CCS Certified Hot Rolled AH36 DH36 EH36 Ship Steel Plate for Marine Vessel Construction
Product Details
| Model NO. | A36 AH36 EH36 DH36 | Technique | Hot Rolled |
|---|---|---|---|
| Width | 100-3000mm | Length | 10000MM Or Customized |
| Thickness | 3mm-300mm | Thickness Tolerance | ±0.15mm |
| Material | AH32 DH32 EH32 AH36 DH36 | Edge | Mill Edge Slit Edge |
| Yield Strength | 355 MPa | Tensile Strength | 490-620 MPa |
| Elongation | 21% | Impact Energy | 34J At -40°C |
| Specific Gravity | 7.8 | Production Capacity | 500000kgs |
| Chemical Composition | C:0.18%, Si:0.1-0.5%, Mn:0.9-1.6%, P:0.035%, S:0.035%, V:0.05-0.1%, Al:0.015%, Cr:0.2% | ||
| Highlight | CCS Certified Ship Steel Plate,Hot Rolled Marine Steel Plate,AH36 DH36 EH36 Shipbuilding Steel Plate |
||
Product Description
ABS AH36 Ship Steel Plate
CCS Certified AH36, DH36, and EH36 marine steel plates for shipbuilding applications. These high-tensile strength steel plates are engineered for optimal performance and longevity in marine environments.
Product Specifications
Material Grades: AH32, DH32, EH32, AH36, DH36, EH36
Standards: AISI, ASTM, BS, DIN, GB, JIS, ISO9001
Technique: Hot Rolled
Surface Treatment: Coated, Clean, Blasting, Painting
Width: 25-3000mm
Length: 10000mm or Customized
Edge: Mill Edge, Slit Edge
Shape: Flat Sheet
ABS EH36 Shipbuilding Steel
ABS EH36 steel is a high tensile strength marine steel engineered for optimal long-lived shipbuilding applications. With a specific gravity of 7.8, these plates offer exceptional strength and durability.
Mechanical Properties
Yield Strength: 51,000 psi (355 MPa)
Tensile Strength: 71,000 - 90,000 psi (490-620 MPa)
Dimensional Range
Thickness: 4mm to 260mm
Width: 1200mm to 4000mm
Length: 3000mm to 18000mm
Chemical Composition
| Element | Content (%) |
|---|---|
| C | 0.180 |
| Si | 0.1-0.5 |
| Mn | 0.90-1.6 |
| P | 0.035 |
| S | 0.035 |
| V | 0.05-0.10 |
| Al | 0.015 |
| Cr | 0.200 |
| Cu | 0.350 |
| Mo | 0.080 |
| Nb | 0.02-0.05 |
| Ni | 0.400 |
| Ti | 0.020 |
Mechanical Properties by Thickness
| Thickness (mm) | Min Yield (MPa) | Tensile (MPa) | Elongation (%) | Min Impact Energy |
|---|---|---|---|---|
| 8mm-50mm | 355 | 490-620 | 21% | 34J at -40°C |
| 51mm-70mm | 355 | 490-620 | 21% | 41J at -40°C |
| 71mm-100mm | 355 | 490-620 | 21% | 50J at -40°C |
Note: Minimum impact energy values are for longitudinal testing.
Applications
- Ship hull construction and ship repairing
- Container and bulk cargo vessels
- Cruise ships, ferries, and yachts
- Offshore oil drilling platforms
- Platform pipe joints and structural components
- Protection against chemical corrosion, electrochemical corrosion, and marine organisms
Ordering Information
Minimum Order Quantity: 25 tons (sample orders accepted)
Shipment Time: 15-20 workdays after receiving deposit or L/C
Export Packaging: Waterproof paper and steel strip packed, standard seaworthy package
Price Terms: CIF, CFR, FOB, EX-WORK
Production Capacity: 250,000 tons/year
Product Images
Gnee is a professional manufacturer and supplier of steel sheets and plates with ISO 9001 certification. We maintain large inventories of stainless steel products including various grades and offer quality guaranteed products with on-time delivery and comprehensive after-sales warranty.
