UNS S32205 Stainless Steel Duplex Plate 2205 Thickness 0.4-16.0mm TISCO POSCO
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 2205 |
| Minimum Order Quantity | 500 kgs |
| Price | 2100-5300 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 2205 |
|---|---|---|---|
| Thickness | 0.4 - 16.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 2B | Brand | TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | UNS S32205 stainless steel duplex plate,stainless steel duplex plate 2205,0.4mm duplex 2205 plate |
||
Product Description
UNS S32205 Duplex Stainless Steel Plate Alloy 2205 Thickness 0.4 - 16.0mm TISCO POSCO
Specification of duplex S32205 stainless steel
| Commodity | duplex 2205 stainless steel plate |
| Key word | Cold rolled stainless steel sheet /stainless steel plate |
| Grade | 201, 202, 304, 304L, 316, 316L, 310S, 309S, 321, 301, 310, 410, 420, 430, 904L 2205 2507 254smo |
| Brand | TISCO, BAOSTEEL, POSCO, JISCO, LISCO |
| Certification | SGS, BV, IQI, TUV, ISO, etc |
| Thickness | 0.1-6mm |
| Width | 1000, 1219, 1250, 1500mm, or as your requirements |
| Length | 2000, 2438, 2500, 3000, 6000mm, or as your requirements |
| Surface | No. 1, 2B, BA, 8K Mirror, Hairline, satin, Embossed, brush, No. 4, HL, matt, PVC film, laser film. |
| Standard | ASTM, AISI, SUS, JIS, EN, DIN, GB, ASME, etc |
| Delivery time | 7-15 days after confirming the order |
| MOQ | 1 Tons |
| Advantages | Showing the splendor of your quality, wearresistant as well, strong corrosion resistance and decorative effect, durable and beautiful in good taste. |
ASTM A240 UNS S32205 duplex stainless steel strip is a chromium-nickel- molybdenum-nitrogen stainless steel strip.
It is also called duplex 2205 stainless steel strip.
UNS S32205 strip has high strength and corrosion resistance at temperatures up to 316°C.
The yield strength of duplex UNS S32205 stainless steel strip is more than twice that of normal austenitic stainless steel strip. This feature enables engineers and designers to reduce weight when designing related products, making this strip more cost-effective than 316L stainless steel strip and 317L stainless steel strip.
Waht Are ASTM A240 UNS S32205 Duplex Stainless Steel Strips Applications
- Due to the super strength and excellent corrosion resistance features, quality grade UNS S32205 stainless steel strip is widely used for below applications.
- Pressure vessels, high pressure storage tanks, high pressure pipelines
- Heat exchangers fittings, chemical processing industry
- Oil and gas pipelines,
- Sewage treatment system
- Pulp and paper industry classifiers, bleaching equipment, storage and processing systems
- High speed blades, impellers
- Cargo box of ship and truck
- Food processing equipment
ASTM A240 UNS S32205 Duplex Stainless Steel Strips Standards Comparison Table
| 2205/S32205 Stainless Steel Strips Standards Comparison Table | ||||||||
| STS | USA | UNS | CHINA | EURONORM | RUSSIA | SWEDISH | JAPANESE | |
| GRADE | AISI/ASTM | NO | GB | NO | NAME | GOST | SS | JIS |
| 2205 | 2205 | S32205 | 00Cr22Ni5Mo3N | 1.4462 | X2CrNiMoN22-5-3 | 02Ch22N5AM2 | 2377 | SUS 329J3L |
ASTM A240 UNS S32205 Duplex Stainless Steel Strips Chemical Compositions
| Grade | Standard | C | Si | Mn | P | S | Cr | Ni | Mo |
| 2205/UNS S32205 | ASTM A240 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.040 | ≤0.030 | 21.00-24.00 | 4.50-6.50 | 2.5-3.5 |
ASTM A240 UNS S32205 Duplex Stainless Steel Strips Mechanical Properties
| Grade | EN Grade | Yield Strength Rp0.2(N/mm²) | Tensile Strength Rm(N/mm²) | Hardness | Vickers Hardness(HV) | Elongation A50% |
| 2205/UNS S32205 | 1.4462 | ≥450 | ≥620 | Annealed | ≤300 | ≥25 |
What’s The Difference Between 2205 And 2507 Stainless Steel Strip?
The standard of duplex stainless steel 2205 is ASTM A240.
Duplex stainless steel 2205 alloy is a duplex stainless steel composed of 22% chromium, 2.5% molybdenum and 4.5% nickel-nitrogen alloy.
It has high strength, good impact toughness and good overall and local stress corrosion resistance.
2507 (UNS S32750) super duplex stainless steel is composed of 25% chromium, 4% molybdenum and 7% nickel.
It has strong strength and corrosion resistance, and is mainly used in chemical processing, petrochemical and sea equipment.
It has strong resistance to chloride corrosion, high thermal conductivity and low thermal expansion coefficient.
The high content of chromium, molybdenum and nitrogen makes it highly resistant to pitting corrosion, crevice corrosion and uniform corrosion.
