Pure Copper Flat Bar C11000 / T2 Copper Flat Plate in 6m Length for Electronic Area

最小注文数量	500kg
価格	US $8-9 / kg

商品の詳細

型番	C11000	形	フラット
合金	非合金	サイズ	103-20040mm または要求として
長さ	リクエストとして3-6m	他の形	四角、六角、丸
銅グレード	C11000、C10100、C12200、H59、H60、H62、H65、H68、H70、H80、H85、H90、H96、C2100、C2200、C2300、C2400、C2600、C2680、C27	処理	押出/冷間引抜
気性	1/4、堅い、堅い、1/2堅い堅い、3/4柔らかい	表面仕上げ	ミル、ポリッシュ、ブライト、オイルド、ヘアライン、ブラシ、ミラー、サンドブラスト
厚さ	1mmから60mm	幅	5mm～350mm
最大長さ	6400 mm (21')	導電率	100%のIACS
純度	99.9%
ハイライト	C11000 Copper Flat Bar , 6m Length Copper Flat Plate , Electronic Area Copper Bar

メッセージ

製品の説明

Pure Copper Flat Bar C11000 / T2 Copper Flat Plate

High-quality pure copper flat bars and plates specifically designed for electronic applications, available in standard 6-meter lengths with various customization options.

Product Specifications

Product Name	Copper Flat Bar
Copper Grades	C11000, C10100, C12200, H59, H60, H62, H65, H68, H70, H80, H85, H90, H96, and various other copper alloys
Available Sizes	Round Bar: 6mm - 200mm Square Bar: 4x4mm - 200x200mm Hex Bar: 8x8mm - 100x100mm Flat Bar: 20x2mm - 200x20mm
Standard Lengths	2m, 3m, 5.8m, 6m, or custom lengths as required
Processing Method	Extrusion / Cold Drawn
Temper Options	1/4 Hard, 1/2 Hard, 3/4 Hard, Hard, Soft
Surface Finish	Mill, polished, bright, oiled, hair line, brush, mirror, sand blast, or as required

Material Description

C11000 Electrolytic Tough Pitch (ETP) Copper offers excellent corrosion resistance, making it suitable for underground applications where soil corrosion resistance is required. This material demonstrates excellent ductility combined with high electrical and thermal conductivity, making it ideal for electrical applications.

Copper flat bars are extensively used in conduction and electricity industries due to copper's superior electrical conductivity among common metals. Only silver offers better conductive properties. Our materials are applied in electrical engineering, switch board construction, grounding systems, lightning protection, and decorative applications.

Technical Specifications

Standard: ASTM B187
Item: Copper Flats ETP
Size: Width up to 152.4mm (6")
Additional Standards: GB/T5231-2001, GB/T1527-2006, JISH3100-2006, JISH3250-2006, JISH3300-2006, and various ASTM standards
Thickness: 1mm to 60mm
Width: 5mm to 350mm
Length: Up to 6400mm (21')
Types: Copper Bars, Flats, Rectangular, Rectangle profiles

Application Areas

Bus Bars
Transformer Connectors
Earthling Protection in L.T. and H.T. Electrical Panels
Power Transmission Equipment
Control Panels

Manufacturer Information

Established in 1994, we are a China-based manufacturer with global distribution to domestic markets, South Asia, Eastern Asia, Mid East, Southeast Asia, South America, Oceania, Africa, and various European and American markets.
