409L stainless Steel Plate Hot Rolled NO.1 Finishing SS Plate 3.0 - 12.0mm With 1250mm 1500mm Width
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 409L |
| Minimum Order Quantity | 500 kgs |
| Price | 8000-8500USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 409L |
|---|---|---|---|
| Thickness | 3.0 - 12.0mm | Width | 1500mm 1250mm |
| Surface | NO.1 2B | Brand | TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | 12.0mm Stainless Steel Plate,409L Stainless Steel Plate,NO.1 Finishing Stainless Steel Plate |
||
Product Description
409L stainless Steel Plate Hot Rolled NO.1 Finishing SS Plate 3.0 - 12.0mm With 1250mm 1500mm Width
409L stainless steel plate informations
| Products Name | 409L stainless Steel Plate |
| Thickness | 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12mm |
| Width | 1250mm 1500mm |
| Surface | NO.1 |
| Brand | TISCO BAOSTEEL |
| Length | 2438mm 3000mm 6000mm |
| Standard | ASTM JIS EN DIN GB |
| Other Grade | 201 304 304L 309S 310S 316L 317L 321 347 410 420 430 436L 439 441 444 904L 2205 2507 17-4PH |
409l Stainless Steel Plate Introduction
Alloy 409 is a general purpose, chromium, titanium stabilized, ferritic stainless steel whose primary application is automotive exhaust systems. It contains 11% chromium which is the minimum amount for the formation of the passive surface film which gives stainless steels their corrosion resistance. It combines good elevated temperature corrosion resistance with medium strength, good formability, and overall cost. Alloy 409 resists corrosion strongly compared to carbon steel and is used as an alternative to carbon steel in mildly challenging environments where its high resistance to corrosion and high temperature oxidation gives an advantage. It is commonly used in applications where appearance is a secondary quality to mechanical properties and corrosion resistance.
409l Stainless Steel Plate Detailed information
| Standard | ASTM, AISI, SUS, JIS, EN, DIN, GB, ASME, ETC |
| Grade | 446, 430, 409, 904L,409L ETC |
| Certification | SGS, BV, IQI, TUV, ISO, ETC |
| Export to | Our stainless steel sheet mainly exported to Ireland, Singapore, Indonesia, Ukraine, Saudi Arabia, Spain, Canada, USA, Brazil, Thailand, Korea, Iran, India, Egypt, Kuwait, Oman, Dubai, Peru, South Africa Iraq, Mexico, Russia, Malaysia, Nigeria, Italy, etc. |
409l Stainless Steel Plate Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Ni | Ti | |
| 409L |
min. max. |
- 0.08 |
- 1.0 |
- 1.0 |
- 0.045 |
- 0.03 |
10.5~11.75 |
- 0.5 |
6C~0.75 |
409l Stainless Steel Plate Properties
| Spec | Grade | Mechanical Property | Physical Property | ||||
|
Y.S (N/MM2) |
T.S (N/MM2) |
EL (%) |
HRB |
Specific Heat (J/gºC) |
Modulus of Elasticity (KN/mm2) | ||
| JIS | SUS409L | ≥175 | ≥360 | ≥25 | ≤80 | 0.46 | 200 |
| JIS | SUS429 | ≥205 | ≥450 | ≥22 | ≤88 | 220 | |
| JIS | SUS 436L | ≥245 | ≥410 | ≥20 | ≤96 | 0.46 | 220 |
| ASTM | S43932 | ≥205 | ≥415 | ≥22 | ≤89 | 0.46 | 220 |
| EN | 1.4509 | ≥250 | 430-630 | ≥25 | ≤80 | 0.46 | 220 |
Our Services
1. Sample order is welcomed;
2. Customized packing and customer's logo (OEM Service) are accepted;
3. Various transport ways :by sea, by air & freight company( DHL, FEDEX, UPS, TNT, EMS...)
4. Factory directly sale :We can produce various stainless steel Products according to customer's
requirements.
