Hastelloy C276 Seamless Tube with Cold-Drawing Technique, Polished Surface, and OD 6-630mm
Product Details
| Shape | Round | Technique | Cold-Drawing |
|---|---|---|---|
| Surface Treatment | Polished | Outer Diameter | 6-630mm |
| Wall Thickness | 0.5-50mm | Length | Max12000mm |
| Nickel Content | Bal. | Chromium Content | 14.5-16.5% |
| Manganese Content | Max 1.0% | Molybdenum Content | 15.0-17.0% |
| Carbon Content | Max 0.010% | Silicon Content | Max 0.08% |
| Iron Content | 4.0-7.0% | Tensile Strength | 690 MPa |
| Yield Strength | 283 MPa | ||
| Highlight | Cold-Drawing Technique Hastelloy C276 Tube,Polished Surface Nickel Alloy Tube,OD 6-630mm Seamless Tube |
||
Product Description
Hastelloy C276 Uns N10276 2.4819 Seamless Tube
Type: Nickel alloy steel pipes
Applications
- Equipment for flue-gas desulfurisation plants
- Organic chloride process equipment
Manufacturing Techniques
- Cold-finished
- Hot-finished
Product Dimensions
| Parameter | Range |
|---|---|
| Outside Diameter (OD) | 5-420mm |
| Wall Thickness (WT) | 0.5-50mm |
| Length | Maximum 12000mm |
Chemical Composition
| Element | Minimum % | Maximum % |
|---|---|---|
| Nickel (Ni) | Balance | Balance |
| Chromium (Cr) | 14.5 | 16.5 |
| Manganese (Mn) | - | 1.0 |
| Molybdenum (Mo) | 15.0 | 17.0 |
| Carbon (C) | - | 0.010 |
| Silicon (Si) | - | 0.08 |
| Iron (Fe) | 4.0 | 7.0 |
Mechanical Properties
| Property | Minimum Value |
|---|---|
| Ultimate Tensile Strength | 100 KSi (690 MPa) |
| Yield Strength (0.2% Offset) | 41 KSi (283 MPa) |
| Elongation in 2 inches (50.8mm) | 40% |
