Corrosion Resistant Bright Annealed Hastelloy C276 Plate 5mm Thickness Nickel Alloy Sheet
Product Details
| Model NO. | C276 | Shape | Flat |
|---|---|---|---|
| Technique | Cold Rolled | Surface Treatment | Bright |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Production Capacity | 50000kgs |
| Thickness Range | 0.1mm To 100 Mm | Width Range | 10-2500mm |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard | Temper | Annealed |
| Condition | Polished On Both Sides | Finish | Hot Rolled Plate (HR), Cold Rolled Sheet (CR), 2B, 2D, BA NO(8), SATIN |
| Cold Rolled Thickness | 0.5-6.4 Mm | Hot Rolled Thickness | 3.0-10.0 Mm |
| Length | 2m, 2.44m, 3m, Or As Required | ||
| Highlight | Corrosion Resistant Hastelloy C276 Plate,Bright Annealed Nickel Alloy Plate,5mm Thickness Hastelloy C276 Sheet |
||
Product Description
Hastelloy C276 Plate 5mm x 1200 x 3000 UNS N10276
ASTM B575 corrosion resistant bright annealed Hastelloy C276 super alloy sheet and plate offering exceptional performance in demanding industrial applications.
Product Overview
Hastelloy C-276 is considered one of the most versatile corrosion-resistant alloys available, exhibiting excellent resistance in a wide variety of chemical process environments including:
- Ferric and cupric chlorides
- Hot contaminated organic and inorganic media
- Chlorine, formic and acetic acids
- Acetic anhydride, seawater, and brine solutions
- Hypochlorite and chlorine dioxide solutions
The alloy resists formation of grain boundary precipitates in the weld heat-affected zone, making it suitable for most chemical processes in the as-welded condition with excellent resistance to pitting and stress corrosion cracking.
Available Forms
- Sheet
- Plate
- Bar
- Pipe & Tube (welded & seamless)
- Wire
Specifications & Dimensions
| ASTM Specification | ASTM B 575; ASTM B 906; ASME SB 575; ASME SB 906, ISO 6208, DIN 17750, VdTÜV 400/12.98 |
| Length & Sizes | 1000x2000mm, 1220x2440mm, 1500x3000mm, 2000x2000mm, 2000x4000mm, 2m, 2.44m, 3m, 36"x120", 48"x144", Cut to size available |
| Thickness | 0.1mm to 100mm |
| Width | 10-2500mm |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| Temper & Condition | Annealed, Polished on both sides |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
Quality Assurance
- Huge stock with timely delivery
- Raw materials certificate
- EN 10204/3.1B certification
- 100% radiography test report
- High special strength with high melt point
- Third party inspection report
- Excellent corrosive and thermal resistance
- Customer support after-sales service
- Strict control from raw material to finished product
Profiling Services
We provide comprehensive profiling services using multiple methods:
- Plasma plate cutting
- Laser plate cutting
- Oxy-propane flame cutting
Product Specialization
- Hastelloy C276 Sheet: material under 5.00mm in thickness and 600mm and over in width
- Hastelloy C276 Plate: material 5.00mm and over in thickness and over 250mm in width
- Hastelloy C276 Strip: cold-rolled material under 5.00mm in thickness and under 600mm in width
- Hastelloy C276 Clad plate: composite steel plate made by bonding Hastelloy C276 plate
Dimension Range
- Width: 914-2030mm
- Thickness: 0.1-6.0mm (Cold rolled sheet), 3-100mm (Hot rolled sheet)
- Length: 300-6000mm
- Surface Finish: No.1, 2B, BA, No.3
Applications
- Stack liners
- Ducts
- Dampers
- Scrubbers
- Heat exchangers
- Reaction vessels
- Evaporators
