AR400 AR500 Abrasion Resistant Steel Plate with 5.0 - 8.0mm Thickness in UT and Q+T Condition
Product Details
| Thickness | 5.0 - 8.0mm | Width | 10-2600mm |
|---|---|---|---|
| Length | 6m, 8m, 10m | Technique | Hot Rolled |
| Hardness Range | 360-540 HRC | Yield Strength | 900-1250 MPa |
| Tensile Strength | 1000-1450 MPa | Elongation | 8-11% |
| Impact Strength | -30C To -40C | Carbon Content | 0.18-0.30% |
| Silicon Content | 0.7% | Manganese Content | 1.70% |
| Chromium Content | 1.00-1.50% | Nickel Content | 0.40-0.70% |
| Molybdenum Content | 0.50% | ||
| Highlight | AR400 AR500 Abrasion Resistant Steel Plate,5.0 - 8.0mm Thickness Steel Plate,UT and Q+T Condition Steel Plate |
||
Product Description
AR400 AR500 Abrasion Resistant Steel Plate
Premium abrasion resistant steel plates in UT and Q+T condition with thickness range of 5.0-8.0mm, designed for exceptional durability in demanding industrial applications.
Product Specifications
Material Types: NM360, NM400, NM450, NM500, NM550, NM600, AR360, AR400, AR450, AR500, AR600
Thickness Range: 5mm - 80mm
Width Options: 1500mm, 2000mm, 2200mm
Length Options: 6m, 8m, 10m or custom lengths as requested
Chemical Composition
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
|---|---|---|---|---|---|---|---|---|---|
| AR500 | 0.30 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
| AR450 | 0.26 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
| AR400 | 0.25 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.70 | 0.50 | 0.005 |
| AR300 | 0.18 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.40 | 0.50 | 0.005 |
Mechanical Properties
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation A | Impact Strength Charpy V 20J | Hardness Range |
|---|---|---|---|---|---|
| AR500 | 1250 | 1450 | 8 | -30°C | 450-540 |
| AR450 | 1200 | 1450 | 8 | -40°C | 420-500 |
| AR400 | 1000 | 1250 | 10 | -40°C | 360-480 |
| AR300 | 900 | 1000 | 11 | -40°C | - |
Applications
- AR400: Premium heat-treated abrasion resistant plates with through-hardening, offering improved forming and welding capabilities
- AR450: Abrasion resistant plate for applications requiring slightly greater strength than AR400
- AR500: Ideal for mining, forestry, and construction applications
- AR600: Utilized in high-wear areas including aggregate removal, mining, and manufacturing of buckets and wear bodies
Product Benefits
Abrasion Resistant steel plates are specifically engineered for long service life in harsh conditions. These products offer excellent resistance to sliding and impact abrasion, making them ideal for mining, quarrying, material handling, construction, and earthmoving applications.
Shipping & Delivery
Delivery Time: 7-30 days after order confirmation
Shipping Methods: By sea (bulk or container)
Shipping Port: Shanghai
Packaging: Standard seaworthy export packing with steel straps, customizable as required
Payment Terms: T/T, L/C, Western Union
Price Terms: EX-Work, FOB, CFR, CIF
