ASTM A29/A29m Hot Rolled Alloy Steel Round Bars SAE4340 10-350mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | SAE4340 |
| Minimum Order Quantity | 1 Ton |
| Price | 600-850 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Alloy Steel Round Bar | Diameter | 10 - 350mm |
|---|---|---|---|
| Length | 6m | Tech | Hot Rolled |
| Service | Cutting | MOQ | 1 Ton |
| Loading Port | Shanghai Port | Standard | ASTM EN GB |
| Highlight | A29m hot rolled alloy steel round bars,ASTM hot rolled alloy steel round bars,350mm rolled steel rod |
||
Product Description
ASTM A29/A29m Material SAE4340 Hot Rolled Round Bar / Alloy Steel Round Bar Diameter 10 - 350mm
Hot rolled / forged 1.6582 4340 40CrNiMoA 34CrNiMo6 Alloy Steel Rod for tools
1.6582 4340 40CrNiMoA 34CrNiMo6 Alloy Steel Rod
Similar Grade
| GB | AISI | DIN | JIS | EN | TOCT | ISO | ||
| 40CrNiMoA | 4340 | 1.6582 | SNCM439 | 41NiCrMo 7-3-2 | 40XH2MA (40XHMA) |
36CrNiMo4 | ||
Specification of 4340 steel rod
| Diameter/Thikness(mm) | Width(mm) | Length(mm) | |
| Round Bar | 16-600 | / | 3000-6000 |
| Plate | 16-200 | 200-800 | 3000-6000 |
| The specification can be customized. | |||
Chemical compositons
| C | Si | Mn | P | S | Cr | Ni | Mo | |
| 40CrNiMo | 0.37-0.44 % | 0.17-0.37 % | 0.50-0.80 % | ≤0.025% | ≤0.025% | 0.60-0.90% | 1.25-1.65% | 0.15-0.25% |
| 4340 | 0.38-0.43 | 0.15-0.35 | 0.60-0.80 | ≤0.035 | ≤0.040 | 0.70-0.90 | 1.65-2.00 | 0.20-0.30 |
Features of 4340 steel rod
- 1, chromium molybdenum alloy steel;
- 2, high strength and toughness;
- 3, good stability of hardenability and anti-overheating;
- 4, good high tensile strength with shock resistance.
Typical applications
- 1, heavy machinery and high-load of shaft;
- 2, rotor shaft and blades;
- 3, special performance requirements of the vital parts after nitriding treatment.
Packing
20ft: GW 27T; (5.80mX2.13mX2.18m)
40ft: GW 27T; (11.8mX2.13mX2.18m)
Delivery time
For abundant stock, 15-20 days.For customized products, 30-50 days.
We have full set of equipement (sawing machine/grinding/polishing machine) to make customer's specification.
1.6582 4340 40CrNiMoA 34CrNiMo6 Alloy Steel Rod
| STANDARD/GRADE of steel | Flat Bar Size(mm) | Round bar Size(mm) | Technics | ||||||
| DIN | AISM | JIS | GB(China) | Thickness | Width | Length | Diameter | Length | |
| 1.121 | SAE1050 | S50C | 50# | 10-450 | 155-2200 | 2000-12000 | Forged, Hot Rolled | ||
| 1.2311 | P20 | PDS-3 | 3Cr2Mo | 10-460 | 155-2200 | 2000-10000 | 20-200 | 2000-6000 | |
| 1.2738 | P20+Ni | - | 3Cr2NiMnMo | 21-300 | 155-2200 | 2000-8000 | 20-200 | 2000-6000 | |
| 1.2379 | D2 | SKD10 | SKD10 | 10-200 | 155-810 | 2000-6000 | 14-80 | 3000-6000 | |
| 1.2080 | D3 | SKD1 | 3Cr2Mo | 10-200 | 155-810 | 2000-6000 | 20-200 | 3000-6000 | |
| 1.2083 | 420 | - | 4Cr13 | 10-500 | 155-1200 | 2000-6000 | 12-300 | 3000-6000 | |
| 1.2344 | H13 | SKD61 | 4Cr5MoSiV1 | 10-500 | 155-1600 | 2000-6000 | 16-400 | 3000-6000 | |
| 1.2510 | O1 | SKS3 | 9CrWMn | 10-200 | 155-810 | 2000-6000 | 20-200 | 3000-6000 | |
| 1.7225 | SAE4140 | SCM440 | 42CrMo | 10-280 | 155-2200 | 2000-6000 | 16-450 | 3000-6000 | |
About Us
we are a professional special steel company, which specializing in this line in China since 2005. Our main products are Plastic Mould Steel, Hot Work Mould Steel, Cold Work Mould Steel, Alloy Structural Steel, Tool Steel, Stainless Steel, Carbon Steel and Forged Block.
To ensure provide high quality products to customers, we have close cooperation with many Chinese first class special steel enterprises, including Baosteel Group, Dongbei Special Steel, Changcheng Special Steel, Hongsheng Heavy Industry, Xingcheng Special Steel and Daye Special Steel.
