DX51D+Z40 SGCC Galvanized Steel Coil Roll Z80 Z100 Z120 Z180 Z275 0.3 - 3.0mm
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL WISCO |
| Certification | ISO |
| Model Number | DX51D SGCC |
| Minimum Order Quantity | 2 Ton |
| Price | 600-850 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Galvanized Steel Coil | Thickness | 0.3 - 3.0mm |
|---|---|---|---|
| Width | 1000mm 1250mm 1500mm Or As Request | Surface | Regular Spangle, Zero Spangle |
| Zinc Coating | Z40 - Z275 | Brand | BAOSTEEL ANSTEEL |
| Service | Cutting | Coil ID | 508mm |
| Highlight | SGCC Galvanized Steel Coil Roll,DX51D+Z40 Galvanized Steel Coil Roll,3.0mm Galvanized Steel Coil Roll |
||
Product Description
DX51D+Z40 Z80 Z100 Z120 Z180 Z275 Galvanized Steel Coil & Roll Thickness 0.3 - 3.0mm
Product Description
| Products Name | Galvanized Steel Coil |
|
Material
|
SGCC , DX51D+Z |
|
Standard
|
JIS G3302 1998, ASTM A653M/A924M 2004, all according to the customer's request
|
|
Surface
|
Zero spangle , regular spangle , oil , dry |
|
Thickness
|
0.1 mm-3.0mm, all available
|
|
Length
|
2000mm 2500mm or custom length as request |
|
Coating Weight
|
Z30-275g/m2,double side
|
| Brand | BAOSTEEL ANSTEEL WISCO |
|
Technology
|
Hot Dipped
|
|
Edge
|
Slit edge
|
|
Delivery Time
|
within 15-20 days after receive 30% deposit or depend on Quantity
|
|
Payment Term
|
T/T, Irrevocable L/C at sight (30% deposit)
|
|
Trade Term
|
EXW, FOB, CFR, CIF
|
Hot-dip Galvanized Steel is an economical and environmentally friendly alternative to stainless steel. It gives durability to a long-lasting and reliable steel product, with cost-saving benefits. It is a versatile product that can be used in a variety of applications from building structural supports to shelves, tables, and so on.
Hot-dip Galvanized Steel Coil Standard
| CNS 1244 2013 | JIS G 3302 2019 | ASTM A653M 2017 | AS1397 2011 | EN 10346 2015 | |||
| Specifications | Hot-rolled Base: SGHC SGHD SGH 340 400 440 490 540 |
Cold-rolled Base: SGCC SGCD 1~3 SGC 340 400 440 490 570 |
Hot-rolled Base: SGHC SGHD SGH 340 400 440 490 540 |
Cold-rolled Base: SGCC SGCD 1~3 SGC 340 400 440 490 570 |
DS DDS CS TYPE A, B, C FS TYPE A, B SS GRADE 33(230) 37(255) 40(275) 50(340)CLASS 1~3 80(550)CLASS 1~3 |
G1~G3 G250 300 350 400 450 550 |
DX51-52-53D S220GD (250 280 320 350 550) |
| Thickness of Base Steel (mm) | 1.2~4.60 | SGCD1~3: 0.27~2.0mm SGCC/SGC: 0.19~2.0mm |
1.2~4.60 | SGCC,SGC340: 0.18~3.0mm; SGCD1~3: 0.25~2.0mm; SGC400, 440: 0.229~3.0mm; SGC490: 1.8~3.0mm; SGC570: 0.229~2.2mm |
DS: 0.27~2.0mm; DDS: 0.25~2.0mm; CS/FS: 0.19~4.50mm; SS GRADE 33~80: 0.19~4.50mm; CS TYPE A, B, C, Grade 33, 37: 0.18~3.0mm; FS TYPE A, B: 0.295~2.0mm; Grade 40, 50: 0.229~3.0mm; Grade 55(380): 0.35~3.0mm; Grade 60(410): 0.47~1.6mm; Grade 65(450): 0.6~3.0mm; Grade 80: 0.229~2.2mm |
G1: 0.19~4.50mm; G2&G3: 0.27~2.0mm; G250~550GD: 0.19~4.6mm; G300: 0.229~2.3mm; G350: 0.229~3.0mm; G450: 0.6~3.0mm; G500: 1.1~2.5mm; G550: 0.229~2.2mm |
DX51D: 0.19~4.50mm; S220~550GD: 0.19~4.6mm; S250GD: 0.18~2.02mm; DX52D: 0.295~2.0mm; DX53D, 54D: 0.25~2.0mm; S280GD, S350GD: 0.229~3.0mm; S320GD: 0.229~2.3mm; S550GD: 0.229~2.2mm |
| Coating Mass: Regular Spangle (thickness > 0.60mm) Minimized (Zero) Spangle |
Z08~Z60 | Z08~Z60 | Z90~Z600 | Z100~Z600 | Z100~Z350 | ||
| Surface Finish | Regular Spangle, Minimized (Zero) Spangle, Extra-Smooth | ||||||
| Surface Treatment | Chromating, Oiled, Resin Coated (Anti-Fingerprint), or Green Treatment (Environmentally Friendly Anti-Fingerprint) | ||||||
| Remarks | 1. Tolerance for thickness, width, flatness and so on conforms to individual product specification. 2. All products with thickness 2.0mm and under can be skin passed. 3. The specification for thicknesses under 1.6mm for hot-rolled base metal according to JIS G3302 will be the same as for thicknesses 1.6mm. 4. The coil inside diameters can be either 508mm or 610mm. The maximum coil outside diameter is 2000mm. 5. Please make inquiries to our Sales & Marketing Division for products with special specifications. 6. Coating mass beyond the specifications above can be provided by Yieh Corp. upon mutual agreement between customers and us. 7. Coating mass Z08, Z09 and Z90 only apply for cold-rolled base metals. |
||||||
vailable Size of Our galvanized steel coil
| Product Name | Base Type | Thickness (mm) | Width (mm) |
| Hot-dip Galvanized Steel Coil | Cold-rolled Base | 0.17~3.00 | 670~1650 |
| Hot-rolled Base | 1.20~4.60 | 670~1300 |
