Hot Rolled Abrasion Resistant Steel Plate AR400 with 5mm-80mm Thickness and Width 10-2600mm
Product Details
| Technique | Hot Rolled | Width | 10-2600mm |
|---|---|---|---|
| Thickness | 5mm-80mm | Length | 6m, 8m, 10m Or Custom |
| Hardness HRC | 5.0 - 80.0mm | Yield Strength | 900-1250 MPa |
| Tensile Strength | 1000-1450 MPa | Elongation | 8-11% |
| Impact Strength | -30C To -40C | Hardness Range | 360-540 |
| Carbon Content | 0.18-0.30% | Silicon Content | 0.7% |
| Manganese Content | 1.70% | Chromium Content | 1.00-1.50% |
| Production Capacity | 50000kgs | ||
| Highlight | Hot Rolled Abrasion Resistant Steel Plate,5mm-80mm Thickness AR400 Steel Plate,Width 10-2600mm Wear Resistant Steel Plate |
||
Product Description
Wear Resistant Steel Plate AR400 & AR500 Steel Plate NM400 Abrasion Resistant Steel Plate
Premium abrasion resistant steel plates designed for extended service life in demanding industrial applications including mining, quarrying, material handling, and construction equipment.
Product Specifications
| Description | Abrasion Resistant Steel Plate |
|---|---|
| HRC | 5.0 - 80.0mm |
| Related Material | NM360, NM400, NM450, NM500, NM550, NM600, AR360, AR400, AR450, AR500, AR600 |
| Thickness | 5mm - 80mm |
| Width | 1500mm, 2000mm, 2200mm |
| Length | 6m, 8m, 10m or custom cutting as requested |
Chemical Composition
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
|---|---|---|---|---|---|---|---|---|---|
| AR500 | 0.30 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
| AR450 | 0.26 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
| AR400 | 0.25 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.70 | 0.50 | 0.005 |
| AR300 | 0.18 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.40 | 0.50 | 0.005 |
Mechanical Properties
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation A | Impact Strength Charpy V 20J | Hardness Range |
|---|---|---|---|---|---|
| AR500 | 1250 | 1450 | 8 | -30°C | 450-540 |
| AR450 | 1200 | 1450 | 8 | -40°C | 420-500 |
| AR400 | 1000 | 1250 | 10 | -40°C | 360-480 |
| AR300 | 900 | 1000 | 11 | -40°C | - |
Application Areas
- AR400: Premium abrasion resistant steel plates with heat treatment and through-hardening. Features improved forming and welding capabilities.
- AR450: Abrasion resistant plate used where slightly greater strength is required beyond AR400 specifications.
- AR500: Suitable for mining, forestry and construction applications requiring high durability.
- AR600: Utilized in high-wear areas including aggregate removal, mining operations, and manufacturing of buckets and wear bodies.
Ordering & Shipping Information
Delivery Time: 7-30 days after order confirmation
Price Terms: EX-Work, FOB, CFR, CIF
Payment Terms: T/T, L/C, Western Union
Shipping Method: By sea from Shanghai port
Packaging: Standard seaworthy export packing with steel straps, customizable as required
Main Markets: Europe, South America, Africa, Oceania including USA, Germany, India, Iran, Dubai, Iraq, Vietnam, Ireland, Singapore
