410/410S Stainless Steel Plate Hot Rolled 3.0 - 250mm AOD SS Plate Custom Cutting
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 410 410S |
| Minimum Order Quantity | 500 kgs |
| Price | 1200-1500USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 410 410S |
|---|---|---|---|
| Thickness | 3.0 - 250mm | Width | 1500mm 1250mm |
| Surface | NO.1 | Brand | TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | AOD Stainless Steel Plate,250mm Stainless Steel Plate,Custom Cutting Stainless Steel Plate |
||
Product Description
410/410S Stainless Steel Plate Hot Rolled 3.0 - 250mm AOD SS Plate Custom Cutting
410 stainless steel properties
Type 410 SS is a hardenable, martensitic stainless steel. It combines the superior wear resistance of high carbon alloys with the excellent corrosion resistance of chromium stainless. It features high strength, heat resistance, and good ductility. Good corrosion resistance in mild atmospheres, steam and mild chemical environments make it well suited for highly stressed parts. This grade of 410 stainless steel is magnetic in both the annealed and hardened conditions.
Our 410 stainless steel materials are used in aerospace, automotive, petrochemical and medical applications. Grade 410 SS is also used in manufacturing of products like springs and fasteners, as it can be machined after tempering or annealing. For free machining applications that do not require the higher corrosion resistance of 410, consider our grade of 416 stainless instead.
410 stainless steel Standard Inventory Specifications
- UNS S41000 AMS 5504 AMS 5613 (Chemistry only)
- ASTM A 240 ASTM A 276 ASTM A 493
- ASTM F 899 ASME SA 240 B50991B
Element | Percent by Weight | |
|---|---|---|
| C | Carbon | 0.15 max |
| Mn | Manganese | 1.00 max |
| Si | Silicon | 1.00 max |
| Cr | Chromium | 11.50 - 13.50 |
| C | Nickel | 0.75 max |
| S | Sulfur | 0.03 max |
| P | Phosphorus | 0.04 max |
410 Stainles Steel Physical Properties
The values reported below are typical for Type 410 alloy in the annealed condition.
Density: 0.276 lb/in3
Specific Gravity: 7.65
Melting Range: 2700-2790°F 1482-1532°C
Modulus of Elasticity: 29 x 106 psi (200 GPa)
Temperature Range | Coefficients | ||
|---|---|---|---|
°C | °F | cm/cm/°C | in/in/°F |
| 20-200 | 68-392 | 10.5 x10-6 | 5.9 x 10-6 |
| 20-600 | 68-1112 | 11.6 x 10-6 | 6.5 x 10-6 |
Temperature Range | W/m·K | Btu/(hr · ft · °F) | |
|---|---|---|---|
°C | °F | ||
| 100 | 212 | (0.249) | 14.4 |
410 stainless steel Specific Heat
.11 Btu/lb.·°F
Temperature Range | microhm-cm | |
|---|---|---|
°C | °F | |
| 20 | 68 | 56 |
410 stainless steel Mechanical Properties and Yield Strength
Typical Annealed Properties | Hardening Response HRC | |||
|---|---|---|---|---|
HRB | 0.2% Offset | Tensile Strength | Elongation, Percent in 2" (51 mm) | |
| 82-96 | 30 (205) - 42 (290) | 65 (450) - 74 (510) | 20 -34 | 38-45 |
410 stainless steel Common Trade Names
ATI 410 (™ Allegheny Technologies)
Alloy 410
AISI Type 410
410 stainless steel Common Applications
Aerospace structures
Automotive exhausts, manifolds and high temperature engine components
Medical instruments and devices
Petro-chemical applications
Cutlery, kitchen utensils
Flat springs
Hand tools
