Deep Drawing Quality 304DQ 0Cr18Ni9 DQ Stainless Steel Sheet Soft Material 0.412502500MM

Place of Origin	China
Brand Name	TSING SHAN
Certification	ISO, AISI, ASTM
Model Number	304DQ 0Cr18Ni9 DQ
Minimum Order Quantity	100 kg
Price	US $1.85-2.55 / kg
Packaging Details	Export Packing
Delivery Time	7 Days
Payment Terms	L/C, T/T
Supply Ability	50000KGS

Product Details

Model NO.	304DQ 0Cr18Ni9 DQ	Shape	Flat Sheet
Technique	Cold Rolled	Surface Treatment	Bright
Cr Content	18%	Ni Content	8%
Specification	12202440, 15003000, 15006000, 20006000mm	Production Capacity	50000kgs
Tensile Strength	≥ 520 MPa	Yield Strength	≥ 205 MPa
Elongation	≥40%	Section Shrinkage	≥ 60%
Hardness	≤ 187HB; ≤ 90HRB; ≤ 200HV	Melting Point	1398 ~ 1454 ºC
Thermal Conductivity	16.3 ~ 21.5 W/m.K

Leave a Message

Product Description

Deep Drawing Quality 304DQ 0Cr18Ni9 DQ Stainless Steel Sheet Soft Material 0.4*1250*2500MM

Our INOX 304 stainless steel sheets comply with ASTM A240 standards and are available in various surface finishes to meet diverse industrial requirements.

Surface Treatments and Characteristics

Surface Finish	Characteristics and Applications
NO.2B	Superior brightness and flatness compared to NO.2D, with enhanced mechanical properties through special surface treatment. Suitable for comprehensive applications.
NO.1	Heat-treated and pickled surface after hot rolling process.
NO.4	Polished with #150-#180 grit abrasive belt, providing good brightness with discontinuous coarse striations. Used for bathtubs, building ornaments, appliances, kitchen utensils, and food processing equipment.
HL	Polished with #150-#320 grit on NO.4 finish, featuring continuous streaks. Ideal for building ornaments, elevators, doors, and frontal plates.
BA	Cold rolled, bright annealed, and skin-passed for excellent brightness and mirror-like reflectivity. Perfect for kitchen apparatus and decorative applications.
8K	Excellent brightness and superior mirror-like reflectivity.

Chemical Composition

Carbon (C): ≤0.08% | Silicon (Si): ≤1.0% | Manganese (Mn): ≤2.0%
Chromium (Cr): 18.0-20.0% | Nickel (Ni): 8.0-10.0%
Sulfur (S): ≤0.03% | Phosphorus (P): ≤0.045%

Physical Properties

Property	Value	Property	Value
Tensile Strength σb (MPa)	≥ 520	Specific Heat Capacity (0-100°C, KJ/kgK)	0.50
Yield Strength σ0.2 (MPa)	≥ 205	Thermal Conductivity (W/m·K)	16.3 (100°C), 21.5 (500°C)
Elongation δ5 (%)	≥ 40	Linear Expansion Coefficient (10⁻⁶/K)	17.2 (0-100°C), 18.4 (0-500°C)
Section Shrinkage ψ (%)	≥ 60	Resistivity (20°C, 10⁻⁶ Ω·m)	0.73
Hardness	≤ 187HB; ≤ 90HRB; ≤ 200HV	Elastic Modulus (20°C, KN/mm²)	193
Melting Point (°C)	1398 - 1454	Specific Heat Capacity	0.50

Corrosion Resistance

Stainless steel's exceptional resistance to corrosion and staining, combined with low maintenance requirements and attractive appearance, makes it ideal for numerous applications. The alloy is widely used in cookware, cutlery, household hardware, surgical instruments, major appliances, industrial equipment, and automotive and construction components for large buildings. It is particularly suitable for commercial kitchens and food processing plants, as it can be steam-cleaned and sterilized without requiring paint or other surface finishes.

Applications

Food preparation equipment, especially in chloride environments
Chemical processing equipment
Laboratory benches and equipment
Rubber, plastics, pulp & paper machinery
Pollution control equipment
Boat fittings, valves and pump trim

Product Images
