EN 10204-3.1 316L Stainless Plate 1.4404 Hot Rolled 3.0-16.0mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 316L |
| Minimum Order Quantity | 500 kgs |
| Price | 2100-5300 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 316L |
|---|---|---|---|
| Thickness | 0.4 - 16.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 2B | Brand | TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | 316l stainless plate 1.4404,316l stainless plate Hot Rolled,16.0mm 316l plate |
||
Product Description
EN 10204-3.1 Certificated 316L Stainless Plate Alloy 1.4404 Stainless Hot Rolled 3.0 - 16.0mm in Coil
Products Specification
| Products Name | 316L Stainless steel plate |
| Standard | JIS/JIS/SUS/GB/DIN/ASTM/AISI/EN |
| Surface | 2B, BA, NO.1, NO.4, 8K, HL, Embossing, Satin, Mirror, ect |
| Technique | Cold Rolled; Hot Rolled |
| Length | 2000mm, 2438mm, 2500mm, 3000mm, 6000mm or as required |
| Width | 1000mm, 1219mm, 1250mm, 1500mm, 1800mm, 2000mm |
| Thickness | 0.3-4mm cold rolled; 3-16mm hot rolled; 16-100mm hot rolled; Customized according to customer requirements |
| Applicaiton | nterior/Exterior decoration; Architectur; Evevator; Kitchen; Ceiling; Cabinet; Advertising nameplate; Roof structure;Shipbuilding |
| Trade Terms | EXW,FOB,CIF, CFR |
| Loading Port | Shanghai port, Tianjin port, Qindao port |
| Payment terms | 1)TT 30 % deposit in advance and balance 70%TT before delivery. |
| 2) 30% deposit by T/T, the balance by L/C at sight. | |
| 3) 100% L/C at sight. | |
| MOQ | 1Ton |
| Packing Detail | Wooden Pallet or according to customer's requirements |
| Delivery time | 1.Usually,within10-20days after receiving deposit or LC. 2.According to the order quantity |
| Samples | Free samples are provided but the freight is borne by the buyer |
General Properties of 316L stainless steel plate
Alloy 316/316L (UNS S31600/S31603) is a chromium-nickelmolybdenum austenitic stainless steel developed to provide improved corrosion resistance to Alloy 304/304L in moderately corrosive environments. It is often utilized in process streams containing chlorides or halides. The addition of molybdenum improves general corrosion and chloride pitting resistance. It also provides higher creep, stress-to-rupture and tensile strength at elevated temperatures.
It is common practice for 316L to be dual certified as 316 and 316L. The low carbon chemistry of 316L combined with an addition of nitrogen enables 316L to meet the mechanical properties of 316.
Alloy 316/316L resists atmospheric corrosion, as well as, moderately oxidizing and reducing environments. It also resists corrosion in polluted marine atmospheres. The alloy has excellent resistance to intergranular corrosion in the as-welded condition. Alloy 316/316L has excellent strength and toughness at cryogenic temperatures.
Alloy 316/316L is non-magnetic in the annealed condition, but can become slightly magnetic as a result of cold working or welding. It can be easily welded and processed by standard shop fabrication practices.
Alloys 316 (UNS S31600) and 316L (UNS S31603) are molybdenum-bearing austenitic stainless steels, which are more resistant to general corrosion and pitting/crevice corrosion than the conventional chromium-nickel austenitic stainless steels such as Alloy 304. These alloys also offer higher creep, stress-to-rupture, and tensile strength at elevated temperatures. In addition to excellent corrosion resistance and strength properties, the Alloys 316 and 316L Cr-Ni-Mo alloys also provide excellent fabricability and formability which are typical of the austenitic stainless steels.
Standard of our 316L stainless steel plate
- ASTM........A 240
- ASME........SA 240
- AMS..........5524/5507
- QQ-S........766
Chemical Analysis of 316 Stainless Steel
Weight % (all values are maximum unless a range is otherwise indicated)
| Element | 316 | 316L |
|---|---|---|
| Chromium | 16.0 min.-18.0 max. | 16.0 min.-18.0 max. |
| Nickel | 10.0 min.-14.0 max. | 10.0 min.-14.0 max. |
| Molybdenum | 2.00 min.-3.00 max. | 2.00 min.-3.00 max. |
| Carbon | 0.08 | 0.030 |
| Manganese | 2.00 | 2.00 |
| Phosphorus | 0.045 | 0.045 |
| Sulfer | 0.03 | 0.03 |
| Silicon | 0.75 | 0.75 |
| Nitrogen | 0.1 | 0.1 |
| Iron | Balance | Balance |
Mechanical Properties
At Room Temperature
| ASTM | |||
|---|---|---|---|
| Typical* | Type 316 | Type 316L | |
| 0.2% Offset Yield Strength, ksi | 44 | 30 min. | 25 min. |
| Ultimate Tensile Strength, ksi | 85 | 75 min. | 70 min. |
| Elongation in 2 inches, % | 56 | 40 min. | 40 min. |
| Reduction in Area, % | 69 | — | — |
| Hardness, Rockwell B | 81 | 95 max. | 95 max. |
Applications
- Chemical and Petrochemical Processing — pressure vessels, tanks, heat exchangers, piping systems, flanges, fittings, valves and pumps
- Food and Beverage Processing
- Marine
- Medical
- Petroleum Refining
- Pharmaceutical Processing
- Power Generation — nuclear
- Pulp and Paper
- Textiles
- Water Treatment
