Hot Rolled AR400 Abrasion Resistant Steel Plate with Width 10-2600mm and Thickness 5-80mm
Product Details
| Technique | Hot Rolled | Width | 10-2600mm |
|---|---|---|---|
| Thickness | 5mm-80mm | Length | 6m, 8m, 10m |
| Hardness HRC | 5.0 - 80.0mm | Carbon Content | 0.25 |
| Silicon Content | 0.7 | Manganese Content | 1.7 |
| Chromium Content | 1.5 | Yield Strength | 1000 MPa |
| Tensile Strength | 1250 MPa | Elongation | 10 |
| Impact Strength | -40C | Hardness Range | 360-480 |
| Production Capacity | 50000kgs | ||
| Highlight | Hot Rolled Abrasion Resistant Steel Plate,Width 10-2600mm AR400 Steel Plate,Thickness 5-80mm Wear Resistant Steel Plate |
||
Product Description
AR400 Abrasion Resistant Steel Plate
Abrasion Resistant (AR) steel plate is manufactured in the as-rolled condition and specifically developed for extended service life in demanding environments. These premium steel plate products deliver exceptional performance in applications involving mining, quarrying, material handling, construction, and earthmoving operations.
Product Specifications
| Description | Abrasion Resistant Steel Plate |
|---|---|
| HRC | 5.0 - 80.0mm |
| Related Materials | NM360, NM400, NM450, NM500, NM550, NM600, AR360, AR400, AR450, AR500, AR600 |
| Thickness | 5mm - 80mm |
| Width | 1500mm, 2000mm, 2200mm |
| Length | 6m, 8m, 10m or custom lengths as requested |
Chemical Composition
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
|---|---|---|---|---|---|---|---|---|---|
| AR500 | 0.30 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
| AR450 | 0.26 | 0.7 | 1.70 | 0.025 | 0.015 | 1.00 | 0.70 | 0.50 | 0.005 |
| AR400 | 0.25 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.70 | 0.50 | 0.005 |
| AR300 | 0.18 | 0.7 | 1.70 | 0.025 | 0.015 | 1.50 | 0.40 | 0.50 | 0.005 |
Mechanical Properties
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation A | Impact Strength Charpy V 20J | Hardness Range |
|---|---|---|---|---|---|
| AR500 | 1250 | 1450 | 8 | -30°C | 450-540 |
| AR450 | 1200 | 1450 | 8 | -40°C | 420-500 |
| AR400 | 1000 | 1250 | 10 | -40°C | 360-480 |
| AR300 | 900 | 1000 | 11 | -40°C | - |
Application Guide
- AR400: Premium abrasion resistant steel plates featuring heat treatment and through-hardening with enhanced forming and welding capabilities
- AR450: Ideal for applications requiring slightly greater strength than AR400
- AR500: Suitable for mining, forestry, and construction applications
- AR600: Utilized in high-wear areas including aggregate removal, mining, and manufacturing of buckets and wear bodies
Shipping & Delivery Information
Delivery Timeline
Within 7-30 days after order confirmation
Packaging
Standard seaworthy export packaging with bundled steel straps. Custom packaging available upon request.
Shipping Methods
Transport via truck to port, followed by sea shipping (bulk or container)
Container Specifications
20ft GP: 5.8m × 2.13m × 2.18m (24-26 CBM)
40ft GP: 11.8m × 2.13m × 2.72m (68 CBM)
40ft GP: 11.8m × 2.13m × 2.72m (68 CBM)
