After pulling the metal from the bath, the pure zinc mixes with oxygen from the atmosphere to form zinc oxide. Then, the zinc oxide reacts with carbon dioxide to form zinc carbonate. The zinc carbonate makes the final coating on the base metal.
|
|
Electro Galvanization
|
|
Unlike the hot-dip method, this type does not use a molten zinc bath. Rather, it uses an electrical current in an electrolyte solution to transfer the zinc ions into the metal. The positively charged zinc ions are reduced electrically and deposited on the charged material. It offers the benefit of precise and uniform coating thickness. |
|
Specification And Size
|
|||||||
| CNS 1244 2013 | JIS G 3302 2019 | ASTM A653M 2017 | AS1397 2011 | EN 10346 2015 | |||
| Specifications | Hot-rolledBase
:SGHC 340 400 440 490 540 |
Cold-rolled Base: SGCC SGCD 1~3 SGC 340 400 440 490 570 |
Hot-rolled Base: SGH 340 400 440 490 540 |
Cold-rolled Base: 1~3 SGC 340 400 440 490 570 |
DS DDS CS TYPE A, B, C FS TYPE A, B SS GRADE 33(230) 37(255) 40(275) 50(340)CLASS 1~3 80(550)CLASS 1~3 |
G1~G3 G250 300 350 400 450 550 |
DX51-52-53D S220GD (250 280 320 350 550) |
| Thickness of Base Steel (mm) | 1.2~4.60 | SGCD1~3: 0.27~2.0mm SGCC/SGC: 0.19~2.0mm |
1.2~4.60 | SGCC, SGC340: 0.18~3.0mm; SGCD1~3: 0.25~2.0mm; SGC400,440: 0.229~3.0mm; SGC490: 1.8~3.0mm; SGC570: 0.229~2.2mm |
DS: 0.27~2.0mm; DDS: 0.25~2.0mm; CS/FS: 0.19~4.50mm; SS GRADE 33~80: 0.19~4.50mm; CS TYPE A, B, C, Grade 33, 37: 0.18~3.0mm; FS TYPE A, B: 0.295~2.0mm; Grade 40, 50: 0.229~3.0mm; Grade 55(380): 0.35~3.0mm; Grade 60(410): 0.47~1.6mm; Grade 65(450): 0.229~2.2mm |
G1: 0.19~4.50mm; G2&G3: 0.27~2.0mm; G250~550GD: 0.19~4.6mm; G300: 0.229~2.3mm; G350: 0.229~3.0mm; G450: 0.6~3.0mm; G500: 1.1~2.5mm; G550: 0.229~2.2mm |
DX51D: 0.19~4.50mm; S220~550GD: 0.19~4.6mm; S250GD: 0.18~2.02mm; DX52D: 0.295~2.0mm; DX53D, 54D: 0.25~2.0mm; S280GD, S350GD: 0.229~3.0mm; S320GD: 0.229~2.3mm; S550GD: 0.229~2.2mm |
