Place of Origin	China
Brand Name	DELTA
Certification	ISO
Model Number	304 316L 321 310S 314 2205 904L.etc
Minimum Order Quantity	500 kgs
Price	2400 - 3500 USD/Ton
Packaging Details	standard packing for export
Delivery Time	5 - 12 days based on the quantity
Payment Terms	T/T, Western Union, L/C
Supply Ability	10 Ton per week

Products	Stainless Steel Pipe	Grade	304 316L 321 2205 310S 904L.etc
Standard	ASTM GB EN	Length	Random Length Of 6m
Diameter	DN10 - DN400	Wall Thickness	SCH10 - XXS Or Unstandard Size
Type	Seamless Pipe	Service	Cutting
Highlight	Hot Rolled Duplex Stainless Steel Pipe , 1.4462 Stainless Steel Pipe , DN400 Seamless Stainless Steel Pipe

tandard Specification	SA 789 alloy 2205, astm a790 duplex 2205, a790 gr 2205 ASTM A790 / ASME SA 790 ASTM A928 / ASME SA 928 ASTM A999 / ASME SA 999
Temperature up to (in sour environments)	450°F (232°C)
Manufacturing Type	Seamless / ERW / Welded / Fabricated / CDW / CDS / DOM / CEW / 100% X Ray Welded
Thickness Range	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXH, SCH XXS, SCH XS
Standard	SUS, JIS, AISI, ASTM, GB, DIN, EN
Value Added Services	Cutting Beveling Threading Destructive and Non Destructive Ultrasonic Testing Draw & Expansion as per required Size & Length
END	Plain End, Beveled End, Treaded 2205 Stainless Steel Pipe
Marking	Specification Material Grade Nominal Size Schedule or Wall Thickness Method of Manufacturing (Seamless / Welded) Heat Number Manufacturer’s Name or Custom Logo - on request Marked Pipe Sample: Duplex 2205 12" NB SCH 40S SEAMLESS HEAT NO. XXXX
Test Certificate	Manufacturer Test Certificate 100% Radiography Test Report DFARS compliant EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC) Fumigation Certificates Raw Materials Certificate Third Party Inspection Report Moisture testing Heat Treatment Charts Surface roughness measurement HS Code Commercial Invoice Laboratory Test Certificate from Govt. Approved Lab Form A for Generalized System of Preferences (GSP)
22 Cr Duplex Steel Pipe Packaging	Packed in PE Fabric Bundles or ply wooden box wrapped in plastic or Standard seaworthy export packing or as per customers' request
Port	Shanghai , China

Duplex 2205 F51 Annealed Pipe	2205 Duplex SS Rectangle Pipes
Duplex Stainless Steel Grade 2205 Beveled End Pipes	1.4462 2205 Thin Wall Pipes
22Cr Duplex Stainless Steel Bush Hex Pipes	DSS 2205 Schedule 40 Pipes
2205 Duplex 1.4462 Fabricated Pipes	ASTM A790 Duplex 2205 Exhaust Pipes
22Cr Duplex Stainless Steel Small Diameter Pipes	Duplex Stainless Steel Grade 2205 Clad Pipes

Density	Melting Range	Yield Stress (0.2%Offset)	Tensile Stress	Elongation
7.8 g/cm3	1350 °C (2460 °F)	Psi - 80000 , MPa - 550	Psi - 116000 , MPa - 800	15 %

C	N	P	Si	Mn	Mo	Fe	Cr	S	Ni
1.0	0.03	0.02	2.0	3.0 - 3.5	22.0 - 23.0	0.03	4.5 - 6.5	0.14 - 0.2	Bal

PRESSURE RATING (PSIG)
SIZES (INCHES)	SCHEDULE (SCH)	OUTSIDE DIA. (IN)	WALL THICK. (IN)	TEMPERATURE (OF)
				100	200	300	400	500	600	650	700	750
				ALLOWABLE STRESS (PSI)
				16700	16700	16700	15500	14400	13500	13200	12900	12600
1"	40	1.315	0.133	2205	2205	2205	2047	1902	1783	1743	1703	1664
	80	1.315	0.179	3061	3061	3061	2841	2640	2475	2420	2365	2310
	160	1.315	0.250	4493	4493	4493	4170	3874	3632	3552	3471	3390
1 1/2"	40	1.900	0.145	1629	1629	1629	1512	1404	1317	1287	1258	1229
	80	1.900	0.200	2303	2303	2303	2138	1986	1862	1821	1779	1738
	160	1.900	0.281	3362	3362	3362	3120	2899	2717	2657	2597	2536
2"	40	2.375	0.154	1371	1371	1371	1272	1182	1108	1083	1059	1034
	80	2.375	0.218	1985	1985	1985	1843	1712	1605	1569	1534	1498
	160	2.375	0.344	3283	3283	3283	3047	2831	2654	2595	2536	2477
3"	40	3.500	0.216	1301	1301	1301	1208	1122	1052	1028	1005	982
	80	3.500	0.300	1844	1844	1844	1712	1590	1491	1458	1425	1391
	160	3.500	0.438	2787	2787	2787	2587	2403	2253	2203	2153	2103
4"	40	4.500	0.237	1102	1102	1102	1023	950	891	871	851	831
	80	4.500	0.337	1596	1596	1596	1482	1377	1291	1262	1233	1204
	160	4.500	0.531	2611	2611	2611	2424	2552	2111	2064	2017	1970
5"	40	5.563	0.258	965	965	965	896	832	780	763	746	728
	80	5.563	0.375	1428	1428	1428	1325	1231	1154	1129	1103	1077
	160	5.563	0.625	2474	2474	2474	2296	2133	2000	1955	1911	1866
6"	40	6.625	0.280	877	877	877	814	756	709	693	677	661
	80	6.625	0.432	1379	1379	1379	1280	1189	1115	1090	1065	1040
	160	6.625	0.719	2382	2382	2382	2211	2054	1925	1883	1840	1797
8"	40	8.625	0.322	771	771	771	716	665	623	610	596	582
	80	8.625	0.500	1218	1218	1218	1131	1050	985	963	941	919
	160	8.625	0.906	2298	2298	2298	2133	1982	1858	1817	1775	1734
10"	40	10.750	0.365	699	699	699	649	603	565	553	540	528
	80	10.750	0.594	1159	1159	1159	1075	999	937	916	895	874
	160	10.750	1.125	2289	2289	2289	2124	1974	1850	1809	1768	1727

Hot Rolled Duplex 2205 / 1.4462 Stainless Steel Pipe For Chemical Seamless DN400

Hot Rolled Duplex Stainless Steel Pipe

1.4462 Stainless Steel Pipe

DN400 Seamless Stainless Steel Pipe

Alloy 2205 Pipe Mechanical Properties

22 Cr Duplex Steel Pipe Chemical Composition

Duplex 2205 Seamless Pipe Equivalent

Duplex 2205 pipe pressure
