12mm Thick ASTM A572 Gr 50 Hot Rolled Steel Plate for Boiler and Pressure Vessel Applications

Minimum Order Quantity	1 Ton
Price	US $720-1,450 / Ton

Product Details

Thickness	6MM To 300MM	Width	1500mm To 4050mm
Length	3000mm To 15000mm	Technique	Hot Rolled
Carbon Content	0.27-0.31%	Silicon Content	0.13-0.45%
Manganese Content	0.79-1.30%	Phosphorus Content	0.035%
Sulfur Content	0.035%	Yield Strength	260 Mpa
Tensile Strength	485-620 Mpa	Elongation	17-21%
Carbon Equivalent	C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15%	Production Capacity	500000kgs
Supplementary Technology	HIC Test, NACE MR0175, Z15, Z25, Z35, S1-S9, S11, S12, S14, S17
Highlight	12mm Thick Steel Plate , ASTM A572 Gr 50 Steel Plate , Hot Rolled Boiler Plate

Leave a Message

Product Description

Steel Plate 12mm Thick ASTM A572, Gr 50, S355 (Grade 50ksi)

ASME SA516 GR 70 Plate Boiler and Pressure Vessel Hot Rolled Astm A516 Gr 70 Mechanical Specifications

ASME SA516 Steel Plate

SA516Gr70 | ASME SA516 Grade 70 | SA516 Gr.70 STEEL PLATE

ASME SA516 standard specification for pressure vessel plates, carbon steel for moderate and lower-temperature service.

ASME SA516 plates 40mm and under in thickness is normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved, or both. ASME SA516 grade plates over 40mm in thickness shall be normalized.

Supplementary Technology

HIC Test
NACE MR0175
Z15 | Z25 | Z35
S1 | S2 | S3 | S4.1 | S5 | S6 | S7 | S8 | S9 | S11 | S12 | S14 | S17

Available Dimensions

Thickness: 6MM to 300MM
Width: 1500mm to 4050mm
Length: 3000mm to 15000mm

Gangsteel is specialized in supplying ASME SA516 steel plate in SA516 grade 70.

SA516 Grade 70 Chemical Composition

Grade SA516 grade 70	C	Si	Mn	P	S
Thick <12.5mm	0.27	0.13-0.45	0.79-1.30	0.035	0.035
Thick 12.5-50mm	0.28	0.13-0.45	0.79-1.30	0.035	0.035
Thick 50-100mm	0.30	0.13-0.45	0.79-1.30	0.035	0.035
Thick 100-200mm	0.31	0.13-0.45	0.79-1.30	0.035	0.035
Thick >200mm	0.31	0.13-0.45	0.79-1.30	0.035	0.035
