ASTM Standard Copper Round Bar C10100 C10200 C10300 C10400 C10500 C10700 C11000 C11300 C12000 with 4 - 250mm Diameter

最小注文数量	400kg
価格	US $7-8 / kg

商品の詳細

形	ラウンド	合金	非合金
直径	4 - 250mm	長さ	要求に応じて任意の長さ
導電率	半硬質で 97% IACS min 以上、焼きなましで 99.95% 以上	純度	銅 - 99.99%
酸素含有量	< 10 ppm (OFC)、< 100 ppm (DLP)	タイプ	正方形、六角、長方形、丸棒
六角バーのサイズ	0.375" ～ 3.000"	角棒のサイズ	0.375インチ～2.500インチ
丸棒サイズ	0.3125" ～ 3.000"	幅	5mm～350mm
厚さ	1mmから60mm	化学組成	Cu：99.99%、Pb：≦0.0005%、Zn：≦0.0001%、Fe：≦0.0010%、P：≦0.0003%、Ag：≦0.0025%、As：≦0.0005%、O：≦0.0005%、Sb： ≤0.0
不純物の制限	Bi：≦1ppm、Cd：≦1ppm、Mn：≦0.5ppm、Ni：≦10ppm、Se：≦3ppm、S：≦15ppm、Sn：≦2ppm
ハイライト	ASTM Standard Copper Round Bar , C10100 C10200 C10300 C10400 C10500 C10700 C11000 C11300 C12000 Copper Rod , 4 - 250mm Diameter Copper Bar

メッセージ

製品の説明

Copper Round Bar Specifications

High-quality copper round bars available in various grades including C10100, C10200, C10300, C10400, C10500, C10700, C11000, C11300, and C12000.

Available Grades

C10100, C10200, C10300, C10400, C10500, C10700, C11000, C11300, C12000, C12200, C14300, C14420, C14530, C19210, C19400

Oxygen Free Copper Round Bars

Dimension Details	4 mm to 70 mm in diameter, lengths up to 6 m
Round Bar Size	0.3125" ~ 3.000"
Specification	ASTM B187, GB/T5231-2001, GB/T1527-2006, JISH3100-2006, JISH3250-2006, JISH3300-2006
Standard	EN 13601: 2002
Conductivity	Above 97% IACS min in Half Hard Above 99.95% in annealed
Purity	Copper - 99.99%

ETP Copper Round Bars

Dimension Details	4 mm to 70 mm in diameter, lengths up to 6 m
Specifications	ASTM B133, ASTM B124, ASTM B187, IS: 191, 613 & 1897
Purity	Copper - 99.9%

DHP / DLP Copper Bars & Flats

Standard	GB/T5231-2001, GB/T1527-2006, JISH3100-2006, JISH3250-2006, JISH3300-2006, ASTM B152M-06, ASTM B187, ASTM B75M-02, ASTM B42-02, ASTM B152, B187, B133, B301, B196, B441, B465, JISH3250-2006, GB/T4423-2007, etc.
Size	1 mm to 60 mm
Width	5mm to 350mm
Length	Up to 6400 mm (21')
Available Grades	ASTM B42, ASTM B68, ASTM B75, ASTM B88, ASTM B111, ASTM B152, ASTM B280, DIN 2.0090, BS 2870/1/5 C106, BS 2871 C106, BS 2875 C106, ENCW024A, C12200, C12000
Types	Copper Bars, Flats, Rectangular, Rectangle

Main Copper Bar Products

ASTM B49 CC Rods
Oxygen Free Copper Round Bars
OFHC C10200 Copper Round Bar
Oxygen-Free Copper Square Bar
ASME SB187 Oxygen-Free Polished Bar
Copper Alloy CDA 10100 Bars
Cu-OF CW008A Bars
Oxygen Free Silver Bearing Copper Round Bar
Copper Alloy C11000 Round Bar
C11000 ETP Copper Flat Bar
C11000 Electrolytic Tough Pitch Copper Bar
DIN 2.0060 ETP Copper Round Rod
ASTM B187 DHP Copper Bars / Flats
C12000 DLP Copper Alloy Square Bars
Copper DHP Grade Flat / Bar
ASME SB187 DLP Copper Flat
Deoxidized Low Phosphorous Copper Bars
DHP / DLP Copper Round Bars
Cu-DHP C12200 Bars
DHP Copper Alloy Rectangle Bar
DIN 2.0090 DHP Copper Rounds
ETP Copper Bars / Flats
DLP Cu Cast Rod
ASME SB133 DLP Copper Square Bar
Commercial Copper Flat / Bar / Patta
ETP Copper Hex Bars
Oxygen Free Copper Square Bars

Chemical Composition

Element	Min (%)	Max (%)
Cu (1,2,3)	99.99
Pb		0.0005
Zn		0.0001
Fe		0.0010
P		0.0003
Ag		0.0025
As		0.0005
O		0.0005
Sb		0.0004
Te		0.0002

(1) This is a high conductivity copper which has, in the annealed condition a minimum conductivity of 100% IACS except for Alloy C10100 which has a minimum conductivity of 101% IACS.

(2) Cu is determined by the difference between the impurity total and 100%. For alloy C10100 the Cu value is exclusive of Ag.

(3) The following additional impurity maximum limits shall apply: Bi 1ppm (0.0001%); Cd 1ppm (0.0001%); Mn 0.5ppm (0.00005%); Ni 10ppm (0.0010%); Se 3ppm (0.0003%); S 15ppm (0.0015%); Sn 2ppm (0.0002).
