Z40-Z275 Galvanized Steel Coil Zero Spangle 0.3-3.0mm
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL |
| Certification | ISO |
| Model Number | DX51D SGCC |
| Minimum Order Quantity | 1 Ton |
| Price | 600-850 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Galvanized Steel Coil | Thickness | 0.1 - 3.0mm |
|---|---|---|---|
| Width | 1000mm 1250mm 1500mm Or As Request | Surface | Regular Spangle, Zero Spangle |
| Zinc Coating | Z40 - Z275 | Brand | BAOSTEEL ANSTEEL |
| Service | Cutting | Coil ID | 508mm |
| Highlight | Z275 Galvanized Steel Coil,Z40 Galvanized Steel Coil,3.0mm galvanized steel sheet coil |
||
Product Description
Z40-Z275 Galvanized Steel Coil Zero Spangle GI coil Thickness 0.3 - 3.0mm
Product Description
| Capacity | About 15000 tons per month for the steel sheet and coil products |
|
Material
|
SGHC, SGCC, DX51D, Q195, all according to the customer's request
|
|
Standard
|
JIS G3302 1998, ASTM A653M/A924M 2004, all according to the customer's request
|
|
Surface
|
Galvanized
|
|
Thickness
|
0.12mm-4.0mm, all available
|
|
Length
|
6m and 5.8m or as customer's request
|
|
Coating Weight
|
30-275g/m2,double side
|
|
Spangle
|
Big spangle, normal spangle, small spangle, non-spangle
|
|
Technology
|
Hot Dipped
|
|
Edge
|
mill edge, cut edge
|
|
Delivery Time
|
within 15-20 days after receive 30% deposit or depend on Quantity
|
|
Payment Term
|
T/T, Irrevocable L/C at sight (30% deposit)
|
|
Trade Term
|
EXW, FOB, CFR, CIF
|
Specification
1. Thickness: 0.15-4.0mm
2. Width: 600-1500mm
3. Inner Diameter: 508mm
4. Weight of Steel Coil: 3-18MT
5. Coating Type: Pure Zinc
6. Available Dipped Layer: 50-275g/m2
7. Surface Finish Structure: Zero Spangle & Finishing Small Spangle & Regular Spangle
8. Available Surface Treatment: Passivating & Oiling & AFP & Filming
Mechanical Properties
| Grades | Mechanical Property | Coating Adhesion | |||||
| Yield StrengthMPa | Tensile StrengthMPa |
Elongation% ≥ |
Bending Center Diameter at Following Coating Weight (g/m²) (a=Plate Thickness) | ||||
| La=80mm b=20(mm) | |||||||
| At Following nominal Thickness ( mm) | |||||||
| ≤0.7 | >0.7 | ≤140/140 | >140/140-175/175 | >175/175 | |||
| DX51D+Z | 140-350 | 270-500 | 20 | 22 | 0a | 1a | 2a |
| DX52D+Z | 140-300 | 270-420 | 24 | 26 | 0a | 1a | 2a |
| DX53D+Z | 140-260 | 270-380 | 28 | 30 | 0a | 1a | 2a |
About us
Our main products are steel products, such as Galvanized Steel Coil , Hot Dip Galvanized Steel Coil,Hot Dip Galvanized Steel Strip,Hot Dipped Galvanized Steel,Galvalume Steel Coils,Aluzinc Steel Coils,Cold Rolled Steel Coils,Cold Rolled Steel Sheets,ERW Steel Pipes,Stainless Steel Seamless Pipes,Prepainted Steel Coils,Welded Steel Pipes.We would be glad to welcome your enquries and will give you very fast feedback.
Superiority
1. Good Resistance to Corrosion
2. Qualified Processing Machinability
3. High Thermal Resistance
4. Excellent Reflectivity
5. Inexpensive and effective enough
6. Can be recycled and reused multiple times
Applications:
1. Construction: roof and roof component, outside walls of civilian and industrial buildings, garage doors and window blinds.
2. Houshold appliances: washing machine, refrigerator, television, air conditioner and ventilation system, Vacuum cleaner, solar water heater.
3. Transportation: car ceiling, auto Industry Muffler, heat shields of exhaust pipe and catalytic converter, the ship bulkhead, highway fence.
4. Industry: industrial Instruments Electric control cabinet, industrial refrigeration equipment, automatic vending machine
5. Furniture: lampshade, counter, signboard and medical facility etc.
